INSTALLATION AND OPERATION
INSTRUCTIONS
MODEL: GRL-850-AU
Approval Number 5837
1
2011-900D 4/04
Advertisement
Table of Contents
Summary of Contents for Heat-N-Glo GRL-850-AU
- Page 1 THIS MANUAL MUST BE USED FOR INSTALLATION AND RETAINED BY HOMEOWNER FOR OPERATION AND MAINTENANCE. HEAT-N-GLO, a brand of Hearth & Home Technologies Inc. 20802 Kensington Boulevard, Lakeville, MN 55044, U.S.A. • (952) 985-6000 This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322; 4,852,548; 4,875,464;...
- Page 2 Failure to follow these installation instructions may result in a possible fire hazard and will void the warranty. Save this Manual for future reference. Copyright 2004 Heat-N-Glo, a brand of Hearth & Home Technologies Inc. 20802 Kensington Boulevard, Lakeville, MN 55044, U.S.A. Printed in U.S.A.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ......................5 ASSEMBLY.........................5 GAS LINE CONNECTION ..................6 LOG PLACEMENT ....................7 OPERATING GUIDELINES AND MAINTENANCE INSTRUCTIONS ....10 SAFETY INFORMATION..................11 LIGHTING INSTRUCTIONS ..................12 REPLACEMENT PARTS: ..................13 WARRANTY POLICY ....................15 u = Contains updated information. - Page 4 FRONT SURROUND PILOT ASSEMBLY REAR SURROUND BURNER PIEZO IGNITOR DECORATIVE FRONT SIDE CONTROL SURROUND ACCESS COVER ON/OFF SWITCH VALVE TOP VIEW - FIREPLACE AREA DEPTH TOP VIEW NOTE: Unit must be 33mm back from WIDTH fireplace front. 33mm MINIMUM FIREPLACE OPENING Minimum Maximum WIDTH:...
-
Page 5: Introduction
CAUTION: DO NOT PLACE ARTICLES ON OR INTRODUCTION AGAINST THIS APPLIANCE. Model GRL-850-AU Gas Log Sets are Decorative Gas CAUTION: DO NOT USE OR STORE FLAMMABLE Appliances for Installation in a Solid-Fuel Burning Fire- MATERIALS NEAR THIS APPLIANCE. place. Minimum fireplace size for GRL-850-AU: height 425mm, width 850mm, depth 300mm. -
Page 6: Gas Line Connection
E. NOTE: An Optional Remote Control Kit and Wall A. Inlet gas supply pressure for purposes of input ad- Switch Kit , for turning the burner ON/OFF are avail- justment, shall be 6.0 inches w.c. (1.5kPa) for natu- able. Detailed installation instructions are found in ral gas and 11 inches w.c. -
Page 7: Log Placement
LOG PLACEMENT Log Set Assembly: GRL-850-AU-LOGS INSTRUCTIONS Model: GRL-850-AU STEP 1: Attach grate to as- sembly by sliding hooks into open- FRONT ings on the front surround. SURROUND PILOT ASSEMBLY REAR SURROUND BURNER PIEZO STEP 2: IGNITOR Ensure that tabs on... - Page 8 STEP 3: LOG #1 (SRV2011-707) Put log #1 behind the locating tab on the right rear corner and up against the locating tab in the center. STEP 4: LOG #2 (SRV530-717) Place log #2 on the left front corner of the grate using its locating groove and tab. STEP 5: LOG #3 (SRV2011-703) Place log #3 onto the center of the burner using its locating tabs and slot.
- Page 9 STEP 6: LOG #4 (SRV568-706) Rest log #4 in the front right hand side between log #3 and the right edge of the set. STEP 7: LOG #5 (SRV720-722) Rest log #5 on log #2 and rest the top in the grove on log #1. 248mm STEP 8: LOG #6 (SRV347-712) Place log #6 in the groove on top of log #1 with its front on log #2.
-
Page 10: Operating Guidelines And Maintenance Instructions
STEP 9: LOG #7 (SRV571-707) Place log #7 in the groove on log #1 with its front resting on log #4. OPERATING GUIDELINES AND Note to Installer: Disconnect this appliance and ad- MAINTENANCE INSTRUCTIONS vise owner if any spillage or abnormal operation oc- Upon completing the gas line connection, a small curs which can't be rechecked immediately. -
Page 11: Safety Information
SAFETY INFORMATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROP- ERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. This appliance has a pilot which must be lighted C. -
Page 12: Lighting Instructions
LIGHTING INSTRUCTIONS LIGHTING INSTRUCTIONS 1. "STOP!" Read the safety information on previous PILOT ASSEMBLY page. 2. Remove the control access cover. 3. Turn the valve control knob to the "OFF" position. To do this, you must turn the knob clockwise to the "Pilot"... - Page 13 GRL-850-AU Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-2003 Ending Manufacturing Date: ________ 13 Log set assembly Part number list on following page.
-
Page 14: Replacement Parts
4.0 REPLACEMENT PARTS: GRL-850-AU When requesting service or replacement parts for your decorative gas log set, please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. ITEM Description SERIAL #... -
Page 15: Warranty Policy
3. HEAT-N-GLO will replace or repair a defective firebox or heat exchanger, at any time during the 10 years from the date of installation. The decision whether to replace the defective component shall be made at HEAT-N- GLO’s sole discretion.
