Using the MICOM GPS Receiver

Table of Contents

Introduction................................................................................................................... 1
GPS Receiver Functions ................................................................................................. 2
Format of GPS Information........................................................................................ 2
GPS Antenna ................................................................................................................. 3
Antenna Description ................................................................................................. 3
Selecting a Proper Location for the GPS Antenna ...................................................... 3
Installing the GPS Antenna ........................................................................................ 3
Operating the GPS Receiver........................................................................................... 4
GPS Menu ................................................................................................................ 4
First-Time Operation................................................................................................. 5
Operating Instructions ............................................................................................... 5
Sending Your Position/GPS Position Requests ............................................................ 6
What to do if ........................................................................................................... 7

Introduction

This Supplement to the "MICOM-2E/2R ALE HF-SSB Transceiver Owner's Guide", Publication
68P02952C60-A, provides you with information on the GPS receiver, an option for the new versions
(Version CK) of the MICOM-2E/2RS/2TS ALE HF-SSB transceivers models which is not documented in
the Owner's Guide.
Note
MICOM transceivers equipped with an internal GPS receiver have a connector for
the GPS antenna on their rear cover.
The information appearing in this Supplement is intended for use with the following publications:
•
Owner's Guide, MICOM-2E/2RS/2TS ALE HF-SSB Transceivers, Publication 68P02952C60-A.
•
Supplement to Owner's Guide, MICOM-2ES/2RS/2TS ALE HF-SSB Transceivers, Publication
6886872J01.
IMRMB007
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS Receiver and is the answer not in the manual?

Questions and answers

Summary of Contents for Micom GPS Receiver

  • Page 1 This Supplement to the “MICOM-2E/2R ALE HF-SSB Transceiver Owner’s Guide”, Publication 68P02952C60-A, provides you with information on the GPS receiver, an option for the new versions (Version CK) of the MICOM-2E/2RS/2TS ALE HF-SSB transceivers models which is not documented in the Owner’s Guide.

  • Page 2: Gps Receiver Functions

    8 satellites to improve accuracy). Therefore, after turning a GPS receiver on for the first time after a long period of inactivity, it is essential to let the GPS receiver operate continuously for at least 15 minutes, to enable it to collect updated almanac data.

  • Page 3: Gps Antenna

    (e.g., fiberglass). The antenna connects to the GPS connector of the MICOM transceiver through a 5-meter (15 feet) long coaxial cable, which is part of the antenna. This cable carries both DC power for the antenna, and the received GPS signals.

  • Page 4: Gps Menu

    ➤ Place the antenna in the selected place, and make sure it attaches well to the surface. Route the cable to the rear side of the MICOM transceiver, and if required, secure the cable at several places. Connect the coaxial connector of the antenna cable to the MICOM GPS connector.

  • Page 5: Operating Instructions

    The internal GPS receiver is always powered when the transceiver is turned on. Therefore, if the GPS antenna is connected and you are in a good place with a clear view of the sky, the GPS receiver can start the satellite acquisition process as soon as the transceiver is turned on, and can then track the satellites continuously.

  • Page 6: Sending Your Position/Gps Position Requests

    You can use the ALE AMD service to: 1. Send your position to any another destination (including one-to-many). 2. Request the position of another MICOM transceiver equipped with the optional GPS receiver. You can make this type of request only when you call an individual station: •...

  • Page 7: What To Do If

    You should see the GPS receiver type. • If you see UNKNOWN, turn the MICOM transceiver off and after a few minutes turn it back on. If the problem persists, the GPS receiver must be serviced. •...
  • Page 8 IMRMB007...
