Summary of Contents for ClipperCreek ACS
- Page 1 ClipperCreek, Inc. Innovative Infrastructure for Electric and Hybrid Vehicles User’s Manual • • • • • • • Model ACS...
- Page 2 PLEASE NOTE This user’s manual includes the latest information at the time of printing. ClipperCreek, Inc. reserves the right to make changes to this product without further notice. Changes or modifications to this product by other than an authorized service facility may void the product warranty.
-
Page 3: Table Of Contents
ACS User’s Manual CONTENTS IMPORTANT SAFETY INSTRUCTIONS ......1 Instructions Pertaining to a Risk of Fire or Electric Shock ..1 SAFETY INFORMATION ..........2 FCC INFORMATION ............2 OPERATION ..............3 FRONT PANEL ..............4 INSTALLATION ..............5 Service Connections ............5 Mounting Procedures ............ -
Page 4: Important Safety Instructions
Instructions Pertaining to a Risk of Fire or Electric Shock When using the the ACS, the following basic electrical safety precautions should be followed: • Use this charge station to charge electric vehicles equipped with an SAE-J1772 charge port only. -
Page 5: Safety Information
Those vehicles which follow the SAE-J1772 standard for communica- tion with the charging station can inform the ACS that they require an exhaust fan. The ACS is not equipped to control ventilation fans. Do not charge your vehicle with the ACS if ventilation is required by your vehicle. -
Page 6: Operation
ACS User’s Manual OPERATION The ACS Electric Vehicle Charging Station is a compact wall-mounted charging station that provides the Plug-in Hybrid or Battery Electric Vehicle (together Plug-In Electric Vehicles, or “PEV”) user with a safe and manageable link between the power grid and the PEV. -
Page 7: Front Panel
Charging (green), indicates that AC power is currently applied to the vehicle. Power Fault (red), indicates that the ACS is not wired correctly. The problem can be due to improper grounding or a missing earth ground. The wiring should be examined by a qualified electrician. -
Page 8: Installation
Notice that L1, Neutral & Ground are labeled on each diagram. Those transformer outputs correspond to the same inputs on the ACS. Also, each of the two 3- phase diagrams shows an L2 and an L3 output, which are not used. Do not connect more than one phase of a 3-phase secondary to the ACS. - Page 9 ACS User’s Manual The Neutral at the service panel must be connected to earth ground somewhere in the system on any of the three connection arrangements. Ground-fault protection is not possible unless the Neutral (center-tap on the service trans- former) is connected to an earth ground. If no ground is provided by the electrical service, a grounding stake must be driven into the ground nearby, following local electrical codes.
- Page 10 With a wye-connected secondary, any one of the three legs, in addition Note to neutral, can be used to provide 120V to the ACS. For example, L1 & Neutral, L2 & Neutral, or L3 & Neutral. Be sure the center point is grounded to earth somewhere in the system.
-
Page 11: Mounting Procedures
EVSE can clearly be seen by anyone who will be operating the device. • The ACS has four mounting holes spaced in a 2” wide by 10” tall rectangular pattern. Use a template to mark hole locations on the wall. For Hollow-Wall Construction: •... -
Page 12: Wiring Instructions
ACS User’s Manual Machine screw size #10 hardware is recommended for mounting the ACS. Screw shafts of at least 2” are recommended. The ACS mounting holes are 3/16” in diameter, so ensure that the screw heads do not exceed this size. Place appropriately sized washers between the screw heads and the ACS enclosure mounting flanges. -
Page 13: Specifications
ACS-25 Note that the maximum current for the vehicle is set by the duty cycle of the Pilot waveform. Refer to the ACS serial number label for the specific factory-set maximum current rating. Output Power Variable depending upon the ACS model and vehicle demand. -
Page 14: Customer Support
ACS User’s Manual CUSTOMER SUPPORT Call your ClipperCreek, Inc. Service Representative at any time, 24 hours a day, at the number below. PLEASE HAVE THE MODEL NUMBER AND SERIAL NUMBER AVAILABLE WHEN YOU CALL. This information is printed on the labels on the sides of the device enclosure. -
Page 15: Warranty Information
If this product is defective in materials, manufacture or design during this warranty period, ClipperCreek, Inc. will, at its option, repair or replace the product. Repair parts and /or replacement products may be either new or reconditioned at ClipperCreek’s discretion. - Page 16 ClipperCreek, Inc. 11850 Kemper Rd., Suite E Auburn, CA 95603 www.ClipperCreek.net...
