  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION ....................1 System Requirements ..................1 Package List ...................... 1 SAFETY CAUTIONS ..................2 ADAPTER ......................2 Ethernet Interface ....................2 Buttons ......................3 LEDs........................3 UTILITY INSTALLATION ..................4 UTILITY SOFTWARE USAGE ................7 Main Tab ......................7 Privacy Tab ......................

  • Page 3: Introduction

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S I N T R O D U C T I O N The NI-707525 Homeplug Adapter utility program detects 200 Mbps PLC-Ethernet bridge devices in the Homeplug network, measures data rate performance, ensures security of the Homeplug network, and performs diagnostics.

  • Page 4: Safety Cautions

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S S A F E T Y C A U T I O N S This device is used for connection to the AC Homeplug.

  • Page 5: Buttons

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S 3.2 Buttons Figure 3-1 Side panel RST: Restore the factory defaults.

  • Page 6: Utility Installation

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S CODED PHY RATE<30：RED 30<CODED PHY RATE<50：YELLOW CODED PHY RATE>50：GREEN...
  • Page 7 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S The page of utility installation is similar to the one shown in Figure 4-1.
  • Page 8 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Figure 4-2 Select installation folder...

  • Page 9: Utility Software Usage

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Figure 4-3 Installation complete Click Close to complete the installation.
  • Page 10 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Figure 5-1: Main tab information The lower panel displays all the HomePlug remote devices, which are discovered in the current logical network.
  • Page 11 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Password By default, this column is blank.
  • Page 12 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S This button is used to add a remote device to the existing network by entering the device password of the device.

  • Page 13: Privacy Tab

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Scan This button is used to perform an immediate search for HomePlug devices connected to the Homeplug network.

  • Page 14: Diagnostics Tab

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Note: If the network name changes to anything other than HomePlug, the network type in the main screen is displayed as Private.
  • Page 15 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S HomePlug chipset manufacturer name (Turbo Only devices) ...

  • Page 16: About Tab

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Device Last known rate ...

  • Page 17: Nmk Pushbutton Usage

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Preferences The lower part of the panel displays options for turning the autoscan function on or off.

  • Page 18: Joining A Network

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S A and B are not part of AVLN A and B are not part of AVLN A and B want to form an AVLN...

  • Page 19: Leaving A Network

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S A and B form an AVLN A and B form an AVLN C wants to join the AVLN...

  • Page 20: Appendix A Specifications

    Compliant with HomePlug AV 1.0 Co-existing with existing HomePlug 1.0 System Support Windows 98SE, Windows 2000, Windows ME, Windows XP 32/64 bit and Windows Vista 32/ 64bit PLC Rate 200 Mbps Modulation Band 2MHz~30MHz Modulation Schemes Support QAM 1024/256/64/16/8, QPSK, BPSK and ROBO Encryption...
  • Page 21 N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S LED Indicators Power Ethernet: Ethernet link and activity...

  • Page 22: Appendix B Acronyms And Abbreviations

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Appendix B Acronyms and Abbreviations AVLN AV In-home Logical Network, the AVLAN is the set of STAs...

  • Page 23: Appendix C About Qos

    N I - 7 0 7 5 2 5 H O M E P L U G A D A P T E R S TA R T E R K I T 2 0 0 M B P S Appendix C About QoS PLC 200AV allows 4 levels of Channel Access Priority (CAP (0 –...
