- Page 1 USER MANUAL GAZELLE WITH BOSCH SYSTEM...
-
Page 2: Table Of Contents
GAZELLE USER MANUAL TABLE OF CONTENTS INLEIDING DISPLAY AND CONTROL UNIT 18 SAFETY DISPLAY 5.1.1 Charging display GENERAL 5.1.2 USB connection 5.1.3 Fitting and removing display LEGAL REQUIREMENTS 1.2.1 Significance for the user 5.1.4 Fitting and removing display 1.2.2 Safety and warranty 5.1.5 Switching system on and off... - Page 3 BOSCH SYSTEEM SPEED SENSOR MOTOR MOTOR OPERATION 8.2 WARRANTY AND SERVICE LIFE RANGE 30 INTERACTION OF THE EBIKE SYSTEM WITH THE BICYCLE GEARS 10. DIAGNOSING AND REMEDYING FAULTS 11. CLEANING 11.1 BATTERY 11.2 MOTOR 11.3 DISPLAY 11.4 CONTROL UNIT 11.5 CHARGER 12.
-
Page 4: Inleiding
GAZELLE USER MANUAL INTRODUCTION Many thanks for choosing a Gazelle with the Bosch system. This bike provides you with assistance on the move by means of an innovative electric drive system. This will make your cycling a great deal more enjoyable when riding into headwinds and carrying your belongings. -
Page 5: Safety
BOSCH SYSTEEM SAFETY It is no longer safe to use if current-car- rying components or the battery show In this manual you will find the following visible signs of damage. symbols that draw attention to hazards or important information. The push-assistance function may only be used when pushing the eBike. -
Page 6: Significance For The User
Unintentional activation 1.2.2 Safety and warranty of the eBike system poses a risk of injury. Read the Gazelle Safety and Warranty • Do not open the battery pack. Danger of manual for all safety instructions and short-circuiting. -
Page 7: Charger
BOSCH SYSTEEM • Batteries must not be exposed to mechani- fire. For short-circuiting damage caused in this manner, any and all warranty claims cal impact. This risks damaging the battery. through Bosch shall be invalid. • The bike operates at low voltage (36 V). •... -
Page 8: Drive Unit
GAZELLE USER MANUAL irritate the respiratory system. drive unit against overload and damage. • Supervise children. This will ensure that • Remove the battery pack from the eBike children do not play with the charger. before beginning work (e.g. assembly, •... -
Page 9: Maintenance And Repair
Have all fitting and setting jobs carried out by your Gazelle specialist. Please observe the operating and storage temperatures of the eBike components, see chapter 11 - “Technical specifications”. -
Page 10: Bike Configuration
GAZELLE USER MANUAL 2. BIKE CONFIGURATION LCD display Control unit (rack-type) Battery pack Motor... -
Page 11: Quick Start
BOSCH SYSTEEM 3. QUICK START 1. Check the battery pack before charging it or using it with your eBike for the first time. For this, press the -button switch on the battery pack. C7 C6 Charging the battery pack on the bike 4. - Page 12 GAZELLE USER MANUAL TURBO SPORT TOUR KM/H C7 C6 PMWH KM/H Reichweite Activating the system on the display Activating the system on the battery pack 7. Activate the electrical system by briefly 8. Check your battery charge status by pressing...
-
Page 13: Battery
BOSCH SYSTEEM 4. BATTERY 4.1 REMOVING THE BATTERY 7° Your battery is a lithium-ion battery, the Always switch the battery pack off most practical form of battery for electric when inserting or removing it from bikes. One of the main advantages of this the holder. -
Page 14: Charging Battery
GAZELLE USER MANUAL charging process does not damage the battery pack. The battery pack is equipped with a temperature control indicator, which enables charging only within a temperature range between 0°C and 40°C. When the battery pack is not within the... -
Page 15: Charging Process
BOSCH SYSTEEM 4.3.1 Charging process When the battery pack is switched on, the Read the safety instructions on the five green LEDs of the charge-control indi- charger attentively before starting the cator indicate the charge condition of charging process. the battery pack. In this, each LED indicates approx. -
Page 16: Checking Charge Status
5 LED’s lit 100% Should a fault occur during this period, your 4 LED’s lit 100 - 80% Gazelle specialist will replace the battery. 3 LED’s lit 80 - 60% Normal aging as well as wear and tear of 2 LED’s lit... -
Page 17: Fault Causes And Remedies
Gazelle specialist Contact your Gazelle specialist 2nd and 4th LED flashing: A fault has been detected. Contact your Gazelle specialist. ** The 2 outer and the middle LED are flashing: the battery is outside the charging temperature range. Remove the battery and allow it to reach the correct temperature. -
Page 18: Display And Control Unit
GAZELLE USER MANUAL 5. DISPLAY AND CONTROL UNIT Gazelle bikes with a Bosch system feature 5. Display on/off button and control unit 10. The an LCD display 6. ‘RESET’ reset button display is fitted in the centre of the hand- 7. -
Page 19: Fitting And Removing Display
BOSCH SYSTEEM play 3, press the lock latch and slide the Display toward the front out of the holder 4. It is possible to secure the Display against removal in the holder. To do so, remove the holder from the handlebars. Put the Dis- play in the holder. -
Page 20: Switching System On And Off
GAZELLE USER MANUAL Assistance Assistance sistance mode). The motor output depends read-out on the settings of the Display. TURBO Maximum assistance for a sporty ride As soon as you stop pedaling when in TURBO normal operation, or as soon as you have... -
Page 21: Speed And Indication Functions
BOSCH SYSTEEM Motor assistance will be switched off if the battery charge status drops below 5%. The remaining charge will be used for the display and lighting, sufficient for a further two hours of use approximately. 5.1.8 Speed and indication functions The current speed is always shown in the Indication function button i on the display speedometer indication f. -
Page 22: Showing And Changing Basic Settings
GAZELLE USER MANUAL When the Display is removed from The following basic settings are available: the holder 4, all function values remain stored and can be viewed. Unit (km/mi) The speed and distance can be displayed either in kilometers or miles 5.1.10 Showing and changing basic... -
Page 23: Control Unit
BOSCH SYSTEEM 5.2 CONTROL UNIT If you press the decrease value/down button 12, the strength of the assistance will be weaker at each press of the button, from TURBO down to OFF, the level with no assistance. Control unit The control unit has four buttons. - Page 24 GAZELLE USER MANUAL Walk assist will be switched off as soon as: You release the “WALK” walk assist but- ■ The wheels on the electric bike are ■ locked. Speed exceeds 6 km/h. ■ The push-assistance function may only be used when pushing the eBike.
