This manual pertains to the following products
•
W-TX
•
W-RX
INCLUDED IN BOX:
•
(1) W-RX or W-TX
•
(1) 5.9V DC Adapter
•
(1) Mounting Bracket
•
(1) Quick User Guide
FEATURES:
• Connection Reliability: The W-TX and W-RX utilize a sophisticated frequency hopping algorithm
at 5.8 GHz and dual antenna diversity for best in class reliability. These devices will never interfere
with ZigBee, Z-Wave, Bluetooth, WiFi, or other wireless protocols in the crowded 2.4GHz channel.
• Easy One-Time Pairing: Pairing is as easy as plugging in and pressing a button. Once paired, the
devices will stay paired even if the power goes out.
Versatile Mounting: The included mounting bracket is designed to mount to the back of a sub, wall,
or other surface mount. The versatile hole pattern allows for a wide range of installation scenarios.
• Pairs with SLIM-PWR44: The W-RX receiver pairs seamlessly with the built in wireless sub trans-
mitter in the SLIM-PWR44 for even more bass.
• Multiple Receivers: One transmitter can connect with up to 8 receivers for earth shattering bass
or for placing many subwoofers in a multi-channel system throughout a home.
WIRELESS SUB EXTENDERS
W-TX / W-RX
User Manual
Advertisement
Table of Contents
Summary of Contents for TruAudio W-TX
- Page 1 (1) Quick User Guide FEATURES: • Connection Reliability: The W-TX and W-RX utilize a sophisticated frequency hopping algorithm at 5.8 GHz and dual antenna diversity for best in class reliability. These devices will never interfere with ZigBee, Z-Wave, Bluetooth, WiFi, or other wireless protocols in the crowded 2.4GHz channel.
- Page 2 User Manual MOUNTING TO SUBWOOFER: Each W-TX and W-RX comes with an included bracket for mounting to a sub, flat surface, or other installation scenarios. Follow these steps to install a receiver to the back of a sub. Step 1: Remove two screws that mount the sub amp to the cabi- net.
- Page 3 WIRELESS SUB EXTENDERS W-TX / W-RX User Manual CONNECTING: For best results use high quality, low impedance, shielded RCA connectors. For stereo inputs con- nect to the RCA Audio In jack. This can be connected to line level outputs on a source device such as a TV or AV receiver.
- Page 4 5. Press the Pair button on the W-RX. 6. Within 10 seconds of pressing pair on the receiver, power on the W-TX transmitter by applying the 5.9v DC In. Note: During the boot up process, the W-TX searches for the W-RX in pair mode and connects automatically.
- Page 5 User Manual PAIRING MULTIPLE RECEIVERS: Each W-TX is capable of connecting with up to 8 W-RX devices and transmitting to all of them simultaneously. To pair a transmitter with multiple receivers, first ensure that only the intended trans- mitter is powered on and all others are off. Establish the first receiver pairing by using the normal procedure.
-
Page 6: Troubleshooting
These warrantees shall not apply to products which have been abused, modified, disassembled, or repaired by anyone other than TRUAUDIO or one of its appointed service centers. Products to be repaired under this warranty must be returned to the factory or designated service center with all transportation and insurance charges pre-paid.
