Page 1 TS4000 Radio Modem User’s Manual Version 5.32 1729 South Main Street Milpitas, CA 95035 (408) 941-1808 (800) 663-3674 (408) 941-1818 Fax www.teledesignsystems.com productsales@teledesignsystems.com techsupport@teledesignsystems.com...
Page 2 Copyright This document is copyrighted by Teledesign Systems Inc. with all rights reserved. No part of this document may be reproduced in any form without the prior written consent of Teledesign Systems Inc. © Copyright 1995 - 2007 by Teledesign Systems Inc. All rights reserved.
Page 3: Emissions
Emissions The TS4000 has been tested and found to comply with the limits for a Class B Part 15 digital device, pursuant to Part15 of the FCC rules (Code of Federal Regulations 47CFR Part 15). Operation is subject to the condition that this device does not cause harmful interference.
Page 4: Table Of Contents
Connections.....................5 Serial Port ...................5 Antenna Connector ................5 Power Connection................5 Mounting ....................6 Configuring the TS4000 ................6 AirTest - Data Testing ................6 Upgrading the TS4000 Firmware ............6 AirScan .....................6 Remote Diagnostics................6 AirCalc - Range Estimation ..............7 Status Lights....................8 Configuration Program..................9 Using Help....................9 System Requirements................9...
Page 5 Setting Packet Timeout..............58 Data Packet Delay ................59 GPS Configuration..................61 Configuration Options ................61 Testing ......................64 AirTest ....................64 Data Test ..................64 BER Test...................65 AirScan ....................66 AirScan Controls ................66 Remote Diagnostics ..................67 Remote Diagnostics with Repeaters ..........67 TS4000 Radio Modem User’s Manual Table of Contents...
Page 6 General Strings .................89 Frequency Control Strings ..............89 Modem Configuration Strings ............89 Packet Strings...................90 Diagnostics Strings ................91 Appendix F – Internal Jumper Block ............95 Factory Default Jumper Settings ............95 Instructions for Accessing the Jumpers..........95 TS4000 Radio Modem User’s Manual Table of Contents...
Page 7 Jumper Settings for Power on Serial Port 1 - Pin 4 ......96 Jumper Settings for Power on Serial Port 2 - Pin 9 ......97 Jumper Settings for TTL Levels on Serial Port 1......97 Appendix G – FCC MURS Rules..............98 TS4000 Radio Modem User’s Manual Table of Contents...
Page 8: Ts4000 Overview
Introduction wireless transmission of digital data. The TS4000 can transfer data at rates up to 19,200 bits per second. The TS4000 includes a synthesized VHF, UHF or 900 MHz transceiver that can be programmed for up to 99 channels. This product is ideally suited to OEMs and system integrators who require a versatile radio modem in a single package.
Page 9 Provides easy determination of the radio coverage and signal quality between TS4000s. Available while the system is in normal operation. Can be used through Serial Port 1 or Serial Port 2 of the TS4000. Windows display software provided, free of charge, with the TS4000 Configuration Software.
Page 10: Model Numbers
TS4000 can be operated with. Transmit duty cycle is the percentage of time that the modem is transmitting (i.e. 50 %). If the TS4000 is operated with too high a transmit duty cycle, then the radio module may get too hot which can result in damage.
Page 11: Channel Spacing And Bandwidth
For the TS4000, the data rate and the type of modulation control the transmitted Transmit Channel channel bandwidth. Therefore, it is important that the TS4000 is setup so that its...
Page 12: Connections
Watertight Case interface connector (See Appendix A - Serial Port). A variety of antennas can be used with the TS4000, but it is important that the Antenna Connector antenna provides a 50 ohm load at the radio’s operational frequencies. In addition, all cabling used with the antenna must be good quality coaxial cable with 50 ohm impedance.
Page 13: Mounting
Watertight Case connector. Fuses The TS4000 has an internal 4 amp fuse for each of the three possible power connections. The power source used with the TS4000 should also be fused with an in-line power fuse. The preferred method of mounting the TS4000 is to use the mounting bracket Mounting supplied with the modem.
