Summary of Contents for Geemarc LoopHEAR 101

  • Page 1 Connevans.info Solutions to improve the quality of life This product may be purchased from Connevans Limited DeafEquipment.co.uk secure online store at www.DeafEquipment.co.uk...
  • Page 2 LoopHEAR Easy set-up Induction Loop English...

  • Page 3: Table Of Contents

    CONTENTS CONTENTS .............. 2 INTRODUCTION ............3 Unpacking the LoopHEAR ........3 DESCRIPTION ............5 INSTALLATION ............7 Setting Up ..............7 Locating the LoopHEAR ........10 USING THE LoopHEAR ........11 Turn the LoopHEAR On ......... 12 Turn the LoopHEAR Off.........

  • Page 4: Introduction

    INTRODUCTION Congratulations on purchasing your Geemarc LoopHEAR This is a portable induction loop system that can be used in a variety of locations, both public and private. This tough but light unit is easily transported and an integral battery enables it to be freestanding. This battery is both replaceable and rechargeable and long usage can be expected (up to 24 hours).

  • Page 5: Unpacking The Loophear Tm

    INTRODUCTION Unpacking the LoopHEAR When unpacking the LoopHEAR , you should find the following in the box: • 1 LoopHEAR • 1 power adaptor/charging Unit. There are several country specific power adaptor/charging units. The one supplied is dependant on country of purchase. Europe version –...

  • Page 6: Description

    DESCRIPTION General Description Front View Magnetic field strength LED Indicator Rear View Power ON , field strength and battery status LEDs See below Fig A...
  • Page 7 DESCRIPTION Rear View (Fig A) Headset Volume DC Power EXT mic jack Headset/ Receiver jack ON/OFF switch Audio IN jack Base View Removable Base Plate...

  • Page 8: Installation

    INSTALLATION Setting Up Battery Charging Remove the base plate from the unit as shown below: See Fig. B for further detail Insert a screwdriver into the opening of the catch mechanism. This is found on the bottom right of the base plate. Push the catch gently with the screwdriver - this will release the base plate.
  • Page 9 INSTALLATION Fig B Opening of the catch mechanism Remove the battery door. Insert the supplied rechargeable battery, plug the connector into the socket and replace the battery door.
  • Page 10 INSTALLATION Replace the base plate by placing the hook found on the bottom left of the LoopHEAR into the catch on the base plate. Press the LoopHEAR down gently until you hear a click.: Hook Catch Plug the power cable into the power socket found on the rear of the unit.

  • Page 11: Locating The Loophear Tm

    INSTALLATION Please use the strain relief mechanism as displayed. This provides extra protection for the cable at the connection point. It will extend the life of the power cable and reinforce the connection to the equipment. The LoopHEAR will need to charge for 4 hours before its first use.

  • Page 12: Using The Loophear Tm

    USING THE LoopHEAR FIXING THE HAND HELD Listener HOLDER The hand held listener holder can be attached to the LoopHEAR on the left hand side or the right hand side, depending on where it would be convenient for use. In order to fix the attache the reveiver holder: 1.

  • Page 13: Turn The Loophear Tm On

    USING THE LoopHEAR Turn the LoopHEAR Turn the power switch found at the rear of the unit to the I position. The power indicator lights up (solid green if the power adaptor is not plugged in, blinking green if it is plugged in). When the battery is weak, the indicator will light up red (solid red if the power adaptor is not plugged in, blinking red if it is plugged in).

  • Page 14: Using The External Microphone

    USING THE LoopHEAR Using the External Microphone Plug the supplied desktop microphone into the MIC JACK at the back of unit. The external microphone will now override the built-in microphone. The magnetic field LED indicator will light up bleu when you speak to the built-in microphone or external microphone.

  • Page 15: Troubleshooting

    TROUBLESHOOTING The RED LED is flashing • Charge the battery The LoopHEAR keeps on switching off • Make sure that the batteries are fully charged You cannot hear clearly due to interference or you cannot hear at all • .Make sure the LoopHEAR is switched on and facing you •...

  • Page 16: Safety Information

    SAFETY INFORMATION General Do not open the unit. Contact the helpline for all repairs. Cleaning Clean the LoopHEAR with a soft cloth. Never use polish or cleaning agents - they could damage the finish or the electronics inside. Environmental Do not expose to direct sunlight. Always ensure there is a free flow of air over the surfaces of the LoopHEAR Do not place any part of your product in water and do not use it...

  • Page 17: Guarantee

    (at our discretion) are free of charge. Should you experience a problem then contact our help line or visit our website at www.geemarc.com. The guarantee does not cover accidents, negligence or breakages to any parts.

  • Page 18: Recycling Directives

    - Or, hand the old product to the retailer. If you purchase a new one, they should accept it. Thus if you respect these instructions you ensure human health and environmental protection. For product support and help visit our website at www.geemarc.com Telephone 01707 384438 Or fax 01707 832529...
  • Page 19 UGLoopHEAR101_En_V0.3...
