- Page 1 243-1145 SOLDERING GUN Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING : When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas can cause injuries. 2.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS 15. USE EYE PROTECTION. Use a full-face mask if the work you’re doing produces metal filings, dust or wood chips. Goggles are acceptable in other situations. Wear a clean dust mask if the work involves creating a lot of fine or coarse dust.
- Page 4 FUNCTION DESCRIPTION 1.Trigger Switch TING PROCEDURES Soldering Tip 3. L L ight 4. Handle OPERATING PROCEDURES Preparing the Soldering Tip 1. Using a screwdriver, check that the Soldering Tip Nuts are not loose. Do not overtighten as you may strip the threads. 2.
- Page 5 MAINTENANCE ADJUSTMENTS Note: Maintenance requiring disassembly of this tool should only be performed while the product is disconnected from the electrical supply circuit and give sufficient time to cool down. 1. When you are finished soldering, heat up the Soldering Tip (1) again and apply a small amount of rosin-core solder to coat the tip.
- Page 6 PARTS LIST ADJUSTMENTS Item # Description Body Transformer Connectors Screw Soldering Tip Connector Holder Cable Strain Relief Light Bulb Power Cord Trigger Switch Electrical Connection Cover Spring Lever Connecting Rods...
- Page 7 SCHEMATIC DRAWING WARNING Repairs should be made by an authorized repair center. Do not this power tool . Contact at open or disassemble 1-866-915-8626 for questions regarding this power tool.