Page 14: Aircalc - Range Estimation
Teledesign for ordering information. The remote diagnostics can be accessed using the Remote Diagnostics screen in the TS4000 Configuration Program and can be operated through either serial port. For more details see Remote Diagnostics. Teledesign provides wireless range estimation software called AirCalc.
Page 15: Status Lights
The TS4000 has three lights (LED) indicators to provide operational status of Status Lights transmit (TX), receive (RX) and power (PWR) functions. Special combinations of these indicators are used to indicate secondary operating modes and fault conditions. TS4000 State LEDs...
Page 16: Configuration Program
3) Follow the installation instructions. Serial Cable TS4000 to PC To transfer configurations between the TS4000 and a PC, their serial ports must Connection be connected together. The serial cable used should be a standard straight through (i.e. pin 1 to pin 1, pin 2 to pin 2, etc) serial cable. This is the same type of cable used to connect a PC to a standard phone modem (See Serial Port).
Page 17: Programming And Retrieving Configurations
The configuration of the TS4000 can be read out of the modem by selecting the Programming and Retrieve Configuration command from the Modem Retrieving menu or by pressing the Retrieve Configuration button. Configurations To program a configuration into the TS4000, use...
Page 18: Diagnostics
Choose the Diagnostics menu to run, read and display diagnostic status of the Diagnostics Screen TS4000. The diagnostics tests the major components of the modem and also monitors the power supply voltages. TS4000 Radio Modem User’s Manual...
Page 19: Modem Hardware Screen
These include details on the firmware version and memory Screen configuration. These modem hardware values are set at the factory based on the modem hardware included in the TS4000 and cannot be changed. Choose the Retrieve Radio Hardware menu to read and display the radio Radio Hardware hardware details.
Page 20: Rs-232 Serial Port
The serial port provides an asynchronous data connection between the TS4000 and the host equipment. The TS4000 serial port is a standard RS-232 serial port with a number of options to allow connection to a wide variety of serial host equipment.
Page 21: Serial Port Connector
The TS4000 with the standard case uses two 9 pin subminiature D connectors Connector with female pins for the serial ports. The TS4000 with the watertight case uses a 19 pin environmentally sealed LEMO connector (see Appendix A - Serial Port).
Page 22: Ri Pin Signal Options
RI pin is normally left unconnected. RI for Modem Power As an alternative, the RI pin can be connected as a power pin into the TS4000. This is non-standard use of this pin and therefore care should be taken when connecting the TS4000 to other serial devices.
Page 23: Configuration Options
Protocol Options Hardware Handshake In this mode the RTS handshake line is used to frame transmit data into bursts. The TS4000 begins transmission when RTS is activated and at least one character (non-control string) is received. Transmission ends when RTS goes inactive and the burst has been completely transmitted.
Page 24 Baud Rate is the value selected from the baud rate list. Wait For Complete Burst This option only has effect only in transparent (non-packet) mode. In packet mode the TS4000 always waits for a complete burst before beginning Before Beginning transmission. Transmission...
Page 25 DCD is active when receive data is sent out of the Receive Data to the User TS4000 via the serial port. Active when Receiving DCD is active when the TS4000 detects a signal on the radio channel. This mode can be used to remote the receive light. Both...
Page 26: Serial Port 2
DSR is active when the TS4000 is transmitting. This selection can be used to remote the transmit light. Active when Receiving DSR is active when the TS4000 detects a signal on the radio channel. This mode can be used to remote the receive light. Serial Port 2 TS4000 Radio Modem User’s Manual...
Page 27 Transmitting DSR Line Control – Active DSR is active when the TS4000 is powered and there are no active faults. An when Operational active fault is indicated by a flashing power light. TS4000 Radio Modem User’s Manual...
Page 28: Radio Setup
This is set at the factory when the unit is manufactured. This maximum value will be shown in the range label when the configuration program is connected to the modem. TS4000 Radio Modem User’s Manual Radio Setup...
Page 29 TS4000 can correctly demodulate the incoming data. When using the TS4000 in a high noise environment, this level can be raised so that the TS4000 is more selective about the signals that it attempts to demodulate.
