WinFast WS1000 Workstation
Copyright
Copyright © Leadtek Corporation, 2012. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from
Leadtek.
Trademark
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
®
WinFast
is a trademark of Leadtek
®
Intel
is a trademark of Intel
®
®
AMI
, AMIBIOS
®
Microsoft
, Windows
®
Aspeed
is a trademark of Aspeed Technology Inc.
Notice
Information contained in this document is furnished by Leadtek and has been
reviewed for accuracy and reliability prior to printing. Leadtek assumes no
liability whatsoever, and disclaims any express or implied warranty, relating to
sale and/or use of Leadtek products including liability or warranties relating to
fitness for a particular purpose or merchantability. Leadtek retains the right to
make changes to product descriptions and/or specifications at any time, without
notice. In no event will Leadtek be held liable for any direct or indirect, incidental
or consequential damage, loss of use, loss of data or other malady resulting from
errors or inaccuracies of information contained in this document.
®
Corporation.
and combinations thereof are trademarks of AMI Technologies.
®
are trademarks of Microsoft Corporation.
Version 1.0

Advertisement

Table of Contents
loading

Summary of Contents for Leadtek WinFast WS1000 Workstation

  • Page 1 In no event will Leadtek be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from...

  • Page 2: About This Guide

    About this guide This user guide contains the information you need when installing and configuring the motherboard. How this guide is organized This guide contains the following parts: Chapter1: Instruction This chapter describes the features of the motherboard and the new technology it supports.

  • Page 3: Table Of Contents

    Contents Before you begin… ................4 1.1 - Congratulations ..................... 5 1.2 - Hardware Specifications ................5 Chapter 2: Board Installation .............. 8 2.1 - Board Image ....................9 2.2 - Block Diagram ..................... 10 2.3 - Board Parts, Jumpers and Connectors............11 2.4 - Installing the Processor ................

  • Page 4: Before You Begin

    Before you begin… Check the box contents! Item Name 1 x WinFast WS1000 Quick Installation Guide 1 x WinFast WS1000 Driver CD 1 x WinFast WS1000 Power Cord IMPORTANT NOTE: If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process.

  • Page 5: Congratulations

    Chapter 1: Instruction 1.1 - Congratulations You have purchased the powerful WinFast WS1000 workstation, based on the ® Intel Patsburg-A (PCH). The WinFast WS1000 is designed to support dual ® Intel Xeon E5-2600 (LGA2011) Series Processors and up to 512GB LR-DIMM (800, 1066 and 1333MHz), 256GB R-DIMM (800, 1066, 1333 and 1600MHz) DDR3 ®...
  • Page 6 (1) PCI-E x4 slot ( x4 link, slot #6) (1) PCI-E x16 slot ( x16 link or x8 link, slot #5) Expansion (1) PCI-E x8 slot ( x0 link or x8 link, slot #4) PCI-E Slots (1) PCI-E x16 slot ( x16 link or x8 link, slot #3) (1) PCI-E x8 slot ( x0 link or x8 link, slot #2) (1) PCI-E x8 slot (w/ x4 link PCH), slot #1 Port Q'ty...
  • Page 7 Remember to visit Leadtek’s Website at http://www.leadtek.com. There you can find information on all products with FAQs, online manuals and BIOS upgrades and more.

  • Page 8: Chapter 2: Board Installation

    Chapter 2: Board Installation You are now ready to install your motherboard. How to install our products right… the first time The first thing you should do is reading this user’s manual. It contains important information that will make configuration and setup much easier. Here are some precautions you should take when installing your motherboard: (1) Ground yourself properly before removing your motherboard from the antistatic bag.

  • Page 9: Board Image

    2.1 - Board Image WinFast WS1000 This diagram is representative of the latest motherboard revision available at the time of publishing. The board you receive may not look exactly like the above diagram.

  • Page 10: Block Diagram

    2.2 - Block Diagram WinFast WS1000 Block Diagram...

