ODX402 / ODX502 / ODX602
COFDM Digital Video Diversity
Receiver
User's Guide & Operating Manual
REV. B
02 Feb 2009
http://www.avalonrf.com/
Avalon RF, Inc. • 344 Coogan Way • El Cajon, CA 92020
Phone: (619) 401-1969 • Fax: (619) 401-1971 • Email:
sales@avalonrf.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODX402 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avalon RF ODX402

  • Page 1 ODX402 / ODX502 / ODX602 COFDM Digital Video Diversity Receiver User's Guide & Operating Manual REV. B 02 Feb 2009 http://www.avalonrf.com/ Avalon RF, Inc. • 344 Coogan Way • El Cajon, CA 92020 Phone: (619) 401-1969 • Fax: (619) 401-1971 • Email: sales@avalonrf.com...
  • Page 2: Table Of Contents

    AVALON RF, INC. Page ii ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Table of Contents General ....................1 Figure A – Front Panel .................2 Figure B – Rear Panel................3 Specifications..................4 Frequency Range ................4 Power Input ..................4 Figure C – Power Input ..............4 Antenna Inputs ..................5...
  • Page 3: General

    Features like OSD menu, two video outputs & front or rear antenna inputs enhance suitability of the ODX602 to various applications. The ODX402 is a VHF/ UHF receiver, the ODX502 is a L-band receiver and the ODX602 is a S-band receiver.
  • Page 4 AVALON RF, INC. Page 2 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Figure A – Front Panel ODX402/ODX502/ODX602 Controls, Indicators and Connectors 1 - Antenna 1 Input 2 - Power Indicator LED 3 - Channel Select Switches...
  • Page 5 AVALON RF, INC. Page 3 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Figure B – Rear Panel ODX402/ODX502/ODX602 Controls and Connectors 1 Rear Antenna inputs 2 Audio Output Connector 3 Power Connector 4 Video Outputs 5 Data Output/Program...
  • Page 6: Specifications

    E.g 4 is UHF, 5 is L-band & so on. The ‘standard’ frequency ranges for the various models are as follows: ODX402: UHF receiver with a tuning range of 170-230 MHz or 470MHz-862MHz. ODX502: L-band receiver with a tuning range of 900 MHz-1200 MHz or 1.2GHz-1.8GHz.
  • Page 7: Antenna Inputs

    AVALON RF, INC. Page 5 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Antenna Inputs, total of 2 (Circle 1 on front panel). The standard ODX602 has 2 SMA (f) inputs on the front panel. The – R option installs the antenna options on the rear panel. This is most convenient in rack mount or OEM installations.
  • Page 8: Data/Program Output

    AVALON RF, INC. Page 6 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Program/ Data output (Circle 5 on rear panel). The Data/ Program connector is a LEMO type ECG.0B.307.CLN or equivalent: The connector pin-out is: Pin 1 – Ground Pin 2 –...
  • Page 9: Wdl Interface

    AVALON RF, INC. Page 7 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual The WDL connector is a 6 pin Hirose male connector. The pinout is as shown below. The dc power to this module is independent & may be turned on/ off without affecting the operation of the main unit.
  • Page 10: Size

    2.11.1 Rack Mounting (Option R2) A special rack mounting kit is available from Avalon RF for mounting 2 ODX602 in a 1U high rack. For rack mount applications, it may be beneficial to have rear connector mounting. Please call for pricing &...
  • Page 11 AVALON RF, INC. Page 9 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual 1.7” (44 mm) 6” 6.25” (158 mm) 6” (150 mm) Figure G – ODX602 Mechanical Specifications - Inches [mm]...
  • Page 12 AVALON RF, INC. Page 10 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Figure H – ODX602 Mounting Holes...
  • Page 13: Environmental Conditions

    AVALON RF, INC. Page 11 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual 2.10 Environmental Conditions. The ODX602 is designed to meet the following environmental conditions: Operating temperature -4° to 122° F (-20° to 50° C) Storage temperature -13°...
  • Page 14: Operating Instructions

    AVALON RF, INC. Page 12 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual Operating Instructions Human Interface. 3.1.1 Front Panel Channel Select Switches (Circle 3 on figure A) The ODX602 has a provision of 16 channels. The frequencies associated with a channel have been factory programmed but can be changed by the user through the serial RS232 interface.
  • Page 15: Power On/Off

    AVALON RF, INC. Page 13 of 15 ODX402/ ODX502/ OODX602 User’s Guide & Operating Manual The power on/off switch controls power to the unit. It is an electronic switch & must be kept pressed for 3 sec. Operating the ODX602.
  • Page 16 The ODX602 receiver has excellent sensitivity allowing use of small low profile antennas. High antenna gain will saturate the front end of the receiver & result in distortion of the received signal thereby causing errors in reception. Please consult Avalon RF for choice & use of antennas.
  • Page 17: Ordering Information

    ODX602 – Basic Receiver Every ODX602 comes with the standard features and following accessories: One ODX402 or ODX502 or ODX602 in a ZIPLOCK ESD bag. One BX002U 12V low noise regulated Universal AC adapter for worldwide use (except for country specific plug).