Page 30: Clear Channel Scan
When clear channel scan is enabled, all of the TS4000s (both transmitters and receivers) constantly scan the channels of the scan list looking for valid TS4000 transmissions and also looking for interference (noise or transmissions from other sources).
Page 31 Transmit Timeout Timer specified period of continuous transmission. This is used to avoid locking up the radio channel due to a continuous transmission caused by a fault in the TS4000 or the host equipment. When enabled, the TS4000 does not receive and will transmit regardless of Transmit Only Operation activity on the channel.
Page 32 When enabled, the TS4000 will not transmit data sent to it through the serial port. Receive Only Operation Transmit Power This sets the transmit power level. The maximum transmit power that can be set depends on the specific radio module in the TS4000. Therefore the maximum value that can be set is listed only when the configuration program is connected to the TS4000.
Page 33: Frequency Programming
The TS4000 comes in various frequency bands (i.e. 450 to 470 MHz) and can be Frequency programmed for any valid channel within a given frequency band. The TS4000 Programming can be set for up to 99 channels. A channel consists of a receive frequency and a transmit frequency which can be set to the same or different frequencies.
Page 34: Frequency Configuration Screen
The minimum and maximum frequencies and the channel spacing depend on the specific radio module in the TS4000. The configuration program does not know this information unless it is connected to the TS4000. Therefore, these fields in the Radio Settings frame only show up when the configuration program is connected to the TS4000.
Page 35: Channel Switching
RX and TX lights will alternately flash. The channel that the TS4000 activates at power up depends on the setting of the Channel at Power Up Frequency Channel at Power Up control (see Radio Setup – Frequency Channel at Power Up).
Page 36: Compatibility
Compatibility mode allows the TS4000 to be setup to be compatible with our Compatibility previous generation TSI9600 radio modem. Enable Selection Description Trimble This mode allows the TS4000 to communicate with Trimble Compatible TrimMark and TrimTalk GPS data links. Mode...
Page 37 Trimble Options - Mode This should be set to match the type of Trimble data link that the TS4000 must operate with. This should be set to match the channel spacing of the Trimble data link that the Trimble Options –...
Page 38: Airnet Packet Protocol
AirNet Packet Protocol AirNet is an embedded packet protocol available in some Teledesign Systems Overview modems. AirNet provides a complete protocol that manages the end to end data transfers of wireless networks. The AirNet protocol is flexible and configurable so that it can be used with any host (user) system or network architecture.
Page 39 Any unit can be configured as a relay node. Allows for easy expansion of the network. Repeater filter allows for repeating of only packets to or from select nodes. This minimizes the amount of repeater traffic created. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 40: Configuration Options
(see CSMA MAC Options - Transmission Index). This minimizes the potential for collisions in multi- access systems. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 41 A packet is repeated if the packet’s source or destination address matches an address range in the list. The addresses consist of a group address and a minimum and maximum individual TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 42: Packet For Port
Multicast Group Reception Multicast groups allow a modem to receive group broadcasts to groups other than its own. This allows modems to be combined in subsets and supersets of their basic groups. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 43 Packet Timeout The packet timeout is the amount of time the modem waits for an acknowledgment before re-sending a packet (see Network Setup - Setting Packet Timeout). TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 44 The corresponding packet number of the packet will be provided as part of the status string (see Control and Status Strings). This does not apply to any type of broadcast transfer or individual transfers without acknowledgment. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 45: Control And Status Strings
The first two characters are for the group address and the remaining three are for the individual destination address. +TSN Set for individual without acknowledgment transfer. +TSNAiii Set for individual without acknowledgment transfer with address change. The three address characters change the TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 46: Status Strings
+TSSPnn Indicates that the transfer of this packet number was successful. This does not apply to any type of broadcast packet or individual without acknowledgment packets. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 47: Master-Slave System Setup
Attack Time = Tx Attack Time + Additional Transmit Attack Time Tx Decay Time and Tx Attack Time are fixed values that are preset for the radio in the TS4000. These values can be read out of the TS4000 using the Retrieve Radio Hardware menu or button. The Additional Transmit Attack Time is the value set on the radio tab of the modem configuration.
