SenseView Duo
User Guide
Distributed in the U.S. by:
GW Micro, Inc.
TEL: (260) 489-3671
FAX: (260) 489-2608
E-mail:
support@gwmicro.com
http://www.gwmicro.com/cctv

Advertisement

loading
Need help?

Need help?

Do you have a question about the SenseView Duo and is the answer not in the manual?

Questions and answers

Summary of Contents for GW Micro SenseView Duo

  • Page 1 SenseView Duo User Guide Distributed in the U.S. by: GW Micro, Inc. TEL: (260) 489-3671 FAX: (260) 489-2608 E-mail: support@gwmicro.com http://www.gwmicro.com/cctv...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. SenseView Duo Package ..1 2. General Instructions..... 1 3. Configuration ......2 4. How to Use Each Function .. 7 5. Technical Specifications ..18 6. Digital Zoom Rate Table ..19 7. Warranty ......20...

  • Page 5: Senseview Duo Package

    1. SenseView Duo Package Thank you very much for choosing the SenseView Duo. Please check to make sure the following items are included in the SenseView Duo Package: (A) SenseView Duo (B) AC power adapter (C) Bag (D) Strap (E) User guide 2.

  • Page 6: Configuration

    all servicing questions to qualified service personnel only. 3. Configuration...
  • Page 7 (A) Power on/off switch You can turn the SenseView on by sliding the switch into the opposite direction of DC-in and turn off by sliding once more. (B) Close-up & handwriting camera indicator The lamp turns on when close-up & handwriting camera is selected, and flickers in the power-saving mode.
  • Page 8 handwriting camera or distance camera by moving the switch to the desired side. (H) Zoom-in/out button You can change the magnification rate with 10 levels. Detailed magnification rate at each level is explained in the Digital Zoom Rate Table section. (I) Color mode button You can change colors on the LCD with 7 different combinations in the close-up...
  • Page 9 can be seen as brightened and changed colors. 1. Full color 2. Enhanced color (close-up camera only) 3. Black on white background 4. White on black background 5. Yellow on black background 6. Yellow on blue background 7. Blue on white background (J) Brightness button You can change the brightness on the LCD with 4 different levels.
  • Page 10 (M) Panning/selection key This key has 5 buttons: right, left, up, down and center. After you press Menu button(L), you can navigate among following functions: 1. Open the stored images one by one 2. Erase the stored images 3. Close-up camera light on/off 4.

  • Page 11: How To Use Each Function

    the battery here. To avoid electrical damage, please use the supplied AC power adapter only. (Q) Strap hole (R) Lamp for handwriting mode 4. How to Use Each Function (1) Power on/off You can turn the power on by sliding the Power on/off switch (A) into the opposite direction of DC-in and turn the power off by sliding it once more.
  • Page 12 at the object from 1m. As you rotate the knob into the right position, you can look at the object further away. <Figure 1> (3) Close-up & handwriting camera select close-up handwriting camera sliding Camera selection switch (G) to the right. (4) Reading mode/handwriting mode Select the handwriting mode by tilting the close-up camera, like in Figure 2.
  • Page 13 (5) Image storing You can capture the image which you are looking at by pressing the Image capture button (K). You can store the captured image by pressing and holding this button once more for more than 1.5 seconds. If you do not want to store the captured image, press this button again for less than 1.5 seconds.
  • Page 14 2. Move to the following icon – Figure 3 - for opening the stored images by pushing the Panning/selection key (M) to the right or left direction. <Figure 3> 3. Press the center of Panning/selection key (M). Then you can find an image which is stored most recently.
  • Page 15 to the normal viewing mode. (7) Erasing pictures You can erase the stored images by doing the following in order: 1. Move to a picture to erase as explained in the ‘Opening saved image’. 2. Press the Menu button (L). 3.
  • Page 16 After deleting an image, you can delete more images on the screen by continuing to press the center of the Panning/selection key (M).You will hear an alarm sound and/or see a flickering 00 when there are no stored images to delete. 6.
  • Page 17 4. You need to slide the Power on/off switch (A) again if you want to wake the SenseView Duo up after auto power-off. (10) Battery status 1. You can check battery status by...
  • Page 18 AC adapter is not connected. <Figure 5> 3. Please connect the supplied AC power adapter to charge the unit when the battery status flickers, like as in Figure 6. <Figure 6> 4. The battery status is in red, like as in Figure 7, when this unit is being recharged by connecting the AC power adapter to the DC-in.
  • Page 19 <Figure 8> (11) Close-up camera light on/off You can turn the close-up camera light on or off by doing the following: 1. Press the Menu button (L). 2. Move to the following icon - Figure 9 - close-up camera light-off pushing the Panning/selection key (M) to the right or left direction.
  • Page 20 <Figure 10> 5. Press center Panning/selection key(M) to turn the light on. (12) Sound on/off You can turn the sound on or off by doing the following: 1. Press the Menu button (L). 2. Move to the following icon - Figure 11 for sound-off by pushing the Panning/selection key (M) to the right or left direction.
  • Page 21 pushing the Panning/selection key (M) to the right or left. <Figure 12> 5. Press center Panning/selection key (M) to turn the sound on. (13) Storage capacity You can check available storage capacity for storing images by doing the following in order: 1.

  • Page 22: Technical Specifications

    be stored. 4. Press Menu button (L) twice to return to the normal viewing mode. 5. Technical Specifications (A) LCD: 4.3 inch WQVGA TFT LCD (16:10 wide type) (B) Magnification rate: 3x ~ 13x (close-up camera) (C) Brightness: 4 levels (D) Color mode: 7 color modes 1.

  • Page 23: Digital Zoom Rate Table

    (H) Size(W*D*H) : 17.8 x 7.8 x 2.8cm 7” x 3” x 1.1” (I) Weight : 261g, 0.57lb 6. Digital Zoom Rate Table (A) Close-up camera Zoom Level Digital Zoom Rate Level 1 3.2x Level 2 3.8x Level 3 4.6x Level 4 5.4x Level 5...

  • Page 24: Warranty

    Level 2 1.2x Level 3 1.4x Level 4 1.7x Level 5 2.0x Level 6 2.3x Level 7 2.5x Level 8 2.9x Level 9 3.4x Level 10 4.1x Digital zoom rate relative magnification rate which is compared with the zoom level 1 on the screen. 7.

  • Page 25: Fcc Warning

    8. FCC Warning NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation.
