INSTALLATION GUIDE
CONGRATULATION WITH YOUR NEW MIB MediaButler.
The MIB MediaButler (in everyday language MIB)
is used for playing music and videos.
Amuseic Denmark is the supplier of the MIB.
In case of questions please contact Amuseic's
support team at phone number +45 38322440.
The received package consists of:
2
7
1
1
5
2
4
3
4
5
3
6
6
7
MIB (computer)
Network cable
Multi-monitor cable
Power supply for the MIB
Cable for the power supply
Video cable (composite)
Adapter (DVI to VGA plug)
- only used by connection
of monitors with VGA
cables.
1
Advertisement
Summary of Contents for Amuseic MIB MediaButler
-
Page 1: Installation Guide
INSTALLATION GUIDE CONGRATULATION WITH YOUR NEW MIB MediaButler. The MIB MediaButler (in everyday language MIB) is used for playing music and videos. Amuseic Denmark is the supplier of the MIB. In case of questions please contact Amuseic’s support team at phone number +45 38322440. - Page 2 Yoga mini-amplifier (HA-04) - consisting of a, b, c, d & e: Yoga mini-amplifier Sound cable (MIB to Yoga) Sound cable (Yoga to sound system) Power supply for the Yoga Adapter (phono to jack plug) - not needed for the installation...
- Page 3 Connections – step by step Place the MIB in the area of your sound system (amplifier). Your amplifier is generally the unit whereby the volume control is placed. Picture I Connect the network cable to the MIB. The other end of the cable is connected to the Internet just like your own computers (back-office computer etc.) and credit card machines.
- Page 4 Connect the power supply to the MIB. The cable is plugged into the power supply and plugged in a socket (power grid). Picture IV Turn on the MIB by a single press on the power button on the front (see arrow in picture V).
- Page 5 Now it is time to connect the MIB to your sound system NB! Turn off you sound system / amplifier before you continues! Bestsellers stores usually uses an amplifier of the brand ”Harman Kardon”. Picture VI indicates the location of the power button (on/off).
- Page 6 Connect the sound cable to one of the Yoga’s sound output channels. You can use any of the four channels ”CH-(1-4)” . The chosen channel has to be turned to ”MAX” (see arrow on picture IX). Picture IX Connect the other end of the sound cable to the ”AUX”...
- Page 7 Like a DVD-player the MIB can be used to play videos that can be shown on monitors installed at the location. Connect the cable from the monitor(s) to one of the MIB’s video-plugs. Possible connections:: Plug: Quality: Composite Standard S-Video Good Component (Y, Pb, Pr) Better...
- Page 8 You can create a remote control for the MIB from your back- office computer. Please follow the steps below to install the program: ”MIB-finder" Download the program ”MIB-finder” via Internet Explorer from the link below: http://www.amuseic.com/MIBButlerResolve110.zip Picture web1 Click on ”Save”. Picture web2 Choose ”Desktop” in the field ”Save in” and click on ”Save”.
- Page 9 Go to your desktop and right-click on the downloaded file ”MIBButlerResolve110.zip” Select ”extract all”. Hereafter the window shown in picture web4 appears. Click on ”Next >”. Picture web4 Click on ”Next >”. Picture web5 Click on ”Finish”. Picture web6...
- Page 10 A new folder called ”MIBButlerResolve110” has been created on your desktop. Open this folder (double-click on it). Find the file ”MIBButlerResolve.exe” and run it by double-clicking on it. Picture web7 If the warning shown in picture web8 appears then click on ”Run”. Picture web8 Now the program will search (scan) for a connection to the MIB.
- Page 11 IMPORTANT Please follow the below mentioned instructions carefully in order not to damage the equipment while using it. Location The MIB must never be placed in a manner or place in which it is subjected to high temperatures. As an addition to this, please avoid the following: ·...
- Page 12 Support Should any questions occur in connection with the installation or use of the MIB please visit the Amuseic website where you can find frequently asked questions plus answers and other types of information: http://www.amuseic.com/support In case of questions left unanswered please call our technical service at phone number +45 38322440.