  • Page 11: Board Parts, Jumpers And Connectors

    2.3 - Board Parts, Jumpers and Connectors Important Notes to the User • " " indicates the location of "Pin 1". ▲ • The diagram is representative of the latest board revision available at the time of publishing. The board you received may not look exactly like this diagram. Jumper Legend OPEN - Jumper OFF Without jumper cover...
  • Page 12 Jumpers & Connectors Jumper/Connector Function SYS FAN1~5 4-pin Fan Power Connector CPU0~1FAN 4-pin CPU0/CPU1 Fan Power Connector FAN_HDR1 System Fan Header SPDIF Coaxial-Input(upper) / Optical-Output(lower) J176 Front Panel Audio J177/J178 1394 Pin Header SGPIO1 SATA 0~5 SGPIO Header SGPIO2 SAS 0~3 SGPIO Header SGPIO3 SAS 4~7 SGPIO Header CD_HD1...
  • Page 13 Jumper Placement SYS_FAN1 SYS_FAN2 CPU1_FAN CPU0_FAN SYS_FAN5 SYS_FAN4 SYS_FAN3 CD_HD1 A_USB1 FAN_HDR1...
  • Page 14 SYS FAN1~5/CPU0~1FAN: 4-Pin FAN Connector Signal P12V FAN_TACH FAN_PWM NOTE: Use this header to connect the cooling fan to your motherboard to keep the system stable and reliable. FAN_HDR1: FAN Connector for Barebone Signal Signal TACH1 TACH6 TACH2 TACH7 TACH3 TACH8 TACH4 TACH9...
  • Page 15 PSMI1 FPIO1 USB2 J176 USB1...
  • Page 16 PSMI1: PSMI Connector Signal SMB_CLK SMB_DAT VCC3 Alert# FPIO_1: Front Panel Header Signal Signal PWRLED+ FPPW (VCC3_AUX) PWRLED- HD_LED+ HWM_FAULT_LED- HD_LED- SYS_FAULT_LED- PWR_SW# LAN1_ACTIVE_LED+ LAN1_ACTIVE_LED- RST_SW# INTRUDER# FPIO_TEMP_IN LAN2_ACTIVE_LED+ NMI_SW# LAN2_ACTIVE_LED- USB1/USB2: Front USB Header Signal Signal USB DATA1- USB DATA2- USBDATA1+ USB DATA2+ J176: Front Panel Audio...
  • Page 17 3PHD_3 3PHD_2 3PHD_1 2PHD_1 KEY_1 J177/J178...
  • Page 18 J177: 1394 Pin Header Signal Signal XTP_A_P_0 XTP_A_N_0 XTP_B_P_0 XTP_B_N_0 VCC12_1394 VCC12_1394 J178: 1394 Pin Header Signal Signal XTP_A_P_1 XTP_A_N_1 XTP_B_P_1 XTP_B_N_1 VCC12_1394 VCC12_1394...
  • Page 19 2PHD_1: INTRUDER Header Signal PCH_INTRUDER_N 3PHD_1 / 3PHD_2: CPU XDP bypass Jumper Signal CPU0_TDO XDP_TDO CPU1_TDO Default: Only CPU0 3PHD_1 3PHD_2 3PHD_3 Only CPU0 Installed Only CPU1 Installed Both CPU Installed 3PHD_3: CPU XDP bypass Jumper Signal CPU0_TDO CPU1_TDI Default: Only CPU0 3PHD_1 3PHD_2 3PHD_3...
  • Page 20 3PHD_8 3PHD_5 3PHD_4...
  • Page 21 3PHD_4: ME RECOVERY MODE Jumper Signal FM_ME_RCVR_N 1-2: Normal Mode (Default) 2-3: ME Recovery Mode 3PHD_5: BIOS RECOVERY Jumper BIOS_RCVR_BOOT_N Signal 1-2: Normal Mode (Default) 2-3: BIOS Recovery mode 3PHD_8: SECURITY OVERRIDE Jumper MFG_MODE_N Signal 1-2: Normal Mode (Default) 2-3: Security Override...
  • Page 22 SGPIO1 SGPIO2 SGPIO3 4PHD_11...
  • Page 23 4PHD_11: BUZZER disable Jumper Signal VCC5 BUZ_1 BUZ_2 1-2: Normal Mode (Default) 2-3: Disable PC Beep 1-4: Use the external speaker SGPIO1/2/3: SATA SGPIO Header Signal Signal SDATA IN SDATA OUT- SLOAD SCLOCK P3V3_AUX HD_ERROR_LED NOTE: SGPIO1 is responsible for SATA port 0~5 SGPIO2 is responsible for SAS 0~3 SGPIO3 is responsible for SAS 4~7 DBG_HD1: WinFast Module Header...
  • Page 24 COM1 SATA0 STBY_PW_LED1 SATA1 SATA2 SATA3 SATA4 SATA5 PWR/RST/Clear Button These connectors have no functions. Do not connect hard drives to them.
  • Page 25 SATA0/SATA1/SATA2/SATA3/SATA4/SATA5: SATA Connector Connects to the Serial ATA ready drives via the Serial ATA cable. SATA RX DP SATA RX DN SATA0/SATA1: Support SATA3.0 SATA2/SATA3/SATA4/SATA5: SATA TX DN Support SATA2.0 SATA TX DP PIN7 PIN1 SYTB_PW_LED1: Stby_PW_LED State Color Description Green System standby power identified System standby power not identified...
  • Page 26 CLEAR BUTTON : Clear CMOS set You can reset the CMOS settings by using this button if you have forgotten your system/setup password or need to clear system BIOS setting. 1.Power off system and disconnect power Normal(Default) connectors from the motherboard 2.Press the button (Clear CMOS) 3.Reconnect power &...

