VSC-101tn Quick Set-Up Guide

Version 1.7.2.0

March 27, 2015

Table of Contents

Need help?

Do you have a question about the VSC-101tn and is the answer not in the manual?

Questions and answers

Summary of Contents for MediaMatrix VSC-101tn

Page 1 VSC-101tn Quick Set-Up Guide Version 1.7.2.0 March 27, 2015...
Page 2: Copyright Notice
The ratc-server component is based in part on the work of the libwebsockets project: http://libwebsockets.org. Prepared by Peavey Digital Research, 6 Elm Place, Eynsham, Oxford, OX29 4BD, UK. Email:mmtechsupport@peavey.com (mailto:mmtechsupport@peavey.com). Scope This guide describes how to configure a VSC-101tn Video Scaler-Switcher with basic settings. Version 1.7.2.0 March 27, 2015...
Page 3: Important Safety Instructions
1 - Important safety instructions Warning: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6.
Page 4 a) The wire that is colored green and yellow must be connected to the terminal that is marked by the letter E‚ the earth symbol‚ b) colored green or colored green and yellow. c) The wire that is colored blue must be connected to the terminal that is marked with the letter N or the color black.
Page 5: What Is Vsc-101Tn
2 - Introduction What is VSC-101tn? VSC-101tn is a full HD video scaler switcher. The device scales and switches any HDMI, VGA, YPbPr, C-Video or S-video video signal to HDMI up to 1080P. It is controllable via buttons on the front, the IR sensor and the RS232 port. It has 12 video inputs and 10 audio inputs.
Page 6: What's In The Box
What's in the box? VSC-101tn products are packaged in a single container. This container includes the following items: 1 x VSC-101tn  1 x Power Cord  1 x IR remote (Cell battery is not included)  4 x Captive screw connectors ...
Page 7 1. Output section. 5-pin Euro-connector for balanced stereo audio output, one VGA output, one HDMI output with embedded audio. One HDBaseT port for HDMI (works with the VCAT-HDR). 2. Four VGA input connectors. 3. Four HDMI input connectors. 4. Four 3.5mm stereo audio connectors for VGA audio inputs. 5.
Page 8: Infrared Remote Control
Infrared remote control Video source select: HDMI inputs 1,2,3,4.  VGA inputs 1,2,3,4.  Component video inputs: 1. Composite video, 2.  Component video (YPbPr), 3. S-Video, 4. Composite video. Menu and volume control area. Mute for line and mic audio inputs.
Page 9 Direction buttons and OK button. These are only available in MENU mode. Mic volume control. This can be used when not in MENU mode. Output resolution select: 720P (1280x720)  1080P (1920x1080)  XGA (1024x768)  WXGA (1280x800)  HD (1360x768) ...
Page 10: Specifying The Picture Parameters
3 - Setting up the unit using the Introduction The product provides an On-Screen Display (OSD) menu. Note: Many of the features are used only during initial installation and setup. Specifying the picture parameters The first icon from the left of the OSD menu is used to set the picture parameters.
Page 11: Specifying The Audio Parameters
Specifying the audio parameters The second icon from the left of the OSD menu is used to set the audio parameters. The settings include sound effect presets, bass, treble, balance, scene mode, surround and smart volume setting. Note: Not all parameters are available with all inputs. Specifying the system parameters The third icon from the left of the OSD menu is used to set the system parameters.
Page 12: Specifying The Tcp/Ip Settings
TCP/IP Introduction You can control the VSC-101tn via the Ethernet port on the rear of the unit. The same commands can be used for control via the Ethernet port and the RS-232 port. For more information, see Communication protocol and command codes (on page 22).
Page 13 Note: Do not change the serial configuration options from the default, otherwise you may not be able to access the VSC-101tn via a serial connection. 6. Set the IP address of the unit so that it matches the IP address scheme used on the network.
Page 14: Sending Commands To The Vsc-101Tn Via Telnet
1. Connect a PC and the VSC-101tn to the same network. 2. Open a Telnet session and connect to the VSC-101tn. The default IP address is 192.168.0.178. The default port is 4001. 3. Once a connection has been made, type commands to control the VSC-101tn. Version 1.7.2.0 March 27, 2015...
Page 15 For information on the available commands, see Communication protocol and command codes (on page 22). March 27, 2015 Version 1.7.2.0...
