READ AND SAVE THESE INSTRUCTIONS
153791
OWNERS INSTRUCTION MANUAL
FOR DUAL MOUNT FAN'S
INSTALLATION
OPERATION
MAINTENANCE
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT
A QUALIFIED ELECTRICIAN
These instructions are suitable for
UL/cUL Listed Ceiling fans

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 153791 and is the answer not in the manual?

Questions and answers

Related Manuals for DesignHouse 153791

Summary of Contents for DesignHouse 153791

  • Page 1 READ AND SAVE THESE INSTRUCTIONS 153791 OWNERS INSTRUCTION MANUAL FOR DUAL MOUNT FAN’S INSTALLATION OPERATION MAINTENANCE CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT A QUALIFIED ELECTRICIAN These instructions are suitable for UL/cUL Listed Ceiling fans...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Tips -----------------------------------------------------------------------------------2 Unpacking Your Fan ----------------------------------------------------------------------3 Material Required ---------------------------------------------------------------------------4 Electrical Outlet box------------------------------------------------------------------------4 Install Mounting Bracket------------------------------------------------------------------5 Installing the Fan-----------------------------------------------------------------------------6 Electrical connections----------------------------------------------------------------------9 Blade Attachment---------------------------------------------------------------------------10 Installing Light kit---------------------------------------------------------------------------11 Operation--------------------------------------------------------------------------------------12 Maintenance----------------------------------------------------------------------------------13 Trouble Shooting---------------------------------------------------------------------------14,15 Part List----------------------------------------------------------------------------------------16 Page 1...

  • Page 3: Safety Tips

    SAFETY TIPS TABLE OF CONTENTS To avoid possible electric shock, turn off the electricity at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. CAUTION: READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 4: Unpacking Your Fan

    UNPACKING YOUR FAN SAFETY TIPS Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary the fan should be returned in original packaging. Remove all parts and hardware. Do not lay motor housing on its side: the decorative casting may shift.

  • Page 5: Electrical Outlet Box

    TOOLS AND MATERIALS REQUIRED *Phillips screw driver *Blade screw driver *Adjustable pliers or wrench *Step ladder *Wire cutter *Electrical tape ELECTRICAL OUTLET BOX 1. If there is an existing outlet box, ensure it is clearly marked” Suitable For Fan Support”. If not, it must be replaced with an approved one. 2.

  • Page 6: Install Mounting Bracket

    INSTALL MOUNTING BRACKET 1. To avoid possible electrical shock, be sure electricity is turned off at the main power panel before wiring. All wiring must be in accordance with National and Local Electrical Codes, and the ceiling fan must be grounded as a precaution against possible electrical shock. 2.

  • Page 7: Installing The Fan

    SELECT TYPE OF INSTALLATION INSTALLING THE FAN HANG DOWN STYLE 1 Slide the canopy on the downrod(Fig.6) Thread the power leads from the fan through the canopy and downrod. Take extra care not to pull on power wires. Damage and loose connections could result from any abnormal pressure on these wires. Set downrod into downrod collar yoke.
  • Page 8 DOWNROD SETSCREW Lock Nut Motor Setscrew Fig.7 Tighten motor set screw. Check the strength of this connection (pre-tightened at factory) by holding the motor housing in position and turning the downrod counter clockwise. If this connection slips, retighten motor setscrew and locknut. Follow the same procedures as mentioned above for downrod setscrew.
  • Page 9 HUGGER STYLE 1. Put 2 screws in the hanger bracket. Leaving them partially out. (Fig. 9.1). 2. Remove three of the six screws and lock washers (every other one) from the top housing (Fig. 9.2) 3. Place the ceiling canopy over the collar on the top of the motor housing. Align the mounting holes with the holes in the motor and fasten, using the three screws and lock washers which are removed in Step 2 (Fig.

  • Page 10: Electrical Connections

    ELECTRICAL CONNECTIONS Four wires are connected to the top of the fan. Black: ” Hot” Power/Live for the fan Blue: “ Hot” Power/ Live for the light kit White: “Common”/Neutral for the fan and the light kit Green/Green & Yellow: “Ground” /Earth wire If the fan and light are connected to the same circuit, the black and blue wires should be connected together to the black wire in the ceiling using a wire nut to make the connection.

  • Page 11: Blade Attachment

    BLADE ATTACHMENT Place screw through the blade and start the screw into the blade arm repeat this procedure without tightening the screw until all 3 screws have been started into the blade arm (Fig.11). As most fan use concealed screw blades arms, screws may not go through the whole blade arms.
  • Page 12 INSTALLING GENERAL TURTLE LIGHT KIT (OPTIONAL) Locate two wires in the switch housing (white and blue labeled “ for light”). Connect them to the light kit wire connectors (Fig. 12) White to white Blue to blue Secure all splices with electrical tape to prevent connectors from vibrating loose during fan operation.
  • Page 13 INSTALLING DISC BOWL LIGHT KIT(OPTIONAL) Remove switch housing screws and then remove bottom cap of switch housing shell on fan. Locate two wires in the switch housing (white and blue labeled “ for light”). Connect them to the light kit wire connectors White to white Blue to blue Secure those wires with wire nuts in the fan.

  • Page 14: Operation

    OPERATION Restore electrical power by turning on the electricity at the main fuse box. Turn on the wall switch. Your fan has two controls on the switch housing SPEED CONTROL DIRECTION CONTROL Pull Chain Switch Reverse Slide Switch (Tug gently) (Up and down) Pull Speed Up for upward air flow...

  • Page 15: Maintenance

    MAINTENANCE The fan natural movements may cause some connections to work loose. A clicking or rattling noise is a certain sign of loosening screws. Check the support connections, brackets and blade attachment twice a year, and tighten all screws as necessary. Make sure all screws attaching the glass screws are tightened. Clean your fan periodically.

  • Page 16: Trouble Shooting

    TROUBLE SHOOTING MAINTENANCE FAN DOES NOT START Check all fuses or circuit breakers. Replace if MISSING. Turn off electrical power and check all wire connections to fan and in switch housing. Make sure pull chain switch is on, and reverse slide switch is up or down, not in the middle.
  • Page 17 FOR 4 BLADES MODELS Numbered tape Switch 3-4 Switch 1-2 Switch 2-4 Switch 4-3 Switch 2-1 placement FOR 5 BLADES MODELS Numbered tape placement Switch 3-4 Switch 2-1 Switch 2-4 Switch 4-3 Switch 2-1 If the above does not eliminate the wobble, clip a balancing kit on any one of blade about the middle of blade edge.
