Rhyno LED RL-WP20-01 Series Installation Instructions Manual

Rhyno LED Lighting Solution Inc
SERIES:
RL-WP20-01,02; RL-WP20-01,02;
Model number parameter list:
Item Model
RL-WP20-01,02
A
RL-WP30-01,02
B
CAUTION: This product use an input 100-277VAC driver of wide range voltage, but the actual
working voltage is depend on the input voltage of the photocell that installed on the product.
Normally the input voltages of photocell are 120V/208V/240V/277V single range, and also have
120-277VAC wide range. Please pay attention when installation.

1. Introduction


This LED Wall-Packs light uses the latest in solid state lighting technology for
long life, low maintenance, and high efficiency.

The same as traditional HID lighting, it could be mounted a standard photocell on
the enclosure, to make it completely suitable for street lighting.

An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal 100V-277V, 60Hz AC supply without any variation in light output.

Suitable for use in the following locations:
• Ambient Temp: -20~+40°C
• Wet Locations
Note: Save these instructions for future reference.
.
Installation INSTRUCTION MANUAL
Input Power
Voltage Factor
100-277VA ≥0.95
Your Imagination Is Your Only Limitation
Halifax  Nova Scotia  Tel: 902.425.LEDs (5337)  Fax: 902.8322258
E-mail: Sales@RhynoLED.ca
LED WALLPACKS LIGHT, 100-277VAC
Watt
20W
30W
 Website:
www.RhynoLED.ca
Version: 2013.V1
Input Current Weight
0.3A --Kg
0.38A --Kg
