Chaney Instrument 00592W Instruction Manual

Indoor/Outdoor Thermometer and Hygrometer with Atomic Radio Controlled Clock
Thank you for purchasing the new generation radio-controlled wireless weather clock. This unit
is designed and engineered with the state-of-art technology and components. This instrument
will provide accurate and reliable measurement including temperature and humidity tendency as
well as humidity and indoor/outdoor temperatures. Please read this manual carefully to fully
explore the features and benefits of the new product.

Name and Functions of Buttons:

Press Functions
SET Manual synchronization
"+" 1 step advance in Set mode,
On/off for alarm
-/C/F (zone) 1 step backward in Set mode,
Celsuis/Fahenheit
Alarm Read alarm time
MEMORY Read maximum/minimum records
CHANNEL Select Channel 1, 2, 3
Snooze/Light Press to activate the Snooze function and to illuminate the backlight for 3
seconds

BATTERY INSTALLATION

For the first installation, insert batteries in the main unit first, then the remote sensor.
1. Insert 2 AA alkaline batteries into the main unit.
2. Insert 2 AA alkaline batteries into the remote sensor.
*Note: Severe cold weather can cause the batteries to freeze and function improperly. Use
lithium batteries when operating under extremely low temperature conditions.

SETTING UP THE WIRELESS THERMOMETER:

• Always insert batteries into the main unit first and then the remote sensor. Your new RF
thermometer is built with random security code technology. The main unit will learn the
random security code of the remote sensor and will be registered without being
interfered with by a neighbor who may be using the same type of sensor under the same
channel setting. The base unit can monitor up to 3 remote sensors at a time. (One
sensor is included with this item.)
• Lift off the rear cover of the remote sensor by separating front and back panels at the
side seam.
• Select the channel with the switch on the right hand side. Place batteries in the sensor
and press "TX" button to send a signal to the main unit. Select temperature display at
this time by pressing the "C/F" button. Replace the back cover on remote sensor.
• Mode button on the inside of the remote sensor allows you to see the humidity and the
temperature. When you press the button once it will show humidity, when pressed again
Instruction Manual
Model number 00592W
enter clock/calendar set
Enter alarm set
Hold 3 seconds
rapid advance in the Set mode
Select Time zone
Clear current channel(s)