-
Page 25: Charger
BOSCH SYSTEEM 6. CHARGER Your bike can be charged directly using a C1 Battery charger charging connection in the battery. The C2 Charger socket battery can remain in the bike during the C3 Plug-in connector charging process. You can also remove the C4 Safety warnings, charger battery from the carrier and charge it off C5 Charge connector... -
Page 26: Connecting Charger To Mains
GAZELLE USER MANUAL The charging procedure is only displayed for 3 seconds by pressing the on/ possible when the temperature of off button A4. the battery pack is within the allowable Disconnect the charger from the mains sup- charging temperature range. -
Page 27: Charging The Battery On The Bike
C6. 6.5 FAULT CAUSES AND REMEDIES Cause Remedy Contact your Gazelle specialist 2 LED’s flashing on Battery faulty the battery Take the battery off the charger until it is within the charging tem- 3 LED’s flashing Battery too hot or too cold perature range. -
Page 28: Speed Sensor
GAZELLE USER MANUAL SPEED SENSOR The speed sensor and its spoke magnet must be mounted in such a manner that the spoke magnet, after a turn of the wheel, moves past the speed sensor with a clea- rance of at least 5 mm, yet no more than 17 mm. -
Page 29: Motor
BOSCH SYSTEEM 8. MOTOR 8.1 MOTOR OPERATION 8.2 WARRANTY AND SERVICE LIFE When you switch on the assistance and the The Bosch mid-mounted motor is a dura- bike is set in motion, it will be assisted by the ble and maintenance-free drive unit. It is motor. -
Page 30: Range
Ask at your section 4.6 “Warranty and service life”. Gazelle specialist for more information. If the brakes are rubbing this will also The distance you can cycle with a fully reduce range. -
Page 31: Interaction Of The Ebike System With The Bicycle Gears
BOSCH SYSTEEM As a general rule: The higher the level of assistance, the shorter the range. The less power you draw from the electric drive (e.g. by optimum use of gears), the longer the range. 9.1 INTERACTION OF THE EBIKE SYSTEM WITH THE BICYCLE GEARS The bicycle gears should be used as with... -
Page 32: Diagnosing And Remedying Faults
KM/H PMWH section 6.5 “Fault causes and remedies”. KM/H Reichweite Have all checks and repairs carried out by your Gazelle specialist. Display To return to the standard indication, press any button on the Display or on the operating unit 10. - Page 33 BOSCH SYSTEEM Restart the system. If the problem persists, contact your Bosch eBike Internal error of the drive unit dealer Restart the system. If the problem persists, contact your Bosch eBike Internal software error dealer Internal error of the Display Have the Display checked SRestart the system.
-
Page 34: Cleaning
(isopropanol) or water. Suitable clea- cable to the battery must be checked for ners are available from your Gazelle specialist. possible contamination before being recon- He can also provide advice. nected. If necessary, the can be cleaned with care using a dry cloth. -
Page 35: Technical Specifications
BOSCH SYSTEEM 12. TECHNICAL SPECIFICATIONS Motor Drive Unit Article number 0 275 007 020 Rated continuous output 250 W Torque at drive, max. 48 Nm Rated voltage 36 V Operating temperature -5°C to 40°C Storage temperature -10°C to 50°C Degree of protection IP 54 (dust and splash water protected) Weight, approx. - Page 36 * Not possible via the eBike battery pack in all country-specific versions, depending on the statutory regulations We wish you a great deal of pleasure using your new bike with a Bosch drive system. Copyright © Koninklijke Gazelle NV Published by and copyright ©: Koninklijke Gazelle N.V., Dieren, the Netherlands Misprints, errors and technical changes excepted.
-
Page 37: Ec Declaration Of Conformit 2014 Ce
BOSCH SYSTEEM EC DECLARATION OF CONFORMITY 2014 CE The manufacturer: Koninklijke Gazelle N.V. Wilhelminaweg 8 6951BP Dieren, The Netherlands +31 313-429891 hereby declares that the following products: Product description: Innergy Model designation: Orange C Hybrid F, Miss Grace Hybrid F, Balance Hybrid F... - Page 38 GAZELLE USER MANUAL...
- Page 39 BOSCH SYSTEEM...
- Page 40 KONINKLIJKE GAZELLE N.V. Wilhelminaweg 8 6951 BP Dieren Gazelle Experience Center Nijkerkerstraat 17 3821 CD Amersfoort Postal address P.O. Box 1 6950 AA Dieren The Netherlands www.gazellebikes.com...
