Summary of Contents for Qual GTR Multifunctional Model Car
-
Page 1: User Manual
GTR Multifunctional Model Car Bluetooth Speaker User Manual... - Page 2 Thank! Thank you for purchasing this GTR Bluetooth Speaker. This product is the newest generation of Bluetooth stereo speakers which can provide you high quality bass effect and musical pleasure.
- Page 3 Cautions Before using this product, please read this part and the rest of the instruction sheet thoroughly, to ensure safety and proper usage. Be careful with the product’s edge, concave and convex parts, metal parts and packaging materials to avoid any possible damage or injury. Do not place this product at where children and infants can access or touch, and avoid the product or part of the product being put into their mouths.
-
Page 4: Package Contents
Package Contents GTR Bluetooth Speaker Gas station power adapter... - Page 5 Main Part Diagram / Front...
- Page 6 Main Part Diagram / Back...
- Page 7 Main Part Diagram / Mic & Speaker...
- Page 8 Main Part Diagram / Car top...
- Page 9 Main Part Diagram...
- Page 10 Main Part Diagram Main switch Signal Light Blue Tooth Pairing Indicator) Headlight (Work Status Indicator) Tail Light(Charging Indicator) Fuel Tank Cover (Charging Hole) Speaker Car Top (Play, Pause, Pickup Call, Hang up, Bluetooth Sensing) DC Plug Battery Indicator AC Plug...
-
Page 11: Operating Procedures
Operating Procedures Turning on and Bluetooth automatically pairing- Switch on electricity, then engine will sound off and the two Headlights(white) will flash slowly. Bluetooth will be automatically turned on after activation. If no mobile phone’s Bluetooth is detected within 15 seconds, Bluetooth Speaker will automatically get into pairing status. - Page 12 Operating Procedures Charging: 30 seconds after Bluetooth Speaker is on, if you hear “Dong, Dong” sound it means its battery level is low. Please charge it as soon as possible. To charge, connect the AC Plug to your AC supply, then open the Fuel Tank Cover and plug in the DC Plug.
-
Page 13: Product Specifications
Product Specifications Item Specification Remarks Sound Built-in Stereo System Speaker Power 2 x 3W Frequency Response 150Hz -20kHz Speaker 40mm / 4Ω Signal-To-Noise Ratio > 75dBA Distortion (%) < 1.0% Max play Duration About 10 hours Battery Type Lithium Battery Battery Capacity 1200mAh Charging Voltage... -
Page 14: Frequently Asked Questions
Frequently Asked Questions Why does the Bluetooth Speaker show “low battery” when I turn it on? Make sure battery is fully charged. Before turning it on for the first time please charge it for more than 8 hours till the red Tail Lights are off. Why does the Speaker have no sound after Bluetooth has finished pairing up? First please check if your equipment has successfully paired up with the Bluetooth Speaker. - Page 15 Copyright © 2013 Qual.
