- Page 1 NanoPC User’s Manual...
- Page 2 User’s Manual V1.1 for NanoPC. Symbol description: Note: Refers to important information that can help you to use NanoPC better, and tells you how to avoid problems. Caution: Indicating a potential risk of hardware damage or physical injury may exist.
- Page 3 Before using this product, please read the below safety notice carefully, this will help to extend the product’s lifecycle, and work normally. ■ When NanoPC is working, please make sure its ventilation system is working. ■ The power adapter is dissipating heat during normal use, please be sure not to cover it and keep it away from your body to prevent discomfort or injury by heat exposure.
-
Page 4: Package Contents
Package Contents NanoPC Seat Base VESA Mount Power Adapter Power Cord Easy Guide, USB Flash Disk Opening Tool Screws, Magnet Rubber Foot, Mini PCIe Half Card Support Mini COM to COM cable (Optional) Screws cover... -
Page 5: Table Of Contents
1-1 Front Side View ...................... 2 1-2 Back Side View ....................... 4 1-3 DDR3/DDR3L jumper ..................... 6 Placement and connecting 2-1 Placement of NanoPC ................... 8 In Seat Base ......................8 On the desk ......................8 Installing to Display....................9 2-2 Connection of NanoPC .................. - Page 6 Fox Intelligent Stepping ..................20 CPU Configuration....................21 Advanced ........................23 Trusted Computing ....................24 North Bridge ......................25 TXE Subsystem ...................... 26 Onboard Device Configuration ................27 SATA Configuration ....................28 Super IO Configuration ................... 29 Network Stack Configuration .................. 30 Boot ..........................
-
Page 7: Introduction
Introduction ■ Front Side View ■ Back Side View ■ DDR3/DDR3L jumper... -
Page 8: Front Side View
INTRODUCTION 1-1 Front Side View... - Page 9 INTRODUCTION Power button with Power indicator LED Press to turn your NanoPC on or off, the LED can indicate your system states. Suspend Button Enter suspend mode in operating system. Clear CMOS : Press Suspend Button 10s in S5. USB 3.0 port This USB port supports the USB 3.0/2.0/1.0 specification.
-
Page 10: Back Side View
INTRODUCTION 1-2 Back Side View... - Page 11 Connect monitor or TV that uses HDMI connector to this port. Kensington lock Attach a Kensington security system or a compatible security lock to secure your NanoPC in place. RJ-45 LAN port Supports 10/100/1000Mb/s Ethernet network. Connect network cable to access Internet.
-
Page 12: Ddr3/Ddr3L Jumper
INTRODUCTION 1-3 DDR3/DDR3L jumper Set the jumper to pins 1-2, it set to DDR3L, the DDR3L Power is 1.35V. Set the jumper to pins 2-3, it set to DDR3, the DDR3 Power is 1.5V. 1.35V 1.5V... -
Page 13: Placement And Connecting
Placement connecting ■ Placement of NanoPC ■ Connection of NanoPC... -
Page 14: Placement Of Nanopc
PLACEMENT AND CONNECTING 2-1 Placement of NanoPC In Seat Base 1. Place your NanoPC into the groove of the Seat Base. On the desk 1. Fit your NanoPC with Magnet Rubber Foot, and put it on the tabletop directly. -
Page 15: Installing To Display
PLACEMENT AND CONNECTING Installing to Display This is the best space-saving way. 1. Use four screws to fasten the Vesa Mount onto the display back. 2. Fit the Nettop into the Vesa Mount with power button locating at the top for easy touch. To fasten the VESA mount, your display must comply with VESA75 or VESA100 stan- dard. -
Page 16: Connection Of Nanopc
PLACEMENT AND CONNECTING 2-2 Connection of NanoPC Connect display Connect a display or TV that has HDMI port or VGA port to your NanoPC. -
