Summary of Contents for Rinex WR900
-
Page 1: User Manual
WR900 repeater User Manual Part Number: 1-1336 Revision Draft – 1 Issue Date: AUGUST 2008... - Page 2 12Vdc power cable Figure 1. WR900 repeater components 1. INTRODUCTION The WR900 repeater is designed for use with the mojoRTK system to extend the range of the console (tractor) from the base station. The mojoRTK and WR900 modems incorporate intelligent message addressing so that the console may receive messages from either the base station and/or repeater directly without conflict.
- Page 3 1-1336 Rev Draft – 1 WR900 repeater user manual...
- Page 4 2. Screw the RF adapter to the WR900 and secure finger tight. 3. Mount the WR900 as required with the antenna mounted vertically at the top of the WR900. Bare in mind that the WR900 must be “in line of sight” with the mojoRTK base station and vehicle. Hence the...
- Page 5 3. OPERATION If the WR900 has been installed in accordance with the steps above the system is operational. Note, the user must confirm that the Red power LED is operational. The mojoRTK base station and MojoRTK console must be set to Channel 5.