  • Page 27: Installing The Processor

    Your brand new WinFast WS1000 motherboard supports both Intel “Sandy Bridge-EP and Ivy Bridge series” processors. NOTE: Leadtek is not liable for damage as a result of operating an unsupported configuration. Locate the CPU socket (LGA 2011) on the motherboard: To install a CPU:...
  • Page 28 Please refer to the image. Position the CPU over the socket, ensuring that the gold triangle is on the bottom-right corner of the socket, and then fit the socket alignment keys into the CPU notches. Close the load plate, ensuring that the front edge of the load plate slides under the retention lever.
  • Page 29 Cautions: The CPU fits in only one correct orientation. Do not force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU.

  • Page 30: Installing The Heatsink

    2.5 - Installing the Heatsink Heatsink Installation Caution: After installing the processor, you should proceed to install the heat sink. The CPU heat sink will ensure that the processor do not overheat and continue to operate at maximum performance for as long as you own them. The overheated processor is dangerous to the motherboard.

  • Page 31: Thermal Interface Material

    2.6 - Thermal Interface Material There are two types of thermal interface materials designed for use with the processors. The most common material comes as a small pad attached to the heat sink at the time of purchase. There should be a protective cover over the material.

  • Page 32: Installing The Memory

    2.7 - Installing the Memory Overview The motherboard comes with four Double Data Rate 3（DDR3）Dual Inline Memory Modules （DIMM）sockets. The figure illustrates the location of the DDR3 DIMM socket. • Sandy Bridge-EP/EX processor supports 4 DDR3 channels • Unbuffered DDR3 and registered DDR3 DIMMs •...
  • Page 33 Recommended Memory Population Table To achieve the best performance, Leadtek strongly recommend memory installation configuration as listed below: Single CPU Dual CPU Installed installed (CPU0 only) (CPU0 and CPU1) Quantity of memory installed √ √ √ √ √ √ √...
  • Page 34 ® ® Intel Xeon processor E5-2600/4600 product families UDIMM Support Ranks Per DIMM & 1.35V 1.50V Memory Capacity per DIMM Data Width 1DPC 2DPC 1DPC 2DPC 1066, 1066, SRx8 Non-ECC 1 GB 1333 1333 1066, 1066, DRx8 Non-ECC 1333 1333 1066, 1066, SRx16 Non-ECC...
  • Page 35 ® ® Intel Xeon processor E5-2600/4600 product families RDIMM Support Ranks 1.35V 1.50V Memory Capacity per DIMM & DIMM 1DPC 2DPC 1DPC 2DPC Data Width 1066, 1066, 1066, 1066, SRx8 1333, 1333, 1333 1333 1600 1600 1066, 1066, 1066, 1066, 1333, 1333, DRx8...

  • Page 36: Memory Installation Procedure

    Memory Installation Procedure Caution: Ensure to unplug the power supply before adding or removing DIMMs, or other system components, Failure to do so may cause severe damage to both the motherboard and the components. Follow these instructions to install memory modules into the WinFast WS1000. Unlock a DIMM socket by Press the retaining clip outwardly in the following illustration.

  • Page 37: Attaching Drive Cables

    2.8 - Attaching Drive Cables WinFast WS1000 is equipped with Serial ATA (SATA) channels. Connections for the drives are very simple. There is no need to set Master/Slave jumpers on SATA drives. distributor. Attaching Serial ATA Cables The following illustrates how to make a SATA Cable connection. If you are in need of SATA/SAS cables or power adapters please contact your local sales representative.

  • Page 38: Installing Add-In Cards

    2.9 - Installing Add-In Cards Before installing add-in cards, it’s helpful to know if they are fully compatible with your motherboard. For this reason, we’ve provided the diagrams below, showing the slots that may appear on your motherboard. PCI-E Gen3 x 16 slot PCI-E Gen3 x 8 slot PCI-E Gen3 x 4 slot Simply find the appropriate slot for your add-in card and insert the card firmly.

  • Page 39: Connecting External Devices

    2.10 - Connecting External Devices Your motherboard supports a number of different interfaces through connecting peripherals. See the following diagrams for the details. NOTE: Peripheral devices can be plugged straight into any of these ports but software may be required to complete the installation.
  • Page 40 Onboard LAN LED Color Definition onboard Ethernet ports have green and amber LEDs to indicate LAN status. The chart below illustrates the different LED states. 10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED (Link/Activity) (Speed) Link Green 10 Mbps Active Blinking Green Link...

  • Page 41: Installing The Power Supply

    2.11- Installing the Power Supply There are four (4) power connectors on your WinFast WS1000. It is required that you have an EPS12V power supply has one 24-pin and two 8-pin connectors. PW1: 24-Pin 12V main PWR Connector Signal Signal +3.3V +3.3V +3.3V...

