Adaptive Beta-Brite Programming Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

®
BETA-BRITE

Remote Control

Programming Manual
®
This manual is for the 1026 and 1040 models of the BetaBrite
sign.
®
To find the model of your BetaBrite
sign, turn it off and then on again.
The model number appears as follows:
10404402d EZ95
The first four numbers ("1040") are the model number.
Form No. 9704-0001B
4/02/2001
