USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR ELECTRICAL
Dear User,
we are sincerely grateful to you for purchasing one of our products.
We are sure that the appliance modern, functional and easy to use, built with the finest materials
and components will satisfy all your needs.
We would ask that you read the instructions within this booklet very carefully so as to enable you
to obtain quality results from the outsets.
The appliance must be installed only by a qualified electrician in compliance with the
instructions provided. The manufacturer declines all responsability for improper installation.
MODELS: TRV602IX - TRV602WH
The manufacturer is not responsible for any transcription errors or misprints contained in this handbook and,
furthermore, reserves the right to make any modification on the products, which might be deemed
necessary or usefull, this being in the user's interest, without altering their basic operating or safety
features. This cook top was designed to be used exclusively as a cooking appliance: any other
use (such as heating rooms) is to be considered improper and dangerous.
BUILT-IN HOT PLATES
COD.: 120349EUR - 13.04.2011
Advertisement
Table of Contents
Related Manuals for Trieste TRV602IX
Summary of Contents for Trieste TRV602IX
- Page 1 The appliance must be installed only by a qualified electrician in compliance with the instructions provided. The manufacturer declines all responsability for improper installation. MODELS: TRV602IX - TRV602WH The manufacturer is not responsible for any transcription errors or misprints contained in this handbook and, furthermore, reserves the right to make any modification on the products, which might be deemed necessary or usefull, this being in the user’s interest, without altering their basic operating or safety...
- Page 2 DESCRIPTION OF THE CERAMIC COOKTOP 1 Radiant electric heating element Ø 145 mm 1200 W (even if “Hi-light”) 2 Radiant electric heating element Ø 180 mm 1700 W (even if “Hi-light”) 9 Switch for plate n. 1 front 14 Switch for plate n. 2 bach...
- Page 3 1) CERAMIC COOKTOP Connection of electric heating elements Heating elements are controlled by energy The hot plates are equipped with 2 radiant heating regulators with 12 positions that permit to obtain a elements with different powers and diameters. big range of different temperatures. In Scheme 1, Cooking zones are aesily identifiables thanks to the by way of information, we give instructions to obtain circles (see illustration in description) on the top;...
- Page 4 SCHEME 1 Power and dimensions of the Position for regulation Possible cooking zones of the knobs cookings Zone Diameter Heating Power Energy Commutators n° in mm. elements regulators To melt butter, Radiant 1200 chocolate (even if else. “Hi-light”) heat small Radiant 1700 1 - 4...
- Page 5 WARNINGS: - The machine must not be used by people (including children) with impaired mental or for a correct use, please look at fig. 2 and remind: physical capacities, or without experience of - switch on the electricity only after having placed using electrical devices, unless supervised or the pot on the cooking zone.
- Page 6 CLEANING - Pay attention to not let fall sugar or element with Before any cleaning operation, disconnect the appliance from the electric circuit. sugar. In this case turn the switch off and clean the surface with hot water and the razor blade 2) CERAMIC COOKTOP scraper.
-
Page 7: Installation
INSTALLATION TECHNICAL INSTRUCTIONS - Stick the seal to the hotplate uniformly, pressing FOR THE INSTALLER it with fingers. - Take the protective paper strip of the seal off, Installation, transformations and maintenances place the hotplate in the opening made in the below listed, may only be carried out by a table top, and lock it with the special screws “F”... - Page 8 INSTALLATION 5) ELECTRICAL CONNECTION appliance, with a minimum nose between the contacts of 3 mm. - Keep in mind that the “earth” cable does not have IMPORTANT: the appliance must be to be interrupted by the switch. installed following the manufacturer's - In an alternative solution the electrical connection instructions.
-
Page 9: Maintenance
MAINTENANCE Before doing any action, disconnect the In case of substitution of the input cable, the appliance from the input power. installer must keep the “earth” conductor longer than “live” ones, and must respect the cautions in 6) COMPONENTS SUBSTITUTION paragraph “electrical connection”. -
Page 10: Technical Data
TECHNICAL DATA 2 HEATING ELEMENTS Voltage 230 - 240 V~ Frequency 50/60 Hz Tot. Rating 2900 W... -
Page 11: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS This appliance, before leaving the factory, has been carefully tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