  • Page 42: Finishing Up

    NOTE: YOU MUST unplug the power supply before plugging the power cables to motherboard connectors. 2.12 - Finishing Up Congratulations on making it this far! You’re finished setting up the hardware aspects of your computer. Before closing up your chassis, make sure that all cables and wires are connected properly, especially power cables and most importantly jumpers.

  • Page 43: Chapter 3: Bios Setup

    Chapter 3: BIOS Setup 3.1 - About the BIOS The BIOS is the basic input/output system, the firmware on the motherboard that enables your hardware to interface with your software. The BIOS determines what a computer can do without accessing programs from a disk. The BIOS contains all the code required to control the keyboard, display screen, disk drives, serial communications, and a number of miscellaneous functions.

  • Page 44: Getting Help

    In particular, do not change settings in the Chipset section unless you are absolutely sure of what you are doing. The Chipset defaults have been carefully chosen either by Leadtek or your system manufacturer for best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable.

  • Page 45: Bios Main Menu

    3.5 - BIOS Main Menu Manual Bar General help Specification Sub-menu items Configuration fields Navigation keys BIOS Information Displays BIOS related information. Memory Information Displays total memory size. System Date (Day dd/mm/yyyy) System Time (hh:mm:ss) Allow user to set system time and date. The Time is displayed in 24 hours format.
  • Page 46 3.5.1 Manual Bars For changing the basic system configuration Main Advanced For changing the advanced system settings Chipset For customize the Intel chipset function Boot For changing the system boot configuration Security For setting the Supervisor and User passwords Server Mgmt For changing the server management Event Logs For record the system Event Logs...

