PRODUCT MODEL NUMBERS
KFCO22EV
KFCS22EV
Electrical Requirements: A 115 Volt, 60 Hz.,
AC only 15- or 20-amp fused, grounded electrical
supply is required. It is recommended that a
separate circuit serving only your refrigerator be
provided. Use an outlet that cannot be turned
off by a switch. Do not use an extension cord,
2-prong adapter or power strip.
NOTE: Before performing any type of installation,
cleaning or removing a light bulb, turn Cooling
OFF, and then disconnect the refrigerator from the
electrical source. When you are finished, reconnect
the refrigerator to the electrical source and turn
Cooling ON.
Water Supply Requirements: Connect the ice
maker to a cold water line with water pressure
between 35 and 120 psi (241 and 827 kPa).
IMPORTANT: The pressure of the water coming
out of a reverse osmosis system going to the
water inlet valve of the refrigerator needs to be
between 35 and 120 psi (241 and 827 kPa).
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the system needs to be a minimum of
approximately 40 to 60 psi (276 to 414 kPa).
LOCATION REQUIREMENTS
1/2"
(1.25 cm)
2-1/2" (6.3 cm)
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
French Door Refrigerator
PRODUCT DIMENSIONS
Model #
KFCO22EV
KFCS22EV
To ensure proper ventilation for your refrigerator,
allow for a 1/2" (1.25 cm) space at the top and behind
the refrigerator. If your refrigerator has an ice maker,
allow extra space at the back for the water line
connections. When installing your refrigerator next to
a fixed wall, leave 2-1/2" (6.3 cm) minimum on both
sides (some models require more) to allow for the
doors to swing open.
NOTE: It is recommended that you do not install the
refrigerator near an oven, radiator, or other heat
source. Do not install the refrigerator in a location
where the temperature will fall below 55°F (13°C).
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
B
A
not incl.
handle
E
incl.
C
handle
top of
cabinet
Depth
Cab. Width Cab. Height Overall Height
"A"
"B"
27-5/8"
35-5/8"
(70.17 cm) (90.49 cm)
27-5/8"
35-5/8"
(70.17 cm) (90.49 cm)
D
overall
Depth
"C"
"D"
70-7/8"
71-7/8"
30-1/8"
(180.02 cm)
(182.56 cm)
(76.52 cm)
70-7/8"
71-7/8"
30-1/8"
(180.02 cm)
(182.56 cm)
(76.52 cm)
"E"
Ref. 12828187
07-01-08
