Initial Setup

1) Connect power to LiteShow module, and connect a VGA cable from the projector to the LiteShow
VGA connector. If desired, audio can also be connected to the LiteShow Audio connector.
2) Turn on the projector and LiteShow module. Note: When the projector shows the instructions below,
LiteShow is ready for use.
3) Verify that your computer's wireless connection is enabled and connect to the LiteShow wireless
network.
4) Open your browser. Although the LiteShow page should display automatically, you can bring up the
LiteShow page by entering the IP address displayed on the projector into your web browser.
Note: The default IP address of LiteShow is 192.168.100.10.
5) At the LiteShow login screen, enter one of the following combinations to access the downloadable
client software:
Login
None
Basic User
Admin User
9
Default Password
Not applicable – No
password required
basic
admin
