Casio CDP-200R Service Manual & Parts List page 16

1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
N Item Parts NO.
55 10175759 PACKING
N 56 10175758 PACKING
57 10209204 PACKING
58 10216009 PACKING
N 59 10209203 PACKING
60 69321322 PACKING
61 10268012 FERRITE CORE
N 62 69264590 SPONGE
Key board assy
63 10294094 PCB ASSY/KEY/RUBBER TK-RJM506061*003
N D801-D888 10294400 DIODE
64 37195442 CABLE
65 10133656 RUBBER/CONATCT/AG
66 10133635 RUBBER/CONATCT/GC
67 10135317 BLACK KEY
68 10135426 WHITE KEY/CEGB
69 10135427 WHITE KEY/DFA
70 10135428 WHITE KEY/B
71 10135429 WHITE KEY/SA
72 10135430 WHITE KEY/SC
73 10208265 HAMMER ASSY/W1
74 10208266 HAMMER ASSY/W2
75 10208267 HAMMER ASSY/W3
76 10208269 HAMMER ASSY/W4
77 10208275 HAMMER ASSY/B1
78 10208281 HAMMER ASSY/B2
79 10208286 HAMMER ASSY/B3
80 10208290 HAMMER ASSY/B4
N 81 10310740 CHASSIS ASSY
N 82 10311215 CUSHION/HAMMER
N 83 10310741 CASE ASSY/LOWER
N 84 10314506 KEY ASSY
ACCESSORY
- 10133504 PEDAL ASSY
- 10303050 AC ADAPTOR
- 10303048 AC ADAPTOR
- 10303049 AC ADAPTOR
N - 10306488 STAND/MUSIC
*1 : Three kinds of plugs(Euro, Austrailia, Korea) are bundled.
Parts Name Specification
RJM504745-001V01
RJM504744-001V01
RJM506160-001V01
RJM506422-001V01
RJM506157-001V01
M441333-1
K5ARH16X9X17
M440564-1
LM1MA142WKT1G
N30315B1B05-UL2896
RJM502920-001V01
RJM502921-001V01
RJM502797-001V01
RJM502862-001V01
RJM502863-001V01
RJM502794-001V01
RJM502795-001V01
RJM502796-001V01
TK-RJM506035*001
TK-RJM506036*001
TK-RJM506037*001
TK-RJM506038*001
TK-RJM506039*001
TK-RJM506040*001
TK-RJM506041*001
TK-RJM506042*001
TK-RJM506053*007
RJM509043-001V01
TK-RJM505967*005
TK-RJM506464*007
TK-RJM503195*001
AD-12ML(E)-FC1(D)
AD-12ML(U)-FC1(D)
AD-12MLGKA-FC1(D)
RJM508666-001V01
– 14 –
Q'TY Price
Code
1 2 3 4 5
5 5 5 5 5 AA
1 1 1 1 1
4 4 4 4 4 AA
4 4 4 4 4 AA
1 1 1 1 1
4 4 4 4 4 AA
1 1 1 1 1 AX
1 1 1 1 1 AA
1 1 1 1 1 CU
88 88 88 88 88
1 1 1 1 1 AO
7 7 7 7 7 AK
1 1 1 1 1 AG
36 36 36 36 36 AC
7 7 7 7 7 AT
7 7 7 7 7 AQ
1 1 1 1 1 AG
1 1 1 1 1 AJ
1 1 1 1 1 AJ
13 13 13 13 13 AF
13 13 13 13 13 AF
13 13 13 13 13 AF
13 13 13 13 13 AF
9 9 9 9 9 AE
9 9 9 9 9 AE
9 9 9 9 9 BJ
9 9 9 9 9 AE
1 1 1 1 1
1 1 1 1 1 BI
1 1 1 1 1
1 1 1 1 1
1 1 1 1 1 BN
1 DE
1 1 CW
1 1 DE
1 1 1 1 1
R Remarks
X
X
X
X
X
X
C
X
C
X
C
B
B
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
A
C
C For UK
C For US
C *1
C
