BTS 630, 635
9.2

Starting up

9.2.1
Performing preparations
1. Set down the machine such that the cutting blade can rotate freely.
2. Set the multifunction lever to the appropriate position.
3. Press the fuel pump bellows repeatedly until the bellows is completely filled
4. Actuate the decompression valve.
Item
Designation
1
Fuel pump
2
Decompression valve
Cold engine: Position "choke".
Warm engine: Position "I".
with fuel.
If you detect resistance when pressing, move the decompression valve back
and forth a bit.
When the engine is running, the decompression valve returns to its original
position.
Operator's manual
9 Use and operation
43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTS 630 and is the answer not in the manual?

Questions and answers

Related Manuals for Wacker Neuson BTS 630

Summary of Contents for Wacker Neuson BTS 630

  • Page 1 BTS 630, 635 9 Use and operation Starting up 9.2.1 Starting the engine Performing preparations Item Designation Fuel pump Decompression valve 1. Set down the machine such that the cutting blade can rotate freely. 2. Set the multifunction lever to the appropriate position.
  • Page 2 9 Use and operation BTS 630, 635 Bringing the throttle lever into the start position Item Designation Item Designation Throttle lever lock Lock button Throttle lever 1. Press and hold the throttle lever lock and the throttle lever. 2. Press the lock button.
  • Page 3 BTS 630, 635 9 Use and operation Starting the engine NOTICE Improper handling can damage the machine. f Do not pull the starter rope as far as it can go. f Let starter rope slowly roll back in. CAUTION Incorrect handling during starting can result in minor injuries.
  • Page 4 9 Use and operation BTS 630, 635 4. Pull the starter rope with force, but not suddenly. When you first hear the engine ignite, move the multifunction switch from the "Choke" position to the "I" position. If necessary, actuate the decompression valve once again.
  • Page 5 BTS 630, 635 9 Use and operation Operating the machine Note: When cutting, lightly pressing the cutting blade against the cutting material produces a very pleasant vibration response as well as a particularly narrow cut. Holding and guiding the machine WARNING Injuries from insufficiently guided or uncontrolled machine.
  • Page 6 9 Use and operation BTS 630, 635 Decommissioning Switching off the machine Item Designation Multifunction switch Throttle lever 1. Release the throttle lever. 2. Set down the machine in such a way that it cannot tilt, fall or slip. 3. Set the multifunction switch to "Stop".
