Summary of Contents for DirectCM DCM1100i
- Page 1 User Manual...
- Page 2 ’ ’ The DCM1100i is designed is specifically to be small and quiet. It adopts Intel® pBTX motherboard technology to enhance thermal management, system size and shape, and acoustics. In addition, the power supply features passive power factor correction (PFC), which allows the power distribution to operate more efficiently.
- Page 3 Copyright Copyright © DirectCM 2006. All right reserved. Disclaimer: DIRECTCM is not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use this product.
- Page 4 ♦ Do not place system in a built-in enclosure unless proper ventilation is available. ♦ Operate this system from power source indicated on the marking label. If you are unsure about the power type, contact your dealer or local power company. ♦...
- Page 5 Warning: This system must be connected to a grounded (earthed) outlet. To reduce the risk of electrical shock and damage to the system or loss of data, do not disable the groundling type plug. Power cord set requirements The power cord set (including the appliance coupler, flexible cord, and wall plug) meets all requirements for use in the country where the computer was purchased.
-
Page 6: Table Of Contents
Table of Contents Chapter1 Error! Bookmark not defined. Unpacking Error! Bookmark not defined. Checklist: ............Error! Bookmark not defined. Chapter2 Error! Bookmark not defined. System Overview Front Panel ...................... 8 Rear Panel ....................... 9 Chapter3 Assembling / Disassembling Error! Bookmark not defined. Removing the Case Cover................ - Page 7 Before unpacking your DCM1100i, provide a steady, level, clean surface located near a wall outlet. The computer should have enough space around it to allow airflow, especially near the rear fan. If the system does not have adequate ventilation, internal components can overheat and be damaged as a result.
-
Page 8: System Overview
The features in the front panel are shown in Figure 2.1, and are described as following. Figure 2.1 Power switch: Lets you to turn the DCM1100i System on and off. When you power on, this LED embedded in Power switch will light blue. If the button is held down for one second, the... -
Page 9: Rear Panel
Assembling / Dissmebling Microphone jack (pink): Plug the microphone into this jack for recording or voice-control functions. USB port x 2 Two USB devices can be connected via these ports; there are a further four on the rear of the computer – see below. IEEE1394 Connector 1394 devices can be connected via these ports. - Page 10 Assembling / Dissmebling 1. PS/2 Mouse connector (purple): Plug your PS/2 mouse into this connector. 2. COM1 port (turquoise): Connect serial (RS232) devices such as a modem to this port. 3. VGA port : Connect VGA devices such as a display monitor to this port.
- Page 11 Assembling / Dissmebling 9. RJ45 LAN connector For connecting with your LAN to access the network services or surf the Internet. Security Mechanism This system features a specifically designed safety mechanism to protect the machine. Figure 2.3 1. Chassis Lock: A hardware security mechanism, when you place the switch in lock position, the chassis cover cannot be opened.
- Page 12 Assembling / Dissmebling About 1394 and USB connector For using the peripheral device of IEEE1394 and USB, please connect the USB and IEEE1394 connectors as shown in shown in Figure 2.4 Figure 2.4 1. USB Connector: Connect to USB connector for any USB device. 2.
- Page 13 Assembling / Dissmebling About Card Reader connector For using card reader, please connect the USB card reader connector as shown in shown in Figure 2.5 Figure 2.5...