  • Page 47: Bios Advanced Menu

    3.6 - BIOS Advanced Menu This section facilitates configuring advanced BIOS options for your system. PCI Subsystem Settings PCI,PCI-X and PCI Express Configuration. ACPI Settings Selection for Advanced ACPI Configuration. RTC Wake Settings Selection for RTC Wake Configuration. WHEA Configuration General WHEA Configuration Setting.
  • Page 48 SAS Configuration SAS Devices Configuration. Info Report Configuration Info report configure USB Configuration Configure the USB support Watchdog Timer Configuration Configure watchdog Timer H/W Monitor Configuration IPMI configuration including server monitoring and event log Super IO Configuration Configures Super IO Serial Port Console Redirection Redirect Serial Port Console...
  • Page 49 3.6.1 - PCI Setting PCI Option ROM Handling PCI ROM Priority In case of multiple option ROMs (Legacy and EFI compatible)， specifies what PCI option ROM to launch. [EFI Compatible ROM] / [Legacy ROM] Default is [EFI Compatible ROM] PCI 64bit Resources Handling Above 4G Decoding Enables or disables 64 bit capable devices to be decoded in above 4G address space(only if system supports 64 bit PCI decoding.
  • Page 50 3.6.2 - ACPI Setting Enable Hibernation Enables or disables System ability to Hibernate (OS/S4 sleep state). This option may be not effective with some OS. [Disabled] / [Enabled] Default is [Enabled] ACPI Sleep State Select the highest ACPI sleep state the system will enter when the suspend button is pressed.
  • Page 51 3.6.3 – Wake system Configuration Wake system with Fixed Time Enable or disable system wake on alarm event. When enabled, system will wake on the hr :: min :: sec specified [Disabled] / [Enabled] Default is [Disabled] Wake system with Dynamic Time Enable or disable system wake on alarm event.
  • Page 52 3.6.4 - WHEA Support WHEA Support Enables or disables Windows Hardware Error Architecture. [Disabled] / [Enabled] Default is [Enabled]...
  • Page 53 3.6.5 - CPU Configuration This section allows you to fine-tune the processor options. Hyper- threading This option enable for Windows XP and Linux (OS optimized for Hyper- threading Technology. And Disabled for other (OS not optimized for Hyper-threading Technology). [Disabled] / [Enabled] Default is [Enabled] Active Processor Core [All]/[1]/[2]/[3]/[4]/[5]/[6]/[7]...
  • Page 54 Adjacent Cache Line Prefetch [Disabled] / [Enabled] Default is [Enabled] DCU Streamer Prefetcher Enable prefetch of next L1 Data line based upon multiple loads in same cache line. [Disabled] / [Enabled] Default is [Enabled] DCU IP Prefetcher Enable prefetch of next L1 line based upon sequential load history. [Disabled] / [Enabled] Default is [Enabled] Intel Virtualization Technology...
  • Page 55 3.6.5.1 – Socket0 CPU Configuration Read only...
  • Page 56 3.6.5.2 – Socket1 CPU Configuration Read Only...
  • Page 57 3.6.5.3 - CPU Power Management Configuration Power Technology Enable the power management features. [Disable] / [Energy Efficient] / [Custom] Default is [Energy Efficient] Energy Performance Optimize between Performance and power savings. Windows 2008 and later OSes overrides this value according to its power plan. [Performance] / [Balanced Performance] / [Balanced Energy] Default is [Balanced Performance] Factory Long Duration...
  • Page 58 Recommended short duration power limit Read only. Short duration power limit Short duration power limit in Watts. 3.6.6 – Runtime Error Logging Configuration Runtime Error Logging Support Enable/Disable Runtime Error Logging Support. [Enabled] / [Disabled] Default is [Disabled]...
  • Page 59 3.6.7 - SATA Configuration External SATA port0/1/2/3/4/5 Enable/Disable SATA Ports Hot Plug Support. [Enabled] / [Disabled] Default is [Disabled]...
  • Page 60 SATA Mode Select SATA Mode. [IDE Mode] / [AHCI Mode] / [RAID Mode] / [Disabled] Default is [AHCI Mode] Agressive Link Power Management [Enabled] / [Disabled] Default is [Enabled] Port1/2/3/4/5 Hot Plug [Enabled] / [Disabled] Default is [Disabled] External SATA Port 0/1/2/3/4/5 [Enabled] / [Disabled] Default is [Disabled] Staggered Spin-up...
  • Page 61 3.6.8 - SAS Configuration Read only.
  • Page 62 3.6.9 Info Report Configuration Post Report Post report support enabled/disabled [Enabled] / [Disabled] Default is [Enabled] Delay Time Post report support enabled/disabled [0]/[1]/[2]/[3]/[4]/[5]/[6]/[7]/[8]/[9]/[10]/[Until press ESC] Default is [2] Summary Screen [Enabled] / [Disabled] Default is [Disabled]...
  • Page 63 3.6.10 USB Configuration Legacy USB Support Enables legacy USB support, Auto option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications. [Disabled] / [Enabled] / [Auto] Default is [Enabled] EHCI Hand-off [Disabled] / [Enabled] Default is [Disabled]...
  • Page 64 3.6.11– Watchdog Timer Configuration Watchdog mode [Disable] / [Post] / [OS] / [Power ON] Default is [Disabled]...
  • Page 65 3.6.12 – Hardware Health Configuration...
  • Page 66 Auto Fan [Disabled] / [Enabled] Default is [Enabled] The disable meaning is FAN Speed running FULL ON Duty Cycle [30% Duty Cycle] / [45% Duty Cycle] / [60% Duty Cycle] Default is [30% Duty Cycle] Beep and warning LED [Enabled] / [Disabled] Default is [Enabled] *The Fan data need set Auto Fan to [Enabled]’...
  • Page 67 3.6.13 Super I/O Configuration Super IO Chip Read only.
  • Page 68 3.6.13.1 Serial port submenu Serial Port 0 Configuration Serial Port Enable or Disable Serial Port (COM) [Enabled] / [Disabled] Default is [Enabled] Device Settings Read only. It can not be modified in user mode. Change/Settings Select an optimal setting for super I/O device. [Auto] / [I/O=3F8h;IRQ=4] / [ I/O=3F8h;IRQ=3,4,5,6,7,8,9,10,11,12]/ [ I/O=2F8h;IRQ=3,4,5,6,7,8,9,10,11,12] / [ I/O=3E8h;IRQ=3,4,5,6,7,8,9,10,11,12]/ [ I/O=2E8h;IRQ=3,4,5,6,7,8,9,10,11,12]...
  • Page 69 3.6.14 Serial Port Console Redirection Console Redirection Console redirection enable or disable. [Disabled] / [Enabled] Default is [Disabled] Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Console redirection enable or disable. [Disabled] / [Enabled] Default is [Disabled] Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data.
  • Page 70 3.6.14.1 Console Redirection Submenu Terminal Type Emulation: ANSI: Extended ASCII charset. VT100: ASCII charset. VT100+: Extends VT100 to support color function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. [VT100] / [VT100+] / [VT-UTF8] / [ANSI] Default is [VT100+] Bits per second Selects serial port transmission speed.
  • Page 71 Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit.1 communication with slow devices may require more than 1. [1] / [2] Default is [1] Flow Control Flow control can prevent data loss from buffer overflow.
  • Page 72 Redirection After BIOS POST The settings specify if bootloader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is always enable means Legacy. [Always enable] / [Bootloader] Default is [Always enable] 3.6.14.2 Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Settings Out-of Band Mgmt Port COM0...
  • Page 73 Bits per Second Select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. [115200] / [9600] / [19200] / [57600] Default is [115200] Flow Control Flow Control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a ‘stop’...