Page 17: Connect Usb Devices
PLACEMENT AND CONNECTING Connect USB devices Connect USB devices to the USB ports, for example, mouse, keyboard devices. Connect network cable Connect one end of a network cable to the RJ-45 LAN port, and the other end to a hub or switch. -
Page 18: Connect Power Cord
PLACEMENT AND CONNECTING Connect power cord Connect the power adapter to the power input port of the NanoPC, and then press the power button to start it. The power adapter is dissipating heat during normal use, please do not cover it and... -
Page 19: Connect Point Of Sales
PLACEMENT AND CONNECTING Connect Point Of Sales Connect one end of cable to the COM port, and the other end to a Point Of Sales. -
Page 20: Bios Setup
BIOS Setup ■ Enter BIOS Setup ■ Main ■ F-centre ■ Advanced ■ Boot ■ Power ■ Health ■ Security ■ Save & Exit... -
Page 21: Enter Bios Setup
BIOS SETUP Enter BIOS Setup The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS pa- rameters is critical to maintain optimal system performance. Power on the computer, when the message “Press <Del> to enter setup. Press <F7> to enter boot menu.” appears at the bottom of the screen, you can press <Del>... - Page 22 BIOS SETUP if you have more memory or I/O cards installed. It means, if your system loading is heavy, set to optimal default may sometimes come out an unstable system. What you need now is to adjust BIOS setting one by one, trial and error, to find out the best setting for your current system. You also can save or discard the changes and exit BIOS setup here.
-
Page 23: Main
BIOS SETUP Main Main F-center Advanced Boot Power Health Security Save&Exit System Date [Sun 01/06/2013] Set the Date. Use Tab System Time [09:37:57] to switch between Date elements. Access Level Administrator Model Name nT-iBT18/-iBT19/-iBT29 TXE Version 01.00.02.1060 EC Version D72F1116 BIOS Version D72F1D14 x64 Build Date and Time... -
Page 24: F-Center
BIOS SETUP no password is set or you enter system with administrator password, this item will display “Administrator”. F-center Main F-center Advanced Boot Power Health Security Save&Exit Super BIOS Protect [Disabled] Super BIOS Protection Settings. ▶ Smart BIOS ▶ Fox Intelligent Stepping ▶... -
Page 25: Smart Bios
BIOS SETUP Smart BIOS Main F-center Advanced Boot Power Health Security Save&Exit Smart Power LED [Disabled] Smart Power LED Smart Boot Menu [Enabled] Settings → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 26: Spread Spectrum
BIOS SETUP ► Smart Boot Menu When PC starts, it will ask you to press [Del] key to enter setup or press [F7] key to enter smart boot menu. If [Disabled] is selected, then pressing [F7] has no function. This also prevents user without password trying to get into your computer through smart boot menu. -
Page 27: Cpu Configuration
BIOS SETUP CPU Configuration Main F-center Advanced Boot Power Health Security Save&Exit CPU Configuration XD can prevent certain classes of malicious CPU Brand Name: buffer overflow attacks Intel(R) Celeron(R) CPU J1900 @ 1.99GHz when combined with a L1 Data Cache 24 KB X 4 supporting OS (Windows L1 Code Cache... - Page 28 BIOS SETUP ► Power Technology This item is used to enable or disable the power management features. Default value is: [Energy Ef- ficient]. ► EIST You can select the EIST (Processor Power Management, PPM) through this item. Enhanced Intel SpeedStep® technology (EIST) allows the system to dynamically adjust processor voltage and core frequency, which can result in decreased average power consumption and decreased average heat production.