Page 16 The VSC-101tn can be used to control third party devices via a VCAT-HDR. The diagram below shows the connections required. The VSC-101tn will pass all commands received via the RS-232 port and the Ethernet port out the HDBaseT port to the VCAT-HDR. These commands will be available at the RS-232 port of the VCAT-HDR for control of third party devices (projectors, monitors, and so on).
Page 17 For information on installation and set up of the VCAT-HDR, refer to the VCAT-HD Quick Set-Up Guide. Notes: Communications are limited to one direction. The VSC-101tn will not be able to receive  commands via the VCAT-HDR. The commands used by the third party device connected to the VCAT-HDR must not be ...
Page 18: Maintaining The Unit
6 - Maintaining the unit Updating the firmware You can update the firmware on the VSC-101 and VSC-101tn products using a flash disk inserted into the USB port at the rear. MediaMatrix Technical Support (mailto:mmtechsupport@peavey.com) will provide you with the files you need to install on the flash disk and explain the procedure.
Page 19 Problem What to do Waves on image If the output image has waves, especially if the waves move up or down, check that all devices and components (video players, computers, etc.) are grounded properly. Poor color saturation Double-check the input and output connections of all cables. Check for bent pins on VGA cables.
Page 20: Reference Information
7 - Reference information Specification Video input Video output Input 4 HDMI, 4 VGA, Output 1 HDMI, 1 VGA, 1 1 YPbPr, 2 C-Video, HDBaseT 1 S-Video Input connectors HDMI female Output connectors HDMI female connector, VGA(15 connector, VGA(15 pin HD), RCA pin HD), RJ-45 female connector, connection (for...
Page 21 Audio input Audio output Balanced stereo audio Input 6 Stereo analog Output output, inputs for audio 2x10W@8Ω/amplifier follow video 1 Stereo Left/Right audio input 1 Balanced mic-level audio input 4 RCA female Input connector Output connector Left/Right 5-pin connector for YPbPr, Euro-connector C-Video &...
Page 22: Supported Video Formats
Supported video formats The device supports many types of video signals, including C-Video, S-Video, YPbPr, VGA and HDMI. All inputs are scaled to the selected HDMI format output. C-Video and S-Video input Supports PAL, SECAM and NTSC formats.  From the OSD, the aspect ratio can be set to full-screen, wide screen or 4:3. ...
Page 23: Vga Input
VGA input The VGA resolution is VESA standard. The following resolutions are supported. The maximum bandwidth is 375MHz (-3dB). The aspect ratio can be changed between full screen and 4:3. The audio bass and treble can be adjusted. Resolution Resolution 640×480@60Hz 1024×768@70Hz 640×480@72Hz...
Page 24: Audio Input/Output
Audio input/output Switched (audio follows video) inputs 4 x VGA audio 3.5mm (1/8) stereo inputs.  4 x HDMI embedded audio.  2 x RCA stereo audio inputs.  Non-switched (always on) inputs 1 x Balanced MIC level audio input (Euro-connector). ...
Page 25 Command Function Description Feedback Example Auto-adjust the input signal(VGA 0606% VGA Adjustment only) 0607% Auto-adjust the color temperature Color Temp: XX 0608% ZOOM the image, set the aspect ratio Aspect Ratio: XX 0609% OK, for OSD selection 0610% OSD: Left Left 0611% OSD: Right...
Page 26 Command Function Description Feedback Example 0635% Check the image aspec ratio Aspect Ratio: XX 0636% Check the brightness Brightness: XX 0637% Check the contrast Contrast: XX 0638% Check the saturation Saturation: XX 0639% Check the sharpness Sharpness: XX 0640% Check the color temperature Color Temp: XX 0644% OSD CHANNEL display enable...
Page 27 Command Function Description Feedback Example 0708% Switch to VGA4 input Source: VGA4 0709% Switch to composite video AV1 input Source: CVIDEO1 0710% Switch to YPbPr input Source: YPbPr 0711% Switch to S-Video input Source: SVIDEO 0712% Switch to composite video AV2 input Source: CVIDEO2 0720% Mute Line and MIC Mute On...
Page 29: Warranty Statement
How To Get Warranty Service DOMESTIC (USA) LIMITED WARRANTY End Users: Take the defective product and your dated sales receipt or other proof of purchase to your Authorized MediaMatrix Systems Effective Date: May 1, 2005 Integrator or Authorized Peavey Service Center. System...
Page 30 MediaMatrix® A Division of Peavey Electronics Corp. 5022 Hartley Peavey Drive, Meridian Mississippi, 39305, USA Phone: 866.662.8750 http://www.peaveycommercialaudio.com/products.cfm/mm/ Features & Specifications subject to change without notice Copyright © 2015, All Rights Reserved 80305813...