  • Page 74: Chipset Menu

    3.7 - Chipset Menu North Bridge North Bridge Parameters. South Bridge South Bridge Parameters. Onboard Device Configuration Configure Onboard Device ME Subsystem ME Subsystem Configuration...
  • Page 75 3.7.1 – North Bridge Chipset Configuration Sub- Menu Total Memory / Current Memory Mode / Current Memory Speed / Mirroring / Sparing Read only. Memory Mode Select the mode for memory initialization. [Independent] / [Mirroring] / [Lock Step] / [Sparing] Default is [Independent] Numa Enable or disable Non uniform Memory Access (NUMA).
  • Page 76 DDR Speed Force DDR Speed. [Auto] / [Force DDR3 800] / [Force DDR3 1066] / [Force DDR3 1333] / [Force DDR3 1600] / [Force DDR3 1866] Default is [Auto] Channel Interleaving Select different Channel Interleaving setting. [Auto] / [1 Way] / [2 Way] / [3 Way] / [4 Way] Default is [Auto] Rank Interleaving Select different rank Interleaving setting.
  • Page 77 3.7.1.1 IOH Configuration Submenu ® Intel I/OAT ® Enable/Disable Intel I/O Acceleration Technology (I/OAT). [Disabled] / [Enabled] Default is [Disabled] VGA Priority Decide the priority between onboard and its offboard video device found. [Offboard] / [Onboard] Default is [Offboard] Target VGA Read only.
  • Page 78 ® 3.7.1.1.1 Intel VT for Directed I/O Configuration Submenu ® Intel VT-d ® Enable/Disable Intel Virtualization Technology Directed I/O. [Disabled] / [Enabled] Default is [Disabled] ® NOTE: The following items will appear when Intel VT-d is set to [Enabled]. Interrupt Remapping Enable/Disable VT-d Engine Interrupt Remapping Support.
  • Page 79 Pass-through DMA Enable/Disable VT-d Engine Pass through DMA support. [Enabled] / [Disabled] Default is [Enabled] 3.7.1.2 QPI Configuration Submenu QPI Link Speed Mode Select the QPI link speed as either the Fast Mode or the Slow Mode. [Fast] / [Slow] Default is [Fast] QPI Link Frequency Select Select the QPI Link Frequency.
  • Page 80 QPI LinkOp Enable/Disable QPI LinkOp. [Enabled] / [Disabled] Default is [Disabled] QPI Link1 Enable/Disable QPI Link1. [Enabled] / [Disabled] Default is [Enabled]...
  • Page 81 3.7.1.3 DIMM Information Submenu Read only.
  • Page 82 3.7.2 – South Bridge Configuration Sub-Menu PCH Information Name / Stepping Only read SMBus Controller [Disabled] / [Enabled] Default is [Enabled] Periodic SMI [Disabled] / [Enabled] Default is [Enabled] Restore AC Power Loss [Power Off] / [ Power On]/[ Last State] Default is [Power Off] Deep Sx Deep Sx configuration.
  • Page 83 [Disabled] / [Enabled in S5 (Battery)] / [Enabled in S5] / [Enabled in S4 and S5 (Battery)] / [Enabled in S4 and S5] Default is [Disabled] Disable SCU devices [Disabled] / [Enabled] Default is [Disabled] Onboard SAS OPROM Enable/Disable onboard SAS RAID option rom if Launch Storage OpROM is enabled.
  • Page 84 3.7.3 – Onboard Devices Configuration Sub-Menu Intel LAN 82574 #1 [Enabled with iSCSI] / [Enabled with PXE] / [Enabled] / [Disabled] Default is [Enabled] Intel LAN 82574 #2 [Enabled with PXE] / [Enabled] / [Disabled] Default is [Enabled] Firewire(1394) Enable/disable firewire(1394) [Enabled] / [Disabled] Default is [Enabled] USB3.0...
  • Page 85 3.7.4 – ME Sub- Menu ME Subsystem Me subsystem Help [Enabled] / [Disabled] Default is [Enabled]...

  • Page 86: Boot Configuration

    3.8 - Boot Configuration Setup Prompt Timeout Only read Bootup Numlock State Select the keyboard Numlock state [On] / [Off] Default is [On] Quiet Boot [Disabled] / [Enabled] Default is [Disabled] GateA20 Active [Upon Request] / [Always] Default is [Upon Request] Option ROM Messages Set display mode for option ROM upon request—GA20 can be disabled using BIOS series Always—do not allow disabling GA20;...
  • Page 87 INT 19 Trap Response BIOS reaction on INT19 trapping by option ROM: IMMEDIATE-execute the trap right away; POSTPONED-execute the trap during legacy boot. [Immediate] / [Postponed] Default is [Immediate] Boot Option #1 Select the first boot device. [Device Name] / [Disabled] Default is [Device Name]...

  • Page 88: Security Menu

    3.9 - Security Menu Password Description Read only. Administrator Password Install or change the password. User Password Install or change the password.

  • Page 89: Save & Exit Menu

    3.10 - Save & Exit Menu Save Changes and Exit Use this option to exit setup utility and re-boot. All new selections you have made are stored into CMOS. System will use the new settings to boot up. Discard Changes and Exit Use this option to exit setup utility and re-boot.
  • Page 90 Restore Defaults Use this option to restore defaults Save as user Defaults Use this option to save the user defaults Restore user Defaults Use this option to restore the user defaults.