-
Page 29: Advanced
BIOS SETUP Advanced Main F-center Advanced Boot Power Health Security Save&Exit ▶ Trusted Computing Trusted Computing ▶ North Bridge Settings ▶ TXE Subsystem ▶ Onboard Device Configuration ▶ SATA Configuration ▶ Super IO Configuration ▶ Network Stack ▶Realtek PCIe GBE Family Controller (MAC:00:00:00:00:00:03) →... -
Page 30: Trusted Computing
BIOS SETUP Trusted Computing Main F-center Advanced Boot Power Health Security Save&Exit Configuration Enables or Disables Security Device Support [Disabled] BIOS support for security device. O.S. Current Status Information will not show Security NO Security Device Found Device. TCG EFI proto- col and INTA interface will not be available. -
Page 31: North Bridge
BIOS SETUP North Bridge Main F-center Advanced Boot Power Health Security Save&Exit North Bridge Configuration Select DVMT 5.0 Pre- Allocated (Fixed) Memory Information Graphics Memory size Total Memory 2048 MB (DDR3/DDR3L 1333) used by the Internal Memory Slot0 2048 MB (DDR3/DDR3L 1333) Graphics Devices. -
Page 32: Txe Subsystem
BIOS SETUP TXE Subsystem Main F-center Advanced Boot Power Health Security Save&Exit Intel TXE Subsystem Configuration TXE Version 01.00.02.1060 → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 33: Onboard Device Configuration
BIOS SETUP Onboard Device Configuration Main F-center Advanced Boot Power Health Security Save&Exit Onboard Device Configuration Enabled/Disabled board LAN Control- Onboard LAN Controller [Enabled] Onboard USB Controller [Enabled] Legacy USB Support [Enabled] USB3.0 Support [Enabled] Azalia HD Audio controller [Enabled] →... -
Page 34: Sata Configuration
BIOS SETUP SATA Configuration Main F-center Advanced Boot Power Health Security Save&Exit SATA Configuration Enabled/Disabled rial ATA Onboard SATA Controller [Enabled] Onboard SATA Mode [Native IDE] Serial-ATA Controller [Enabled] SATA Port1 Not Present → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. -
Page 35: Super Io Configuration
BIOS SETUP Super IO Configuration Main F-center Advanced Boot Power Health Security Save&Exit Super IO Configuration Set Parameters of Serial Port 1 Super IO Chip IT8518E/IT8519E (COMA) ▶ Serial Port 1 Configuration → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. -
Page 36: Network Stack Configuration
BIOS SETUP Network Stack Configuration Main F-center Advanced Boot Power Health Security Save&Exit Network stack [Disabled] Enable/Disables UEFI network stack → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 37: Boot
BIOS SETUP Boot Main F-center Advanced Boot Power Health Security Save&Exit Boot Configuration Select the keyboard Bootup Numlock State [On] NumLock state Quiet Boot [Enabled] Fast Boot [Disabled] ▶ CSM Configuration FIXED BOOT ORDER Priorities Boot Option #1 [UEFI Hard Disk] Boot Option #2 [UEFI CD/DVD] Boot Option #3... -
Page 38: Csm Parameters
BIOS SETUP ► Hard Disk Drive BBS Priorities / CD/DVD ROM Drive BBS Priorities/USB Floppy Drive BBS Priorities / USB CD/DVD ROM Drive BBS Priorities / USB Hard Disk Drive BBS Priorities / USB KEY Drive BBS Priorities / NETWORK Device BBS Priorities / UEFI Boot Drive BBS Priorities This items appear only when the devices are available. -
Page 39: Power
BIOS SETUP Power Main F-center Advanced Boot Power Health Security Save&Exit Resume By USB Resume By USB Device(s) [Enabled] Device(s) Resume By Onboard LAN [Disabled] Resume By RTC [Disabled] Energy-using product [Enabled] Restore AC Power Loss [Power Off] → ←: Select Screen ↑... -
Page 40: Health
BIOS SETUP ► Restore AC Power Loss This item is used to set which state the PC will take with when it resumes after an AC power loss. Health Main F-center Advanced Boot Power Health Security Save&Exit CPU Temperature : +40 ˚C CPU Shutdowm CPU Fan Speed : 3326 RPM... -
Page 41: Security
BIOS SETUP Security Main F-center Advanced Boot Power Health Security Save&Exit Set Administrator Security configuration Password Administrator Password Not Installed User Password Not Installed Administator Password ▶ Secure Boot menu → ←: Select Screen ↑ ↓/Click: Select Item Enter/Dbl Click: Select +/-: Change Opt. -
Page 42: Restore Defaults
BIOS SETUP Save & Exit Main F-center Advanced Boot Power Health Security Save&Exit Save Changes and Reset Reset the system af- Discard Changes and Reset Restore Defaults saving the changes. Boot Override Windows Boot Manager (P1: WDC WD2500BEVT-22A23T0) UEFI: General USB Flash Disk 1.0 UEFI: SMI USB DISK 1100 UEFI: Built-in EFI Shell ▶... - Page 43 BIOS SETUP By this default, BIOS have set the optimal performance parameters of system to improve the performances of system components. But if the optimal performance parameters to be set cannot be supported by your hardware devices (for example, too many expansion cards were installed), the system might fail to work.
