User Manual
Combo DB-15
Combo DB-15 2-Console KVM
Combo DB-15 KVM
Designed/Manufactured by Austin Hughes and Distributed by Eclipse Rackmount, Inc.
Manual ML43V02A -- Generation 4 -- www.EclipseRackmount.com
- Integrated USB KVM
for LCD Console Drawer
KVM
8-IP
16-IP
Rear
8-2X
16-2X
Rear
8-USB
16-USB
Rear
Advertisement
Table of Contents
Summary of Contents for CyberView Combo DB-15 IP KVM 8-IP
- Page 1 User Manual - Integrated USB KVM for LCD Console Drawer 8-IP Combo DB-15 16-IP Rear 8-2X Combo DB-15 2-Console KVM 16-2X Rear 8-USB Combo DB-15 KVM 16-USB Rear Designed/Manufactured by Austin Hughes and Distributed by Eclipse Rackmount, Inc. Manual ML43V02A -- Generation 4 -- www.EclipseRackmount.com...
-
Page 2: Safety Instructions
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 3: Table Of Contents
Contents < Part 1 > Combo DB-15 KVM Kit Ending in: 8-IP, 16-IP Package Contents KVM Port Connections IP Console Connection IP Console Settings KVM Cascade Specifications < Part 2 > Combo DB-15 2-Console KVM Kit Ending in: 8-2X, 16-2X Package Contents P. -
Page 4: Part 1 > Combo
< Part 1 > Combo DB-15 < 1.1 > Package Content < 1.1 > Package Contents Combo DB-15 IP KVM 8-IP 16-IP KVM Rear Kit Rear The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model. -
Page 5: Kvm Port Connections
< 1.2 > KVM Port Connections Combo DB-15 IP KVM CAE-6 / CAE-10 / CAE-15 USB Servers ■ ■ 6 / 10 / 15 ft Combo KVM cable ■ ■ Support PS/2 or USB server DB-15 Combo KVM port Drawer KVM Rear Kit CAE - 6 / 10 / 15 Combo KVM cable supports PS/2 or USB server PS/2 Servers... - Page 6 After the cable connection, please take the following steps to configure the IP KVM : 1. Download IPKVMsetup.exe from the link: www.austin-hughes.com/support/utilities/cyberview/IPKVMsetup.exe 2. Double click IPKVMsetup.exe to configure the IP KVM by device setup as below. 3. Click Refresh Device to search the connected IP KVM 4.
-
Page 7: Kvm Cascade
< 1.5 > KVM Cascade Combo DB-15 IP KVM ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVM1-8-USB / KVM1-16-USB. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 8: Specifications
< 1.6 > Specifications Combo DB-15 IP KVM Ending in 8-IP, 16-IP KVM Port ▀ Number of ports: 8 or 16 Connector: DB-15 combo connector Connectivity: Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 ) ▀... -
Page 9: Part 2 > Combo Db-15 2-Console Kvm Kit
< Part 2 > Combo DB-15 2-console KVM < 2.1 > Package Contents Combo DB-15 2-console KVM 8-2X / 16-2X • Receiver box for remote console x 1 • Power adapter w/ power cord ( for receiver ) x 1 •... -
Page 10: Kvm Port Connections
< 2.2 > KVM Port Connections Combo DB-15 2-Console KVM CAE-6 / CAE-10 / CAE-15 USB Servers ■ 6 / 10 / 15 ft Combo KVM cable ■ Support PS/2 or USB server DB-15 Combo KVM port Drawer KVM Rear Kit CAE - 6 / 10 / 15 Combo KVM cable supports PS/2 or USB server PS/2 Servers... - Page 11 Using the Receiver Combo DB-15 2-console KVM Receiver Local Computer Monitor Remote I/O Front Power Rear Local Remote Mouse Button Button KVM switch The receiver allows for hotkey functions (listed on page 21). Remote Drawer KVM Rear Kit Console Monitor CAE-6 Cat 6 cable Local computer...
-
Page 12: Kvm Cascade
< 2.4 > KVM Cascade Combo DB-15 2-console KVM ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVM1-8-USB / KVM1-16-USB. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 13: Specifications
< 2.5 > Specifications Combo DB-15 2-console KVM Ending in 8-2X, 16-2X KVM Port ▀ Number of ports: 8 or 16 Connector: DB-15 combo connector Connectivity: Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 ) ▀... -
Page 14: Part 3 > Combo Db-15 Kvm Kit
< Part 3 > Combo DB-15 KVM < 3.1 > Package Contents Combo DB-15 KVM 8-USB 16-USB KVM Rear Kit Rear The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model. 8-USB Cascade Power... - Page 15 < 3.2 > KVM Port Connections Combo DB-15 KVM CAE-6 / CAE-10 / CAE-15 USB Servers ■ 6 / 10 / 15 ft Combo KVM cable ■ Support PS/2 or USB server DB-15 Combo KVM port Drawer KVM Rear Kit CAE - 6 / 10 / 15 Combo KVM cable supports PS/2 or USB server PS/2 Servers...
- Page 16 < 3.3 > KVM Cascade Combo DB-15 KVM ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVM1-8-USB / KVM1-16-USB. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.
-
Page 17: Ending In 8-Usb, 16-Usb
< 3.4 > Specifications Combo DB-15 KVM Ending in 8-USB, 16-USB KVM Port ▀ Number of ports: 8 or 16 Connector: DB-15 combo connector Connectivity: Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 ) ▀... -
Page 18: Kvm Buttons
Part 4. Using the KVM Combo DB-15 KVM Usage 4.1 KVM Buttons Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch and finally the computer Front Panel - Port LED Indications Front Panel - Port LED Indications 8 ports... -
Page 19: Password
< 4.2 > Password Combo DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 20: Kvm Osd
< 4.3 > KVM OSD Combo DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter... -
Page 21: Kvm Hotkey & Remote Console Hotkeys
< 4.4 > KVM & Remote Console Hotkeys Combo DB-15 KVM Usage Local Console Hotkeys Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port... -
Page 22: Dc Power 12V, 24V, 48V Input
< 4.5 > DC Power 12V, 24V, 48V Input Combo DB-15 KVM Usage Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA... - Page 23 The company reserves the right to modify product specif cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2013 Austin Hughes Electronics Ltd. & Eclipse Rackmount, Inc. All rights reserved. Manual ML43V02A -- www.EclipseRackmount.com...
