Summary of Contents for MoxPower power-resq

Page 1 MULTI-FUNCTION JUMP STARTER USER MANUAL Ensure battery is fully discharge prior to the first charging to maximise your battery life. Trademarks All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In association with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd. (Malaysia), Maka Technologies Group (H.K.) Limited &...
Page 2: Safety Information
Safety information To prevent injury to yourself and others or damage to your device, read the safety information about your device before using the device. Warning Failure to comply with safety warnings and regulations can cause serious injury or death. Do not use damaged power cords or plugs, or loose electrical sockets Unsecured connections can cause electric shock or fire.
Page 3 Do not bite or suck the device or the battery  Doing so may damage the device or result in an explosion or fire. • Children or animals can choke on small parts.  If children use the device, make sure that they use the device properly. Do not handle a damaged or leaking Lithium Ion (Li-Ion) battery For safe disposal of your Li-Ion battery, contact your nearest authorised service centre ©...
Page 4 Caution Failure to comply with safety cautions and regulations can cause injury or property damage Do not expose the device to heavy smoke or fumes Doing so may damage the outside of the device or cause it to malfunction. If you notice strange smells or sounds coming from your device or the battery, or if you see smoke or liquids leaking from the device or battery, stop using the device immediately and take it to a Maka Service Centre Failure to do so may result in fire or explosion.
Page 5 Correct disposal of this product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Page 6 Disclaimer Some content and services accessible through this device belong to third parties and are protected by copyright, patent trademark and/or other intellectual property laws. Such content and services are provided solely for your personal non- commercial use. You may not use any content or services in a manner that has not been authorised by the content owner or service provider. Without limiting the foregoing, unless expressly authorised by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device...
Page 7 About this manual This device provides high quality digital recording device using Maka’s high standards and technological expertise. This user manual is specially designed to detail the device’s functions and features.  Please read this manual before using the device to ensure safe and proper use. Descriptions are based on the device’s default settings.
Page 8: Table Of Contents
Table of Contents Product Specifications Getting Started Overview of your MaxPower 9900mAh Power ResQ MaxPower 9900mAh Power ResQ Layout Car Jump Terminal Layout Standard Packaging of your MaxPower 9900mAh Power ResQ Package Contents Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ Jump Start 12V Car Installation Acting as a Backup Battery in your Car Charging your MaxPower 9900mAh Power ResQ...
Page 9: Product Specifications
Product Specifications Smart-Charge Technology  Restore and Recharge MaxPower 9900mAh Power ResQ at the same time by diverting overloaded electricity back to the device. Intelligent Reverse Polarity Protection  Prevents damage to the jump starter if the battery is connected in reverse. ...
Page 10: Getting Started
Getting Started Overview of your MaxPower 9900mAh Power ResQ REAR VIEW FRONT VIEW Figure 1: MaxPower 9900mAh Power ResQ Multi-Function Jump Starter Table 1: Keys of MaxPower 9900mAh Power ResQ Function Power Button Press and hold to turn the device on or off. Output Port 1 Power supply can provide up to 5 Volts @ 1.0 Amps (maximum).
Page 11: Car Jump Terminal Layout
Getting Started Overview of your MaxPower Car Jump Terminal Figure 2: Car Jump Terminal Diagram Table 2: Keys of Car Jump Terminal Function Display OLED display screen that display messages transmitted from the terminal. Car Jump Terminal Port Connect the Car Jump Terminal to the jump starter port. It also acts as a protection against short-circuit, over-voltage, and over-current situation.
Page 12: Standard Packaging Of Your Maxpower 9900Mah Power Resq
Getting Started Standard Packaging of your MaxPower 9900mAh Power ResQ Package contents Check the product box for the following items: • 9900mAh Power ResQ • Operating Manual • Wall Socket Charger • Smartphones Connectors • Laptop Connector Tips Kit The items supplied with the device and any available accessories may vary depending on the region. The supplied items are designed only for this device and may not be compatible with other devices.
Page 13: Jump Start 12V Car Installation
Getting Started Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ Jump Start 12V Car Installation Warning • This power system is to be used ONLY on vehicles with 12 volt DC battery systems. • Read your vehicle owner’s manual first as the manufacturer may have specific steps and precautions that pertain to your vehicle.
Page 14 Getting Started Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ STEP 1 STEP 1 Make sure the battery capacity of the MaxPower 9900mAh Power ResQ is at 50% or more to jump start a vehicle. (At least 2 indicator lights stay ON) Note: Do not use the jump start cable for any other purpose other than jump starting the vehicle.
Page 15 Getting Started Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ STEP 4 STEP 4 Plug in the Car Jump Terminal to the Jump Starter Port. STEP 5 STEP 5 Press start button to turn on Car Jump Terminal. Smart-Charge Technology will begin charging your vehicle’s battery terminal and recharging MaxPower PRESS HERE...
Page 16 Getting Started Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ STEP 6 STEP 6 After a successful start, detach the clamps. First, disconnect the black clamp and then the red clamp in that order. Note: You should be sure to run your vehicle for at least 15 minutes before shutting the engine off again.
Page 17: Acting As A Backup Battery In Your Car
Getting Started Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ Acting as a Backup Battery in your Car MaxPower 9900mAh Power ResQ will keep the PIN codes and settings for radios and navigation systems from getting erased when you disconnect the battery on your car. Warning •...
Page 18: Charging Your Maxpower 9900Mah Power Resq
Getting Started Charging your MaxPower 9900mAh Power ResQ Charging the battery Warning Ensure battery is fully DISCHARGE prior to the FIRST charging to maximise your battery life. MaxPower 9900mAh Power ResQ will take approximately 3 hours to have a full charge. Only charge the product at temperatures between 20°C ~ 60°C.
Page 19: Charging The Your Smartphones/ Laptops
Getting Started Charging your MaxPower 9900mAh Power ResQ Charging the your smartphones/ laptops Charging Smartphones • You may use the USB data cable that comes standard with your phones or choose from the given smartphone charger connector to charge. • Attach the USB connector to Output Port 1 (5V/2A) and dock connector to the bottom of the phone.
Page 20: Operating The Led Touch Light
Getting Started Operating the LED Touch Light Turning on your Touch Light There are 3 modes of LED Touch Light to choose from: Torchlight Burst Flashing STEP 1 Hold on to the Power Button for 3 Seconds. STEP 2 Press on the Power Button again to toggle between the 4 different modes ouchlight/ Burst Flashing/ –...
Page 21: Faq On Maxpower 9900Mah Power Resq
Getting Started FAQ on MaxPower 9900mAh Power ResQ How long does MaxPower 9900mAh Power ResQ take to be fully charged? It will take approximately 3 hours to be fully charged. How long does MaxPower 9900mAh Power ResQ battery last in storage? The battery can last up to 6 ~ 12 months.
Page 22 Copyright Copyright © 2015 Maka GPS Technologies Group including Maka Corporation USA Inc. and its subsidiaries. All rights reserved. MaxPower is a trademark of Maka GPS Technologies Group Group including Maka Corporation USA Inc. in one and more countries. All trademarks mentioned belong to their owners, third party brands, product names, trade names, corporate names.
