Elan HD series Homeowner's Information Manual

Hide thumbs

Table of Contents

Quick Links

SERIES

Homeowner's

Information

Inside:

Safety & User Info........................Page 2-4

Introduction & System Overview .....Page 5-6

Using Your HD System ..............Page 6-19

Features .....................................Page 6-7

System Control........................ Page 8-12

ELAN Telecommunicatons .....Page 13-18

Telephone Guide .........................Page 19

Key Map Tables ......................Page 20-22

Other Fine ELAN Products ..........Page 23

Warranty ..................................Back Cover

Table of Contents

Need help?

Do you have a question about the HD series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elan HD series

Page 1: Table Of Contents
Introduction & System Overview ..Page 5-6 Information Using Your HD System ....Page 6-19 Features ........Page 6-7 System Control......Page 8-12 ELAN Telecommunicatons ..Page 13-18 Telephone Guide ......Page 19 Key Map Tables ......Page 20-22 Other Fine ELAN Products ..Page 23 Warranty ........Back Cover...
Page 2: Safety & User Info
—The appliances should be connected to a power supply only of the type described in the operating instructions or as marked on each appliance. If you are not sure of the type of power supply to your home, consult your authorized ELAN dealer or local power company.
Page 3 —Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning. Do not use a telephone to report a gas leak if the leak is in the vicinity of the ELAN electronic equipment because of risk of fire or explosion.
Page 4: Important User Information
If you experience trouble with this telephone equipment, please contact ELAN TECHNICAL SUPPORT at 1-800-622-ELAN (3526) for information on obtaining service or repairs. The telephone company may ask that you disconnect this equipment from the network until the problem has been corrected or until you are sure the equipment is not malfunctioning.
Page 5: Introduction & System Overview
Nook). Series HD’s flexible programming options allow each zone to be custom-tailored depending on the use of the room. For example, in the Family Room ELAN paging and doorbell are enabled and their volume levels programmed accordingly, while in the Nursery page and doorbell have been disabled.
Page 6: Using Your Hd System
USING YOUR HD SYSTEM This section details the control of your system using ELAN’s in-wall keypads and hand held remotes; but first there are a few ELAN features you need to become familiar with ..WHOLE-HOUSE MUSIC Whole-House Music is a feature that can make your entire home come alive with music.
Page 7 DO-NOT-DISTURB (DND) When a zone is in Do-Not-Disturb, ELAN Page and Doorbell audio will not be allowed into that zone, nor will the Telemute or Whole-House Music features be activated in that zone.
Page 8: System Control
Learning IR system, which learns the commands from your components original remote controls into the MCU and then reissues these commands at the request of an ELAN keypad or Hand Held Remote. With the exception of ELAN System Commands such as VOLUME UP/DOWN, MUTE, ZONE ON/OFF, etc., any...
Page 12 Basic system control is also available from the front panel of the MCU. More importantly, there are numerous LED indicators on the front panel that can tell you the status of certain ELAN features and the status of a particular zone.
Page 13: Elan Telecommunicatons
ELAN features will be inactive. MULTIPLE PHONE LINES Only one telephone line will run to your ELAN system and carry your ELAN telecommunication features. Should you have multiple phone lines coming into your home, choose the one that you would most like to have these features on.
Page 14: Telephone Features
• You can mute the music with a #, M (6) As you can see, the # key on your telephone is used to initiate all the ELAN phone features. Should you have a security system in your home that also...
Page 15 • Press # again. This reconnects you with the caller, who you can now ask to hold on until the person you paged picks up. Now, press #, H (4). This puts the caller back on HOLD without initiating any ELAN features. You can now hang up the phone. When the person you paged picks up any phone in the house the caller will automatically be there.
Page 16 Zone-Specific Muting : #, M, 0, 1 will mute Zone 1, while #, M, 1, 1 will mute Zone 11. #,9 BYPASS Pressing #,9 bypasses your ELAN system. This feature will come in handy when: • Dialing out to an automated service that requires the use of a “#” to enter information (i.e.
Page 17 DOOR SPEAKER COMMUNICATIONS ELAN Door Speaker Assemblies provide you with two-way communications and door latch activation via your telephones, as well as ELAN’s whole house door chime, which is heard through the speakers throughout your home. WHOLE HOUSE DOOR CHIME When someone presses the doorbell button located on the ELAN Door Speaker Assembly, ELAN’s two or three note door chime will be transmitted...
Page 18 Your HDC1050 Telephone Interface Card has two different doorbells–– a 3-note chime and a 2-note chime––enabling you to distinguish between, for example, front and back doors. Up to six more ELAN door stations or doobell buttons, each with their own distinct electronic tone, can be added to your system via the HDC2042 Automation Control Card’s six sets of Sense...
Page 19: Telephone Guide
Note: If you have a caller on the line and you activate any of the ELAN features, the caller is automatically placed on hold. Note: If other systems in your home (i.e. security) require the use of the...
Page 20: Key Map Tables
H O M E O W N E R S I N F O R M A T I O N TO BE FILLED OUT BY YOUR INSTALLER: HDP1000 SOURCE CONTROL KEY MAP HDP2000/3000 SOURCE CONTROL KEY MAP © 1998. ELAN HOME SYSTEMS. All Rights Reserved H O M E S Y S T E M S...
Page 22 H O M E O W N E R S I N F O R M A T I O N TO BE FILLED OUT BY YOUR INSTALLER: HDR2000 HANDHELD REMOTE CONTROL SOURCE CONTROL KEY MAP © 1998. ELAN HOME SYSTEMS. All Rights Reserved H O M E S Y S T E M S...
Page 23: Other Fine Elan Products
ELAN speakers are well-matched with your system electronics, interior design, and ultimately..your critical listening requirements. And consider ELAN’s line of in-wall IR receivers and volume controls when a keypad is not quite what you want..or what you need. The ELAN patented “override”...
Page 24: Limited Warranty
ELAN installer, (c) to installed equipment which is not installed to ELAN’s specifications, (d) to equipment which shall have been repaired or altered by others than ELAN, (e) to equipment which shall have been subjected to negligence, accident, or damage by circumstances beyond ELAN’s control, including, but not limited to, lightning, flood, electrical surge, tornado, earthquake,...