Page 48: Data Packet Transmit Time
Packet Length = ((50 x 8) + 112) x 1.1 x 1.5 = 845 bits Packet Transmit Time = 845 / 9600 = 88 ms Total Packet Delay Time = 20 + 88 = 108 ms TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 49: Polled System With Store And Forward Repeaters
The following section will show a number of system topologies and the appropriate settings for the TS4000. All of these systems operate on a single frequency (simplex) although clear channel scan can be used.
Page 50: Single Repeater System
10+ (each remote must have a unique address) CSMA MAC Setup: Data Pkts: Min Idle Slots Remote Sites: Blind (that cannot hear the repeater) Modem Address: Individual 10+ (each remote must have a unique address) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 51 Packet Transmit Time = [9 * 255 * 1 / 9.6] + 20 = 259ms Number of slot for an outbound polling packet = 259/30 = 9 (rounded up from 8.6) (this value must always be round up) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 52: Dual Repeater System
CSMA MAC Setup: Relay Pkts: Min Idle Slots Store and Forward Repeater Operation: All Packets Relay All Repeater B Site Modem Address: Individual CSMA MAC Setup: Data Pkts: Min Idle Slots CSMA MAC Setup: Relay Pkts: Min Idle Slots TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 53 Packet Transmit Time = [9 * 255 * 1 / 9.6] + 20 = 259ms Number of slot for an outbound polling packet = 259/30 + 1 = 10 (rounded up from 9.6) (this value must always be round up) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 54: Three Repeater System
Modem Address: Individual CSMA MAC Setup: Data Pkts: Min Idle Slots CSMA MAC Setup: Relay Pkts: Min Idle Slots Store and Forward Repeater Operation: All Packets Relay All Repeater B Site Modem Address: Individual TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 55 Packet Transmit Time = [9 * 255 * 1 / 9.6] + 20 = 259ms Number of slot for an outbound polling packet = 259/30 + 2 = 11 (rounded up from 10.6) (this value must always be round up) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 56: Chain Repeater System
Relay All Repeater B Site Modem Address: Individual CSMA MAC Setup: Data Pkts: Min Idle Slots CSMA MAC Setup: Relay Pkts: Min Idle Slots Store and Forward Repeater Operation: All Packets Relay All TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 57 Packet Transmit Time = [9 * 255 * 1 / 9.6] + 20 = 259ms Number of slot for an outbound polling packet = 259/30 + 3 = 12 (rounded up from 11.6) (this value must always be round up) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 58: Other System Topologies
The TS4000 is very versatile and can be configured for virtually any system Other System topology. If one of the above topologies cannot be adapted to match a particular Topologies network then Teledesign can work with you to create a suitable configuration.
Page 59: Csma System Setup
Attack Time = Radio Attack Time + Additional Transmit Attack Time Tx Decay Time and Tx Attack Time are fixed values that are preset for the radio in the TS4000. These values can be read out of the TS4000 using the Retrieve Radio Hardware menu or button. The Additional Transmit Attack Time is the value set on the radio tab of the modem configuration.
Page 60: System With Repeaters - Setup Summary
Attack Time = Radio Attack Time + Additional Transmit Attack Time Tx Decay Time and Tx Attack Time are fixed values that are preset for the radio in the TS4000. These values can be read out of the TS4000 using the Retrieve Radio Hardware menu or button. The Additional Transmit Attack Time is the value set on the radio tab of the modem configuration.
Page 61 ACK Packet Length -Uncoded = 16 bytes x 8 bits per byte = 128 bits -Coded = 128 bits x 1.5 = 192 bits Decay Time = Tx Decay Time + Additional Transmit Attack Time Attack Time = Tx Attack Time + Additional Transmit Attack Time TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 62: Setting Slot Time
Attack Time = Tx Attack Time + Additional Transmit Attack Time Tx Attack Time is a fixed value that is preset for the radio in the TS4000. This value can be read out of the TS4000 using the Retrieve Radio Hardware menu or button. The Additional Transmit Attack Time is the value set on the radio tab of the modem configuration.
