Table of Contents Product Introductions ....................... 2 Precautions ........................4 Guides of Using GPS Navigator..................5 Basic Operation ......................6 Bluetooth and FM ......................9 Change Wallpaper......................14 Media Playback......................16 Games ........................... 22 System Setting ....................... 23 Specifications ......................... 26 In order to enable you to use this product correctly and quickly, we design and provide this manual to introduce the product and the operation instructions.
Precautions Always operate the vehicle in a safe manner. Do not become distracted by the navigation while driving, and always be fully aware of all driving condition. Minimize the amount of time spent viewing the screen of the navigation while driving and use voice prompts when possible.
Guides of Using GPS Navigator This device is supplied with built-in Lithium battery which could be recharged. In order to prolong battery's service life, please charge it at least 8 hours before the first times use. When using the device for the first time, it is necessary to calibrate the screen strictly to avoid poor touch effect result from inaccurate calibration.
Basic Operation WindTouch Technology This GPS adopts the new touch technology - advanced “WindTouch”. The user is not only can operate by pressing keys as before, but can click the menu, dragging the options and so on. With this innovative and functional “WindTouch”, the user can handle all functions simply by clicking with fingertip.
Main Menu Main Menu Sub-menu Media VideoPlayer MusicPlayer Image Viewer Text Reader Browser Setting Setting Calibrate GPS TTFF Game Click the main menu icon on the left to open the sub-menu. Click the same icon again to close the sub-menu.
Page 9
Drag leftward or rightward on the Taskbar area which is under the sub-menu to choose different icon or directly click the icon of sub-menu to launch the program.
Bluetooth Click the setting,double click and then enter bluetooth. Pls see thefollowing: You will find the following interface:...
Page 11
This product can be used for Bluetooth earphone. Click and then enter the link status as follows.Pls connect your Bluetooth mobile phone with in 1 minute. Pls repeat this operation if exceed 1 minute. Note: Pls review the operation manual of mobile phone for adding the Bluetooth device on the phone, and the connection code is 0000.
Page 12
2. Dialthe Phone Click and enter dial interface. You can make a call via this product. 3. Calls History Click and you will see the calls history of dial out/dial in & hng up.
Page 13
4. Shortcut Dial This device support short cut dial, click and you can callfast on the last telephone No. in the calloutrecord 5. Connection Record of Bluetooth In the records of Bluetooth connection the connection records between this device & other Bluetooth devices are saved.
Page 14
Click , and you can check the version information. Pls see the following: Click the FM transmitter menu and enter the operation interface of FM transmitter. 1. Move the frequency adjustment button left & right with your finger or click+-to select afixed frequency.
Change Wallpaper The replacement of wallpaper Touch on the top edge of desktop to change the wallpaper. Audio Control Click the music symbol on the top right of desktop to turn on or off the audio. Audio on Audio off...
Page 16
Reset the Device If the system halts when the GPS is running, restart the device by pressing the reset button on the back side of device. Connect to Computer & Transfer Data Files 1. Connect GPS device with USB Cable to computer. 2.
Media Playback Media Center On the main menu, click and select Media => Browser to enter My Media Center. On the top right corner of My Media Center interface and other main interface, there is a power icon of battery. When the device is connected to the computer or charger, the power pulse in power icon is scrolling, and the icon is in static state while the battery is fully charged.
Page 18
File Classification Management Button Icon File Type Audio ( MP3, WMA, OGG, ACC) Video ( AVI, WAV, 3GP, ASF, MPG) Image (JPEG, BMP, GIF) e-Book (TXT) My Media Center Play List Click different icons on the bottom of browser to display related files.
Page 19
Click the upper right icon of the browser to add or delete the files. Select and click a media file in any category, the player or browser will be started automatically to play the designated file. User can browse all the files in My Media Center to play, edit or delete files. Music Player Music player supports the audio files of following formats: MP3, WMA, OGG, and ACC.
Page 20
Play List in Media Player File options Add file (to open file-selection dialog box) Move file upward Move file downward Delete file OK and back Cancel and close File-selection dialog box Selecting : When this botton is hold, user can select multiple files to add into playlist. All : Press this button to select all files in the current directory.
Page 21
Video Player Video Player supports video files in format of AVI, WAV, 3GP, ASF, and MPG. On the main menu, press Media => Video Player to brows video files and start to play. Customized Icon of Video File In the Media Center, user can select a frame from the video file to be its icon so the user can recognize the file easily by previewing the icon.
Page 22
Image Viewer Interface Toolbar Icons Descriptions Open files To open image files in specific direction. Previous Display the previous image. Next Display the next image. Zoom in Zoom in the image. Zoom out Zoom out the image. Drag and move to view the image if image size is larger Hand tool than the screen.
Save bookmark Save a bookmark (take row as a unit) Font Size Select font size (Small / Middle / Big) Page selection Move to specific page Encoding Select character encoding In reading mode, click “Current/total Pages” on the upper right corner can switch to “Current/total Rows”.
Line Miner System Setting On the main menu, there are several setting options are available. User can click and select these options to adjust the system properly according to individual requirements.
Page 25
System Information: It describes the software version, remained and total memory capacity details. Sound Setting: Adjust audio volume of system. Backlight Setting: Adjust the backlight. Background Selection: User can select a picture in BMP format from folder and set it as desktop background.
Page 26
Language Selection: Selection would be effected only after the device is restarted. Calibrate the Touch Screen For the first time use of the GPS device or after it’s used for a long time, the user can enter the screen calibration to reset it. In order to keep high accuracy, please use stylus to calibrate and follow the instructions.
Specifications Basic Specifications Model Navigationssystem GEO-43 ® Operating System Windows CE 6.0 core Built-in Memory 2GB NAND Flash Memory Power Source Built-in Li-ion Battery (3.7V/1100mAh) Memory Expansion Support SD / MMC Card Interface USB 2.0 (High-Speed) Display System Screen Size 4.3"...
Page 28
Audio Features Audio Format Support MP3, WMA, OGG, ACC, AC3 Built-in Loudspeaker, 1W Loudspeaker Lyrics Support LRC lyrics function Additional function Built-in Games Others Car Charger, USB Cable, Stylus, Car Mount Accessories User’s Manual...
