Please read this manual carefully before setting-up and using your unit

Super SeaSpy Camera

Operator & Installation

Manual

The electronic version of this document is the controlled copy. Therefore all

printed versions of this document are uncontrolled.

For the latest manual revision always visit ''www.tritech.co.uk''

Supplied by

Issue 0

TIL -- - Eng -- - Spec -- - 098

Super SeaSpy Camera OIM

Table of Contents

Need help?

Do you have a question about the Super SeaSpy PCAM1Z-S and is the answer not in the manual?

Questions and answers

Summary of Contents for Tritech Super SeaSpy PCAM1Z-S

Page 1 Manual The electronic version of this document is the controlled copy. Therefore all printed versions of this document are uncontrolled. For the latest manual revision always visit ‘‘www.tritech.co.uk’’ Supplied by Issue 0 TIL -- - Eng -- - Spec -- - 098...
Page 3 COPYRIGHT © Tritech International Ltd The copyright in this document is the property of Tritech International Limited. The document is supplied by Tritech International Limited on the understanding that it may not be copied, used, or disclosed to others except as authorised in writing by Tritech International Limited.
Page 4: Table Of Contents
Tritech International Ltd Super SeaSpy Camera OIM Handling of Electrostatic-Sensitive Devices Statutory Compliances Waste Electrical and Electronic Equipment Directive (2002/96/EC - WEEE) Safety Statements Technical Support Introduction Operating conditions SAFETY OF USE Internal Layout & Configuration SS2 MANUAL ELECTRONIC LIGHT CONTROL SETUP:...
Page 5: Handling Of Electrostatic-Sensitive Devices
Tritech International Ltd Super SeaSpy Camera OIM Handling of Electrostatic-Sensitive Devices Attention Observe Precautions for handling Electrostatic Devices Caution Handling of Electrostatic-Sensitive Devices Certain semiconductor devices used in the equipment are liable to damage due to static voltages. Observe the following precautions when handling these devices in their unterminated state, or sub-units...
Page 6: Warranty Statement
Super SeaSpy Camera OIM Warranty Statement Tritech International Limited herein after referred to as TIL TIL warrants that at the time of shipment all products shall be free from defects in material and workmanship and suitable for the purpose specified in the product literature.
Page 7: Statutory Compliances
Waste Electrical and Electronic Equipment Directive (2002/96/EC - WEEE) Tritech International Limited is very aware of its responsibilities to the environment and to the sustainability of the resources of our planet. The European Commission has issued the above Directive in an effort to reduce the impact on the environment due to electronic appliances being committed to landfill after they have come to the end of their useful life.
Page 8: Technical Support
Tritech International Ltd Super SeaSpy Camera OIM Technical Support Contact your local agent or Tritech International Ltd Tritech International Ltd. Peregrine Road, Mail Westhill Business Park, Westhill, Aberdeen, AB32 6JL, UK Telephone ++44 (0)1224 744111 ++44 (0)1224 741771 Email support@tritech.co.uk www.tritech.co.uk...
Page 9: Introduction
Super SeaSpy Camera OIM Introduction The Tritech PCAM1Z-S Super SeaSpy underwater video camera is a compact, high resolution, full colour camera with integral low voltage lighting. Built to survive in the harsh underwater inspection environment the Super SeaSpy has been designed to be compact and rugged while at the same time provide a high quality colour picture.
Page 10: Operating Conditions
The camera should not be used out of the limit conditions specified in this manual. For any special requirement please contact TRITECH INTERNATIONAL LTD. The camera has internal temperature sensing circuitry which will protect the camera from damage due to overheating.
Page 11: Internal Layout & Configuration
Tritech International Ltd Super SeaSpy Camera OIM Internal Layout & Configuration 6-PIN DIN MATES TO WATER BLOCK CONNECTOR CAMERA PSU & CONTROL PCB VIDEO MODULE RETAINING WASHER CAMERA VIDEO MODULE PCB STACK CAMERA FOCUS ADJUSTMENT NUTS VIDEO MODULE MOUNTING COLLAR...
Page 12: Ss2 Manual Electronic Light Control Setup
+/- LIGHT line (PIN1 on Tritech connector). If you wish to return to Dynamic Light Control mode, after making a manual control input, the camera must be switched OFF for several seconds.
Page 13: S21 Video Output Setup
Tritech International Ltd Super SeaSpy Camera OIM S21 VIDEO OUTPUT SETUP: TO ENABLE VIDEO OUTPUT (Without Amplification) Link solder pads 1 & 2 together - Amplification & video filter are OFF DEFAULT SETTING TO ENABLE VIDEO OUTPUT (With Amplification) Link solder pads 2 & 3 together - Amplification &...
Page 14: Fuse Information
Tritech International Ltd Super SeaSpy Camera OIM FUSE INFORMATION VIDEO LINE FUSE – F2 250mA quick blow fuse protects all the outputs of the camera module and amplifier. 0451.250MRL- LITTELFUSESMD250mA REF. Farnell: 9922148 POWER SUPPLY FUSE – F1 1.5A quick blow fuse protects all the camera power supply circuitry against over voltage and reverse polarity.
Page 15: Focus
Tritech International Ltd Super SeaSpy Camera OIM Focus By rotating the nuts on each side of the camera module (shown in the picture in section INTERNAL LAYOUT & CONFIGURATION) this will compress or release the module mounting collar and will affect the focus accordingly.
Page 16: Part List
Tritech International Ltd Super SeaSpy Camera OIM Part list HEAD HOUSING PCAM1Z-H01 BODY HOUSING PCAM1Z-H02 PSU/DRIVER BOARD PCAM1Z-PSU WATER CORRECTED PORT PCAM1Z-WP01 VIDEO MODULE PCAM1Z-V482 VIDEO MODULE MOUNTING COLLAR PCAM1Z-V00 LED BOARD PCAM1Z-L12 SUNDRIES KIT PCAM1Z-S1 O-RING SET PCAM1Z-R03 Issue 0...
Page 17: Appendix 1 Product Specification
Tritech International Ltd Super SeaSpy Camera OIM APPENDIX 1 Product Specification Issue 0 TIL -- - Eng -- - Spec -- - 098 Page 17 of 19...
Page 18: Appendix 2 Super Seaspy Camera Pin Configuration
Tritech International Ltd Super SeaSpy Camera OIM APPENDIX 2 Super SeaSpy Camera Pin Configuration Issue 0 TIL -- - Eng -- - Spec -- - 098 Page 18 of 19...
Page 19: Appendix 3 Super Seaspy Circuit Diagrams
Tritech International Ltd Super SeaSpy Camera OIM APPENDIX 3 Super SeaSpy Circuit Diagrams Issue 0 TIL -- - Eng -- - Spec -- - 098 Page 19 of 19...