Page 63: Setting Tx Index
Attack Time = Tx Attack Time + Additional Transmit Attack Time Tx Decay Time and Tx Attack Time are fixed values that are preset for the radio in the TS4000. These values can be read out of the TS4000 using the Retrieve Radio Hardware menu or button. The Additional Transmit Attack Time is the value set on the radio tab of the modem configuration.
Page 64 Since: Max Backlogged Nodes / 4 > Average Backlogged Nodes Estimated Backlogged Nodes = Max Backlogged Nodes / 4 = 100 / 4 = 25 Transmission Index = Estimated Backlogged Nodes / Attempt Rate = 25 / 0.57 = 44 TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 65: Setting Packet Timeout
Added to this must be the number of idle slots between the last transmission and when the current relay decides to transmit. Relay #Y Data Packet Delay = Decay Time + (Y x Slot Time) + Attack Time + Data Packet Transmit Time TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 66: Data Packet Delay
PDR = Packet Detection Ratio TI = Transmission Index N = Backlogged Nodes PR = (TI - 1)/TI Average Delay = Tslot x (1 + PDR - PR N ) PDR x ln(1/PR) TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 67 Note that the 50% probability of sending value is not equal to the average delay. This is because the delay spread is a statistical distribution where the mean and median delays are not the same. TS4000 Radio Modem User’s Manual AirNet Packet Protocol...
Page 68: Gps Configuration
Note that a repeater unit can also be used to provide data to a GPS rover host. The baud rate list provides selection of the serial port asynchronous baud rate. Baud Rate List TS4000 Radio Modem User’s Manual GPS Configuration...
Page 69 This sets the transmit power level. The maximum transmit power that can be set depends on the specific radio module in the TS4000. Therefore the maximum value that can be set is listed only when the configuration program is connected to the TS4000.
Page 70 TS4000 can correctly demodulate the incoming data. When using the TS4000 in a high noise environment, this level can be raised so that the TS4000 is more selective about the signals that it attempts to demodulate.
Page 71: Testing
To start AirTest press the AirTest button on the main screen of the configuration program. For details on using AirTest consult AirTest’s on line help. To test the operation of the TS4000, AirTest can be used to pass data between Data Test two modems.
Page 72: Ber Test
AirTest can be setup to run a BER test. To run a BER test, the TS4000s must be configured with packet operation disabled. This is because when the TS4000 is setup for packet operation it discards corrupted packets and does not send them out the serial port.
Page 73: Airscan
AirScan enables the TS4000 to be used as a frequency scanner. AirScan is AirScan useful for determining the frequency and magnitude of potential interference within the TS4000’s frequency band. To start AirScan press the AirScan button on the main screen of the configuration program.
Page 74: Remote Diagnostics
Remote diagnostics is available while the host system is in operation and can be accessed through serial port 1 or 2 of the TS4000. The remote diagnostics screen is accessed from the main screen of the TS4000 Configuration Program.
Page 75 This button is used to retrieve the diagnostics data from the TS4000 that the PC Retrieve Local Diagnostics is physically connected to. This function does not require the remote diagnostics firmware upgrade option.
Page 76: Remote Diagnostics Request And Response Strings
Temp The internal temperature of the modem. Tx Power Forward The forward (outgoing) transmit power of the modem. This field is not available on all TS4000 models. Tx Power The transmit power reflected back into the modem. Reflected This field is not available on all TS4000 models.
Page 77: Upgrading Firmware
Upgrading Firmware The TS4000 comes with flash program memory that allows the firmware to be easily upgraded in the field. Firmware is upgraded with the upgrade program which is included as part of the TS4000 configuration program. 1) Attach the TS4000 to a PC serial port.
Page 78: Licensing
Note that the setting of occupied bandwidth limits the maximum over the air data rate that the TS4000 can operate at. The maximum over the air data rate is also dependent on the modulation type selected.
Page 79: Usa (Fcc)
TS4000 meets the licensing requirements. The TS4000 radio modem can be used without a license, with some restrictions, Unlicensed in the United States on five specific VHF frequencies under the MURS (Multi-Use Operation Radio System) rules of the FCC.
