- Page 1 Model 3100-1L One Channel Temperature Controller User Manual L-1 Standards and Technology, Inc. www.L-1.biz...
- Page 2 New Windsor, MD 21776-0729 warranties of merchantability and fitness for a particular purpose. L-1 shall not be +1 410-635-3300 Phone liable for errors or for any direct, indirect, +1 410-635-3200 FAX incidental, consequential, or other dam- sales@L-1.biz...
-
Page 3: Table Of Contents
Table of Contents Overview Parts List Identification Setup Software General Specifications... -
Page 4: Overview
Overview The Model 3100-1L Temperature Controller is a precision control unit which provides closed loop temperature control of Peltier thermo-electric coolers/heaters at the <+/- 0.001 °C level. The controller is a microprocessor based unit with an Ethernet inter- face which communicates through TCP/IP. The controller is optimized for use with L-1 Standards and Technology Inc.’s line of temperature controlled detectors which include... -
Page 5: Parts List
Parts List • Model 3100-1L Temperature Controller 1 ea • Model 3100 Temperature Controller One Channel Cable 1 ea • Model 3100 Temperature Controller Power Suppy 1 ea • Manual & Software CD 1 ea Model 3100-1L Temperature Controller User Manual... -
Page 6: Identification
Identification Model 3100-1L Front LCD Screen Displays the temperature set point (SetPt) and current temperature of the connected detector in degrees Celsius. Model 3100-1L Temperature Controller User Manual... - Page 7 Ethernet Provides connection to a computer through an Ethernet cable (not provided). Output Provides connection to a L-1 temperature controllable detector using the Model 3100 Temperature Controller One Channel Cable. DC Power Provides power using the Model 3100 Temperature Controller Power Supply.
-
Page 8: Setup
If a change in set point is needed or if automated recording of the temperatures is desired, connect the temperature controller to a computer using an Ethernet cable (not supplied) and use the Model 3100-1L Temperature Controller Soft- ware. Please refer to the software section of this manual for further details. -
Page 9: Software
Software The Model 3100-1L Temperature Controller can be controlled with computer software written in LabVIEW. Using the provided software with LabVIEW 2012 or higher, a user can modify the temperature set point, change the IP address and user name of the temperature controller, modify various parameters and record data (including temperatures) to file. - Page 10 Running the Model 3100-1L Temperature Controller Software Click the Run button (button with the white arrow in the upper left of the screen underneath the edit menu of the software) of the Model 3100-1L Temperature Controller v1.vi. The Run button starts LabVIEW running.
- Page 11 Verify the IP address on the screen and if needed, change it to match the tem- perature controller’s IP address shown on the LCD screen during system boot up. The preset IP address of the unit is also labeled on the top of the Model 3100-1L Temperature Controller unit upon shipment.
- Page 12 Eth- ernet connection, and IP address. Pressing the OK button will close the pop-up window and stop the Model 3100-1L Temperature Controller v1.vi. When communication is established, the Detector Temperature Control and Manual Commands buttons, which were unavailable during connection estab- lishment, become available.
- Page 13 (Detector Temperature Control v1.vi and Manual Commands v1.vi respectively). When either of these two programs is running, the Stop Communi- cation button and the program buttons are unavailable within the Model 3100-1L Temperature Controller v1.vi. To switch between these two programs, close the current program using the Stop Program button and then click the other program button in the Model 3100-1L Temperature Controller v1.vi.
- Page 14 The time in seconds for writing data to file. Default is 3 seconds. Store Temps Only Button Toggle this button to store all data or store temperatures only. Default is to store temperatures only. Model 3100-1L Temperature Controller User Manual...
- Page 15 The maximum number of data points to be graphed at any one time. Default is 100. Click the Set button to activate. Clear Graphs Button Click this button to clear the DAC Value and Detector Temperature graphs. Model 3100-1L Temperature Controller User Manual...
- Page 16 10 Use the Manual Commands v1.vi to send get and set commands directly to the temperature controller. Manual Commands v1.vi showing the Manual Commands v1.vi showing the Get/Set toggle in the Get position. Get/Set toggle in the Set position. Model 3100-1L Temperature Controller User Manual...
- Page 17 Allows selection of set commands from a drop down list. The Get/Set toggle button must be toggled to Set for this drop down list to be available. The set command is not sent to the temperature controller until the Send button is pressed. Model 3100-1L Temperature Controller User Manual...
- Page 18 01, and the time in 24 hour format was 14:59 when the file was created. The file name is not displayed until it is created after the Send button is pressed for the first time. The file name cannot be changed. Model 3100-1L Temperature Controller User Manual...
- Page 19 The file path cannot be changed on this screen. If you need to change what folder the data file is saved to, see step 3 in the software section of this manual. Model 3100-1L Temperature Controller User Manual...
- Page 20 Stopping Model 3100-1L Temperature Controller Software To stop the Model 3100-1L Temperature Controller Software, first, if open, stop the Detector Temperature Control v1.vi or the Manual Commands v1.vi program by pressing the Stop Program button and wait until the program window closes.
-
Page 21: General Specifications
Operating Environment: Up to 80 % relative humidity, non-condensing Warranty: All goods manufactured by L-1 shall be free from defects in material and workmanship for a period of one (1) year from the date of delivery. The purchaser is responsible for all transportation costs to and from the factory for repair.
