Owner's Manual — Phoenix CAM Pro
Low amp draw, balanced airflow characteristics and maximum velocity of 2700 FPM are what propel the
Phoenix to rise above the competition.
The unique 1/3 horsepower design of the Phoenix Centrifugal Air Mover Pro, coupled with a two-speed
switch, allows the restoration technician to deliver the most airflow using the fewest amps.
Maximum amp draw on high speed is 2.8 amps. This drops to a mere 2.4 amps on low speed. It is now
possible to fit as many as four Phoenix Centrifugal Air Mover Pros onto a typical 15 amp household circuit.
The Phoenix CAM is lightweight and has an on-board duplex GFCI outlet, circuit breaker, and superior cord
management.
The Phoenix housing is durable, washable, and chemical resistant. It features multiple operating positions
allowing it to be angled up from horizontal to 45° and 90°.
The Phoenix Centrifugal Air Mover Pro
• 2-Speed 1/3 Horsepower Motor
2.8 Amps on High Speed
2.4 Amps on Low Speed
• Maximum Velocities 2700 FPM
• Balanced Exhaust Airflow
• Directional Airflow
Horizontal, 45° Angle, 90° Angle
• Durable, rugged, chemical resistant housing, fan
wheel, and controls design.
• Operator interface conveniently located for easy
access, featuring: power indicator lamp and large
three-position switch.
• Phoenix exclusive Pilot Light and Sealed Switch are
recessed to prevent damage.
• Ergonomic carry handle and power cord storage.
• Non-marking, anti-skid, rubber feet.
Specifications subject to change without notice.
Toll-Free 1-800-533-7533
4201 Lien Rd. • Madison, WI 53704
Installation, Operation & Service Instructions
Read and Save These Instructions
Phoenix Centrifugal Air Mover Pro
PN 4027550
1
www.UsePhoenix.com • sales@UsePhoenix.com
TS-480c 08/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phoenix CAM Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Therma-Stor Phoenix CAM Pro

  • Page 1: Introduction

    4201 Lien Rd. • Madison, WI 53704 Owner’s Manual — Phoenix CAM Pro Installation, Operation & Service Instructions Read and Save These Instructions Low amp draw, balanced airflow characteristics and maximum velocity of 2700 FPM are what propel the Phoenix to rise above the competition.

  • Page 2: Table Of Contents

    5. Operator Panel Features .........4 properly installed and secured. Do not operate the unit 5.1 12 Amp Circuit Breaker ........4 if the guards become damaged. Contact Therma-Stor for 5.2 Power Indication Lamp ........4 replacement parts. 5.3 3-Position Drying Selector Switch ......4 •...

  • Page 3: Specifications

    2 Specifications • Use only as described in this manual. 2 Specifications • Use only Manufacturer’s recommended attachments. • Use only Manufacturer’s recommended attachments. Contact Therma-Stor for proper repair instructions. Part No. 4027550 Contact Therma-Stor for proper repair instructions. Part No.

  • Page 4: Recommended Use

    3.2 Recommended Use 3.2 Recommended Use Recommended use(s) of on-board duplex GFCI are shown. Recommended use(s) of on-board duplex GFCI are shown. IMP0RTANT: Total amperage of the Centrifugal Air Mover Note: Standard 115 VAC electrical outlets. IMPORTANT: Total amperage of the Centrifugal Air Mover Note: Standard 115 VAC electrical outlets.

  • Page 5: Gfci Protection

    7 Replacement Parts and 5.4 GFCI Protection and the On-Board Duplex Outlet Optional Accessories The standard AC voltage outlet GFCI (Ground Fault Circuit Interrupter) promotes operator safety in wet applications. 4030989 motor, 60HZ GFCI devices trip when a fault to electrical ground is 4027572 blower wheel sensed.

  • Page 6: Wiring Diagram

    8 Wiring Diagram CAPACITOR (low) BLUE left hand pole (high) right hand pole Note: No hour meter on CAM or CAM Pro Note: Switch is Double Pole Throw Note: This is for CAM Pro motels built in U.S.A. Toll-Free 1-800-533-7533 www.UsePhoenix.com •...

  • Page 7: Warranty

    RMA you must present proof of purchase or (lease), by use of a warranty card, original sales receipt or other reasonable and reliable means. To obtain an RMA call Therma-Stor LLC at the above number and ask for the Therma-Stor LLC Service Department, which will then issue an RMA# and arrange for, at our option, either repair or replacement.