Page 80: Power
USA (FCC) Part 15 The TS4000 has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC rules (Code of Federal Regulations 47CFR Part 15). Operation is subject to the condition that this device does not cause harmful interference.
Page 81: Industry Canada
Many countries allow radio equipment that meets the FCC rules to be operated. International However, some countries have their own rules which radio manufactures must comply with. It is the user’s responsibility to ensure that the TS4000 meets the required regulations. TS4000 Radio Modem User’s Manual...
Page 82: Service And Support
Service and technical support can be reached during our normal business hours Contacting of 8 AM to 5 PM (Pacific Standard Time) Monday through Friday. Teledesign Teledesign Systems can be reached at the following phone numbers.
Page 83: Warranty
Warranty Two Year Warranty Teledesign Systems Inc. warrants this product to be free from defects in materials and workmanship for a period of two (2) years from the date of shipment. During the warranty period, Teledesign Systems Inc. will, at its option, either repair of replace products that prove to be defective.
Page 84: Appendix A - Serial Ports
Data Terminal Ready (DTR) Input Transmit Data (TD) Input Receive Data (RD) Output Data Carrier Detect (DCD) Output Signal Ground (SG) Data Terminal Ready (DTR) Input Transmit Data (TD) Input TS4000 Radio Modem User’s Manual Appendix A - Serial Ports...
Page 85 [2] This pin is normally setup as the serial port Data Terminal Ready (DTR) line, which is an input for DCEs (input to the TS4000). As an alternative, this pin can be setup to feed DC power into the TS4000.
Page 86: Standard Rs-232 Serial Port Pinout
Instead, this pin can be connected to the serial port Data Set Ready (DSR) line which is an output for DCEs (output of the TS4000), or this pin can be setup to provide DC power into the TS4000.
Page 87: Signal Levels
Stop bit state (end of async character) Logic one data bit state (within async character) Voltage High Space Control signal active Start bit state (beginning of async character) Logic zero data bit state (within async character) TS4000 Radio Modem User’s Manual Appendix A - Serial Ports...
Page 88: Appendix B - Ascii Character Set
& Ctrl-G ‘ Ctrl-H Ctrl-I Ctrl-J Ctrl-K Ctrl-L Ctrl-M Ctrl-N Ctrl-O Ctrl-P Ctrl-Q Ctrl-R Ctrl-S Ctrl-T Ctrl-U Ctrl-V Ctrl-W Ctrl-X Ctrl-Y Ctrl-Z Ctrl-[ Ctrl-\ < Ctrl-] Ctrl-^ > Ctrl- TS4000 Radio Modem User’s Manual Appendix B - ASCII Character Set...
Page 89: Appendix C - Specifications
4.3" x 3.1" x 1.8" (109 mm x 79 mm x 46 mm) w/o heat sink 5.0" x 3.1" x 1.8" (127 mm x 79 mm x 46 mm) with heat sink Enclosure Options Standard and Watertight TS4000 Radio Modem User’s Manual Appendix C - Specifications...
Page 90: Specifications: Ts4000-02A
1.5 watts - Receive (typical) 7.0 watts - Transmit (typical) Dimensions 4.3" x 3.1" x 1.8" (109 mm x 79 mm x 46 mm) w/o heat sink Weight 14 ounces (400 grams) TS4000 Radio Modem User’s Manual Appendix C - Specifications...
Page 91: Specifications: Ts4000-05B
1.5 watts - Receive (typical) 27 watts - Transmit (typical) Dimensions 6.5" x 3.1" x 1.8" (165 mm x 79 mm x 46 mm) with heat sink Weight 20 ounces (560 grams) TS4000 Radio Modem User’s Manual Appendix C - Specifications...
Page 92: Specifications: Ts4000-05C
1.5 watts - Receive (typical) 24 watts - Transmit (typical) Dimensions 6.5" x 3.1" x 1.8" (165 mm x 79 mm x 46 mm) with heat sink Weight 20 ounces (60 grams) TS4000 Radio Modem User’s Manual Appendix C - Specifications...