-
Page 14: Chapter3
Assembling / Dissmebling & & Removing the Case Cover Lay the unit flat, face the rear panel of the unit. Switch the Chassis Lock to unlock cover position, as shown in Figure 3.1 Figure 3.1 Pull the cover forward slightly then lift it upwards and iii. -
Page 15: Removing Of Hard Disk Rack
Assembling / Dissmebling Figure 3.2 Perform the above steps in reverse order to replace the cover. Removing of Hard Disk Rack Before removing the whole hard disk rack from the main body, please disconnect the flat cable and power cord of the hard disk, as shown in Figure 4.1, and Figure Figure 4.1 Figure 4.2... -
Page 16: Removing Of Odd & Card Reader Frame
Assembling / Dissmebling Removing of ODD & Card Reader Frame Remove the front cover with disengaging metal tab that hook on bottom and move it forward to open it. Figure 5.1 Before removing ODD & Card Reader frame from the main body, you must first disconnect the card reader connector, IDE connector and power connector, as shown in Figure 5.2 Power... -
Page 17: Removing The Vga Card
Assembling / Dissmebling Hold up the shield plate (as indicated by below iii. drawing circle) and pull forward, you may totally opened the ODD & card reader rack, as shown in Figure 5.3. Figure 5.3 Removing the VGA Card Lift up the VGA board shield plate from the main braket, as shown in Figure 6.1. -
Page 18: Removing The Power Supplier
Assembling / Dissmebling Disengage metal tab that stepped with main bracket as indicated in step1, and slightly move the VGA board to right side as indicted in step 2 to unhook the board from staple. Figure 6.2 Perform the above steps in reverse order to install the VGA card. Removing the Power Supplier Pull up the switch to unlock the power supplier, as shown in Figure 7.1. -
Page 19: Installing/Uninstalling The Hard Disk Drive
Assembling / Dissmebling Figure 7.1 Disengaged the power supplier from the main frame, as shown in Figure 7.2. Figure 7.2 Installing/Uninstalling the Hard Disk Drive Hook your hands inward onto the plastic holder (as indicated in below drawing step 1) and then lift it upward from the hard disk rack (as indicated in below drawing step 2), as shown in Figure 8.1. -
Page 20: Installing/Removing The Cpu
Assembling / Dissmebling Pull the plastic holder outward a bit for removing the hard disk, as shown in Figure 8.2. Figure 8.2 Fix the hard disk rack in position by simply iii. placing it back to main frame, as shown in Figure 8.3. - Page 21 Assembling / Dissmebling Front Fan Rear Fan Connector Connector Power Connector Figure 9.1 Unscrew the heat sink from motherboard, as shown in Figure 9.2. Figure 9.2 Orient the CPU with the socket, place the CPU iii. on socket, it should slide into place without the use of force.as shown in Figure 9.3.
- Page 22 Assembling / Dissmebling Figure 9.3 Pull down the socket lever and click it into its latch at the side of the socket, as shown in Figure 9.4 above, to lock the CPU in position. Figure 9.4 Place the heat sink back to motherboard, and screw each side of the heat sink, there are 4 holes in total, as shown in Figure 9.5 below.
-
Page 23: Installing Foot Stand
Assembling / Dissmebling Figure 9.5 Installing Foot Stand The foot stand is intended for the DCM1100i to stand securely in the upright position. Please assemble it on the chassis, as shown in Figure 10.1 and Figure 10.2 Figure 10.1 Figure 10.2 The DCM1100i System with the foot stand that keeps the DCM1100i up and stable during use. - Page 24 Assembling / Dissmebling Figure 10.3...
-
Page 25: Appendix
Product Features • Drive bays Slim CD-ROM / DVD-ROM / CD-RW DVD-RAM Drive x 1 • 3.5” standard HDD drive x 1 • Card Reader drive x 1 • Front Panel Switches: Power Button • Creative Window: USB port x 2 IEEE1394 port x 1 Line out jack x 1 Microphone jack x 1... - Page 26 Assembling / Dissmebling Integrated Drive Controllers (1) Integrated ATA-100 (2) Integrated Serial ATA-300 connectors Audio Integrated High Definition 5.1 Audio Expansion Slots One x16 PCI Express Slot Graphics Integrated Intel GMA 950 ® Network Interface Integrated Intel Gigabit Ethernet w/AMT* ®...
- Page 27 Assembling / Dissmebling All contents in the specifications are subjected to change without notice.
