ASSEMBLY AND INSTALLATION INSTRUCTIONS
Important: Read entire instruction sheet before
assembling or installing mantel kit.
These mantels are only approved for use with any
DESA Heating, LLC 32" electric and compact gas
fireplace system. Do not use mantel with any other
product.
This mantel kit contains the following:
• Mantel pieces - unassembled and numbered as follows:
#1 Base
#2 Right Side Assembly
#3 Left Side Assembly
#4Header
#5 Top
#6 Heat Reflector Strip
• Hardware Package
20 - 1
/
" Wood Screws
1
4
* Extra hardware may be included
Smoky Mountain Fireplace
828-670-1970
www.smfireplace.com
W32GO Mantel and Base
114325-01
Smoky Mountain Fireplace
828-670-1970
www.desatech.com
www.smfireplace.com
Tools required:
• Power Screwdriver with #2 Phillips Bit
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement. If
hardware is missing or damaged, contact DESA Heating, LLC
at 1-866-672-6040 for referral information. You can also visit
DESA Heating, LLC's web site at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
mantel. Damage to mantel will result if other screws
are used for this purpose.
/
" screws to assemble
1
4