Page 93: Specifications: Ts4000-05D
1.5 watts - Receive (typical) 30 watts - Transmit (typical) Dimensions 6.5" x 3.1" x 1.8" (165 mm x 79 mm x 46 mm) with heat sink Weight 20 ounces (560 grams) TS4000 Radio Modem User’s Manual Appendix C - Specifications...
Page 94: Appendix D - Case Dimensions
P W R connector 1.78" TS4000 Radio Modem Serial Number: 012345 Optional Mounting Plate 4-40 tapped 0.56" Mounting Hole, 6 places 1.98" 3.10" 0.56" 1.14" 0.99" 0.99" 1.14" 4.25" 4.93" TS4000 Radio Modem User’s Manual Appendix D - Case Dimensions...
Page 95 RX PWR DATA PORTS 1.78" TS4000 Radio Modem Serial Number: 012345 Optional Mounting Plate 4-40 tapped 0.56" Mounting Hole, 6 places 1.98" 3.10" 0.56" 1.14" 0.99" 0.99" 1.14" 4.25" 4.93" TS4000 Radio Modem User’s Manual Appendix D - Case Dimensions...
Page 96: Appendix E - Control And Status Strings
:03,006-123 - the modem will repeat packets will repeat packets with a source or destination address in group 3 from 6 to 123. :00,000-000 - the modem will repeat all network TS4000 Radio Modem User’s Manual Appendix E – Control and Status Strings...
Page 97: Packet Strings
+TSG Set for group broadcast transfer. +TSGAgg Set for group broadcast transfer with address change. The two address characters change the group destination address. TS4000 Radio Modem User’s Manual Appendix E – Control and Status Strings...
Page 98: Diagnostics Strings
= Individual address as ASCII character The local diagnostics response is a total of 45 bytes with the following fields. Local Diagnostics Response Structure Structure Field Description Header +TSDL TS4000 Radio Modem User’s Manual Appendix E – Control and Status Strings...
Page 99 Redundancy A one byte field indicating if the TS4000 is part of a redundancy switch setup. 0 = Not in a redundancy switch 1 = The TS4000 is the A modem in a redundancy switch 2 = The TS4000 is the B modem in a redundancy switch TS4000 Radio Modem User’s Manual...
Page 100 A two byte (high byte first) binary number indicting the forward (outgoing) transmit power in 0.1 watt increments (i.e. 34 = 3.4 watts). This field is not available on all TS4000 models. A value of -1 (0xFFFF) indicates that this is not available from the TS4000.
Page 101 Redundancy A one byte field indicating if the TS4000 is part of a redundancy switch setup. 0 = Not in a redundancy switch 1 = The TS4000 is the A modem in a redundancy switch...
Page 102: Appendix F - Internal Jumper Block
1 located at the bottom right corner. Unless otherwise specified by the customer, the TS4000 is shipped from the factory with eleven jumpers installed as shown below.
Page 103 DTR pin (i.e. a PC). This could result in the power supply voltage of the TS4000 being shorted to the DTR output of the host serial port, which could damage the host device. Therefore, when connecting the TS4000 to a PC for configuration, make sure that the cable does not have the DTR (pin 4) line connected.
Page 104 Port 1 DSR RS232 signal Port 1 DSR TTL signal Port 1 DSR pin Port 1 DCD RS232 signal Port 1 DSR 1k pullup Port 1 DCD pin Port 1 DCD TTL signal TS4000 Radio Modem User’s Manual Appendix F – Internal Jumper Block...
Page 105 Appendix G – FCC MURS Rules For information on using the TS4000 under the FCC’s unlicensed MURS rules see the Licensing – Unlicensed Operation section above. Notes: 1) The rules for MURS first went into effect on November 13, 2000.
Page 106 95.1311 Repeater operations an signal boosters prohibited. MURS stations are prohibited from operating as a repeater station or as a signal booster. This prohibition include store-and-forward packet operation. 95.1313 Interconnection prohibited. TS4000 Radio Modem User’s Manual Appendix G – FCC MURS Rules...
Page 107 November 13, 2000, are granted a license by rule that authorizes continued operations under the terms of such nullified part 90 authorizations, including any rule waivers. TS4000 Radio Modem User’s Manual Appendix G – FCC MURS Rules...