  • Page 91: Event Logs

    3.11 - Event Logs...
  • Page 92 Smbios Event Log Change this to enable or disable all features of Smbios Event Logging during boot. [Enabled] / [Disabled] Default is [Enabled] Erase Event Log Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation during reset.

  • Page 93: Chapter 4: Diagnostics

    Please be aware that by flashing your BIOS, you agree that in the event of a BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. Leadtek does not have a policy for replacing BIOS chips directly with end users. In no event will...

  • Page 94: Amibios Post Code (Aptio)

    4.2 - AMIBIOS Post Code (Aptio) The POST code checkpoints are the largest set of checkpoints during the BIOS pre- boot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS: Checkpoint Ranges Status Code Range Description...
  • Page 95 SEC Error Codes 0x0C – 0x0D Reserved for future AMI SEC error codes 0x0E Microcode not found 0x0F Microcode not found SEC Beep Codes None PEI Phase Status Code Description Progress Codes 0x10 PCI Core is started 0x11 Pre-memory CPU initialization is started 0x12 Pre-memory CPU initialization (CPU module specific) 0x13...
  • Page 96 Status Code Description 0x38 Post-Memory North Bridge initialization (North Bridge module specific) 0x39 Post-Memory North Bridge initialization (North Bridge module specific) 0x3A Post-Memory North Bridge initialization (North Bridge module specific) 0x3B Post-Memory South Bridge initialization is started 0x3C Post-Memory South Bridge initialization (South Bridge module specific) 0x3D Post-Memory South Bridge initialization (South Bridge module specific) 0x3E...
  • Page 97 Recovery Progress Codes 0xF0 Recovery condition triggered by firmware (Auto recovery) 0xF1 Recovery condition triggered by user (forced recovery) 0xF2 Recovery process started 0xF3 Recovery firmware image is found. 0xF4 Recovery firmware image is loaded. 0xF5 – 0xF7 Reserved for future AMI progress codes Recovery Error Codes 0xF8 Recovery PPI is not available.
  • Page 98 Status Code Description 0x6B North Bridge DXE initialization (North Bridge module specific) 0x6C North Bridge DXE initialization (North Bridge module specific) 0x6D North Bridge DXE initialization (North Bridge module specific) 0x6E North Bridge DXE initialization (North Bridge module specific) 0x6F North Bridge DXE initialization (North Bridge module specific) 0x70 South Bridge DXE initialization is started.
  • Page 99 Status Code Description 0xA3 IDE Enable 0xA4 SCSI initialization is started. 0xA5 SCSI Reset 0xA6 SCSI Detect 0xA7 SCSI Enable 0xA8 Setup Verifying Password 0xA9 Start of Setup 0xAA Reserved for ASL (see ASL Status Codes section below) 0xAB Setup Input Wait 0xAC Reserved for ASL (see ASL Status Codes section below) 0xAD...
  • Page 100 Status Code Description 0xDB Flash update is failed. 0xDC Reset protocol is not available. DXE Beep Codes # of Beeps Description Invalid password Some of the Architectural Protocols are not available. No Console Output Devices are found. No Console Input Devices are found. Flash update is failed.

  • Page 101: Appendix: Fan And Temp Sensors

    Appendix: Fan and Temp Sensors This section aims to help readers identify the locations of some specific FAN and Temp Sensors on the motherboard. A table of BIOS Temp sensor name explanation is also included for readers’ reference. NOTE: The red dot indicates the location of the sensor. Fan and Temp Sensor Location: Fan Sensor: It is located in the third...
  • Page 102 BIOS Temp Sensor Name Explanation:...
  • Page 103 BIOS Temp Sensor Name Explanation CPU0_DTS Temperature of the CPU0 Digital Temperature Sensor CPU1_DTS Temperature of the CPU1 Digital Temperature Sensor CPU0_PECI Temperature of the CPU0 Platform Environment Control Interface CPU1_PECI Temperature of the CPU1 Platform Environment Control Interface PCH_Area_Temp Temperature of the PCH Area PCIE_Air_Inlet_Temp Temperature of the PCI-E Air Inlet Area...

