- Page 1 Model MTI-5 Operator's Manual A Patented Product of Motion Technology, Inc. 6 Huron Drive Natick, MA 01760 Telephone: (508) 653-0082 Technical Support: 888-664-6640 MTI Form OP-0005 Rev. 002 7/98 E167653...
- Page 2 Rear = 3" Min. Top = 24" Min. Oil capacity: 2.5 US Gallons Approvals and Listings UL cUL NSF CE CSA AUTOFRY and NO HOODS! NO VENTS! NO PROBLEM? are registered trademarks of Motion Technology, Inc. MTI Form OP-0005 Rev. 002 7/98 E167654...
-
Page 3: Table Of Contents
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Table of Contents Prepare electrical service Prepare counter top Set-up and Installation Remove components Re-set high limit Leg installation Initial cleaning Install charcoal filter Install oil pot Install heater box Install food basket clip... -
Page 4: Prepare Electrical Service
A licensed electrician in accordance with the National Electrical Code (NEC) and all local codes must install electrical service. Do not alter the factory supplied power cord or plug. Never attach the AUTOFRY to an extension cord. Consult the Identification Tag for equipment wattage and voltage. -
Page 5: Remove Components
130 pounds Remove and save the packing materials. Be sure to inspect the AUTOFRY. Your AUTOFRY has left the factory in perfect condition and has been packaged to withstand rugged travel. However, in the event that you observe damage to the AUTOFRY, you should contact the carrier immediately and report any damages. -
Page 6: Leg Installation
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Charcoal filter removal and leg installation. • With the AUTOFRY still on its shipping pallet, tilt the unit backward and remove the charcoal filter from the food exit cutout. • Install two of the adjustable legs by rotating them clockwise to a hand tight fit into the front two leg plates located on the underside of the AUTOFRY. -
Page 7: Initial Cleaning
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Initial Cleaning. • Wash the oil pot, wire food basket and food exit chute in warm soapy water followed with a clear water rinse. • Remove the food exit chute by turning the food chute knob counterclockwise (see Figure 3A). -
Page 8: Install Charcoal Filter
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual . Install Charcoal Filter • Remove the filter cover plate from the back interior wall of the cooking chamber by removing the two black plastic knobs securing the cover plate (see Figure 4). " Remove the charcoal filter from the plastic... -
Page 9: Install Oil Pot
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Install oil pot. • Place the oil pot into the cooking chamber. Ensure that the taller of the two oil pot handles is towards the rear of the cook chamber and that both handles are fully lowered (see Figure 6). -
Page 10: Install Food Basket Clip
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Install the food basket clip. • Install the food basket clip onto the two mounting buttons located to the right of the door opening by aligning the holes in the clip over the buttons (see Figure 8). -
Page 11: Add Liquid Shortening
It is simpler and safer to add cool shortening to the oil pot than it is to remove hot shortening. Once the AUTOFRY has heated the shortening will expand. Only after this expansion has finished should the oil level be increased to the upper FILL level. -
Page 12: Power
3. That the front door is closed tightly and locked. 4. There is nothing blocking the air exhaust vent at the top of the AUTOFRY. 5. That the fire system pressure gauge is in the Green charged area. If the display reads Prb. check the following... -
Page 13: Let's Get Cooking
"FILL" line. Close the main door and press the ON button to re-start the AUTOFRY. The AUTOFRY will be ready at 340°F. It takes the AUTOFRY between 12- 20 minutes to heat the oil to 350°F. -
Page 14: Begin Cooking
Close the food chute and push the START button. Never overload the food entry chute. Over loading will result in splashing. The AUTOFRY can cook a maximum load of 1 1/2 Pounds (.68 kg) of french fries. Never place ice into the AUTOFRY. Ice will cause boil over. Never entry an order until the GREEN READY light is on. -
Page 15: During Cooking
? The wire food basket will return to the ready position, the O WAIT light will go out and the O READY light will illuminate. A quick "beeping" sound will occur to signal that the AUTOFRY is ready for the next order. AUTOFRY Shutoff Procedure Push OFF. -
Page 16: Additional Keypad Functions
The COUNT button tracks equipment cycles and this function can be utilized to record sales and control inventory. To use COUNT follow this procedure: The AUTOFRY has two count features. A re-settable count and a total cumulative count. To access these count features simply press the COUNT button once to view the re-settable count. -
Page 17: Stand-By Button
This may be useful if you have a single product menu or multi-product menu with identical cook times. Maximum Cook Time The AUTOFRY has maximum cook time of 15 minute and 59 seconds. MTI Form OP-0005 Rev. 002 7/98 E167654... - Page 18 AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Programming Cook Times The AUTOFRY offers you the ability to program the 1 - 6 keys for your most common cook times. It is a good idea to write down your six most commonly used cook times prior to programming the AUTOFRY.
-
Page 19: Programming Cook Times
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Programming Cook Times (cont.) Key # 3 1. Press the 2 button. • The display will read 003. 2. Press the 1 button to view or edit the pre-set cook time. • The display will read 3:00. - Page 20 AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Programming Cook Times (cont.) Key # 6 Press the 2 button. • The display will read 006. Press the 1 button to view or edit the pre-set cook time. • The display will read 6:00.
-
Page 21: Recommended Cleaning Schedule
Oil changing will vary widely depending on the use of the AUTOFRY. However, the use of a shortening monitor kit is the most accurate means of determining the status of the oil. -
Page 22: Daily Cleaning
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Daily Cleaning (cont.) Use extreme caution when cleaning around the fire system actuation cables and fusible link in the interior cabinet. Accidental discharge of the fire system could result, (see Figure 12). Clean all interior surfaces to bare metal. -
Page 23: Weekly Cleaning
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Weekly Cleaning Repeat daily cleaning. Remove the heater box assembly. Never immerse the heater box. Permanent damage and or electric shock will result. Use caution when cleaning around the temperature probes. Remove the oil pot. -
Page 24: Quarterly Cleaning
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Quarterly Cleaning and Maintenance Disconnect (un-plug) the AUTOFRY from main power Perform weekly cleaning routine. Remove the top panel and clean to bare metal the fire damper and fan section with a clean dry cloth or absorbent paper towels (see Figure 12A and 12B). -
Page 25: Charcoal Filter
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Charcoal Filter In order for the AUTOFRY to continue to perform as a VERY IMPORTANT ventless cooking appliance the charcoal filter medium or activated charcoal must be changed a minimum of every three months. This maintenance is required by your equipment warranty. -
Page 26: Fire System
Suppression System An inspection report / insurance certificate of installation will be forwarded to you by mail shortly after shipment of your AUTOFRY. This document must be filed in a safe place for future reference. An inspection of the fire suppression system must be performed every six months in order to comply with NFPA 96, NFPA 17A and UL 197. -
Page 27: Safety System Test
AUTOFRY Models MTI-5 Rev. 2 Operator's Manual Safety System Test (cont.) The AUTOFRY is equipped with an air-flow switch. To test this switch follow these instructions. 1. With all the filter components installed and the main door closed press the ON button at the keypad.