-
Page 44: Install Os
Install OS ■ Install Windows 8.1/Windows 8/ Windows 7(64 bit) ■ Install Drivers... -
Page 45: Install Windows 8.1/Windows 8/Windows 7(64 Bit)
1. Windows 8.1/Windows 8/Windows 7(64 bit) Install USB Disk or USB DVD-ROM drive and ndows 8.1/ Windows 8/Windows 7(64 bit) Install CD (Other purchase) 2. NanoPC USB Flash Disk (In this package) 4-1 Install Windows 8.1/Windows 8/Windows 7(64 bit) 1. Connect the Windows 8.1/Windows 8/Windows 7(64 bit) Install USB Disk (or USB DVD-ROM drive) to one USB port of NanoPC. - Page 46 INSTALL OS 8. The setup will display the hard disk partitions (20GB, in this example) of your system. If there were other systems (such as Linux) installed previously, you need select them and click “Drive options (advanced)” to delete them. When all partitions are clean, setup will display the biggest size of your hard drive.
- Page 47 INSTALL OS 9. In the hard disk size screen, you can click the “new” button to create partitions as you need. In this example we are creating a 70GB partition to install Windows. Make your modifications and click “Apply”. To ensure that all Windows features work correctly, Windows might create additional partitions for system files.
- Page 48 INSTALL OS 10. The setup program will then start to install Windows 8.1/Windows 8/Windows 7(64 bit) on your hard disk. During the installation, your computer will restart several times.
-
Page 49: Install Drivers
When you install the driver of Windows 7(64bit) OS, you need to install it manually under the path: Driver \ Intel \ TXEpatch TXEpatch. 4. After installing all the drivers, you need to restart your NanoPC, then you can start using it. -
Page 50: Utility
Utility ■ Fox WINFLASH... -
Page 51: Fox Winflash
UTILITY Fox WINFLASH Fox WINFLASH is a useful utility to backup and update your system BIOS. Supporting Operating Systems: ■ Windows 8.1 ■ Windows 8 ■ Windows 7 (64bit) Please set the BIOS setting “BIOS Write Protect” or “Super BIOS Protect” to [Disabled] when running this application. - Page 52 UTILITY 1-2 Local Update - Backup BIOS This page can back up your system BIOS. You can click “Backup BIOS”, and key in a file name, then click “Save” to finish the backup operation. The extension of this backup file is “.ROM” for AMI BIOS. Make sure you can remember the file name together with the directory which it is stored, prevented that you may need them to recover your BIOS later.
-
Page 53: About & Help
UTILITY 2. About & Help This page shows some information about Fox WINFLASH. - Page 54 Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device,...
- Page 55 Warning statement for Europe: Also, put in the manual which directive to fulfil and also which countries to sell the product. Example of a text to tell which directive has been fulfilled: Hereby, Foxconn, declares that this nT-iBT Series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.”...