  • Page 104: Glossary

    Glossary ACPI (Advanced Configuration and Power Interface): a power management specification that allows the operating system to control the amount of power distributed to the computer’s devices. Devices not in use can be turned off, reducing unnecessary power expenditure. AGP (Accelerated Graphics Port): a PCI-based interface which was designed specifically for demands of 3D graphics applications.
  • Page 105 losing your data should the system crash. Information in a buffer is temporarily stored, not permanently saved. Bus: a data pathway. The term is used especially to refer to the connection between the processor and system memory, and between the processor and PCI or ISA local buses.
  • Page 106 BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. Leadtek’s BIOS updates can be found at http://www.leadtek.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n-Play devices in the system BIOS.
  • Page 107 I/O (Input/Output): the connection between your computer and another piece of hardware (mouse, keyboard, etc.) IRQ (Interrupt Request): an electronic request that runs from a hardware device to the CPU. The interrupt controller assigns priorities to incoming requests and delivers them to the CPU. It is important that there is only one device hooked up to each IRQ line;...
  • Page 108 designed to define a standard set of preboot protocol services within a client with the goal of allowing networked-based booting to boot using industry standard protocols. RAID (Redundant Array of Independent Disks): a way for the same data to be stored in different places on any hard drives. By using this method, the data is stored redundantly and multiple hard drives will appear as a single drive to the operating system.
  • Page 109 advantage of the increased bandwidth of the PCI Express bus architecture, and features hardware and software innovations within NVIDIA GPUs (graphics processing units) and NVIDIA MCPs (media and communications processors). Depending on the application, NVIDIA SLI can deliver as much as two times the performance of a single GPU configuration.

  • Page 110: Technical Support

    (which can have expensive consequences). If these options are not available for you then Leadtek can help. Besides designing innovative and quality products for over 25 years, Leadtek has continuously offered customers service beyond their expectations.
  • Page 111 (RMA) number. The RMA number Should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. Leadtek will pay to have the board shipped back to you. Notice for the USA Compliance Information Statement (Declaration of Conformity...

  • Page 112: Winfast Ws1000 Chassis Introduction

    WinFast WS1000 Chassis Introduction Model Number WinFast WS1000 Dimension(mm) 533x198x425 M/B Size(max.) 12” x 13” 5.25” Bay 3.5” Bay HDD Trays Backplane Serial ATA Cooling fan 1x120mm, 92mm, 80mm Front USB PSU Support Single PS/2 Rackmount by tray (optional)
  • Page 113 WinFast WS1000 Outline Power ON LED Description 24X DVD RW HDD activity LED 3x5.25" bays USB Cover LAN1 activity LED Power button RESET button LAN2 activity LED Alarm Mute KeyLock Fan Failure Foot Stand &Overheat LED...
  • Page 114 WinFast WS1000 Rear View Side cover screws Single PS/2 PSU 120mm Rear Fan Slot bracket with ventilation holes Support Kensington Lock WinFast WS1000 Rear View...
  • Page 115 WinFast WS1000 Side View 80mm fan holder Description Easy bezel removal design Screws for slide rail installation Hotswap HDD Cage 92mm fan Add-on card retainer Mother board 120mm rear fan 900W Power supply Hotswap Cage...
  • Page 116 Front Panel Indicators Status of LED colors Power Blue, Power on Blue, Access IDE HDD HDD Activity LAN1 Activity Blue/Cable connection Blinking blue/LAN Activity LAN2 Activity Overheat& Fan failure Red, Fan Failure or HDD overheat LEDs Color of Wires Power Green/Black HDD Activity RED/Black...
  • Page 117 Serial ATA Backplane I. Connectors Layout Description J9, 4pin DC Power Connector J10, 4pin DC Power Connector FAN1, 3P3C Fan Connector FAN2, 3P3C Fan Connector J5, 7P serial ATA Connector J7, 7P serial ATA Connector J6, 7P serial ATA Connector J8, 7P serial ATA Connector S1, Hardware Monitor switch JP1, Front Panel Control Jumper...
  • Page 118 II. HDD Connectors Description J1, serial ATA HDD1 connector J2, serial ATA HDD2 connector J3, serial ATA HDD3 connector J4, serial ATA HDD4 connector...
  • Page 119 III. Jumper Settings...
  • Page 120 Chassis Installation and Assembly Open the front bezel of WinFast WS1000 (a). Unlock the keylock on rear panel if necessary (b). Remove the side cover as instrucions decribed in next section (c). Swing the release lever(1) anticlockwise, and then take off it from chassis.
  • Page 121 Installing HDD and HDD Cage I. Before start Hotswap Cage WS1000 80mm Fan Holder(1) Support Location of thumbscrews(2) Up&down Type of thumbscrews(3) #6-32*D12 WS1000 Hotswap Cage...
  • Page 122 II. Know hard disk carrier The hard disk carrier is used to hotswap cages of WinFast WS1000. assembly parts are detailed as the picture below. Description Contact spring to chassis HDD Power ON LED HDD activity LED Release button Contact spring to upper carrier Lever Air dam NOTE:...
  • Page 123 III. Removing Hotswap Cage (a). Loosen the four thumbscrews, which secure the HDD cage to chassis body. (b). Pull out the HDD cage slightly. (c). Disconnect serial ATA or power cables. (d). Continue to pull out this HDD cage until it is totally out of drive bay. IV.
