- Page 1 Pico Projector Owner’s Manuel Please read this owner’s manual carefully before operating the unit.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction…………………………………………..2 Safety precautions………………………………….3 Package contents…………………………………...5 Product overview……………………………………6 How to use the projector……………….………11 Troubleshooting..……………………………………23 Specifications………………………………………….25 - 1 -... -
Page 3: Introduction
Introduction LCOS projector technology Latest LED technology 4:3 aspect ratios and 640X480 VGA resolution Built in stereo speaker Built in high capacity battery Support a wide range of media formats - 2 -... -
Page 4: Safety Precautions
Safety Precautions Please read this manual carefully before using your projector and keep the manual handy for future reference. Do： Turn off the machine before cleaning. Use normal glass cleaner and a soft cloth to clean. Operate in low light conditions for best effect If the projector is not to be used for an extended period of time, disconnect the plug from the power outlet. - Page 5 Warning： Do not look into the lens while the projector is on. Serious damage to your eyes could result. Use appropriate power supply. Dropping or jarring your projector can damage internal components. Do not attempt any repair yourself. Safety Certification：UL、CE、CCC, BSMI - 4 -...
-
Page 6: Package Contents
Package contents Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Standard Accessories： Power adaptor Projector AV cable USB cord Tripod Remote control Owner’s manual Optional Accessories： iPad/iPhone out line USB to mini USB converter Micro SD 2G Micro SD 4G - 5 -... -
Page 7: Product Overview
Product Overview Front/Back view 1. Lens 2. Speaker 3. Infrared receiver Left/Right view - 6 -... -
Page 8: Control Panel
1. AV in 2. SPEAKER OUT 3. Volume knob 4. TF card slot 5. ON/OF 6. DC IN 7. USB port Top/Bottom view 1. Vent 2. Focus ring 3. Plastic protection pad 4. Tripod Mount 5. Control panel. - 7 -... - Page 9 : press for 2 seconds to turn on/off : Return to previous menu : Switch between AV/PMP : Up/play the previous file : Down/play the next file : Left/rewind/turn the picture counter clock wise : Left/forward/turn the picture clock wise ENTER: Confirm/Start/Slide mode Remote control This projector comes with an...
- Page 10 MUSIC : Music mode MENU : PMP menu EXIT : back to the previous menu : Up/Down in menu, Next/previous music, Video or picture : Left/Right in menu, rewind/fast forward in music and video mode, turn the picture in picture mode. ENTER : confirm/execute the selection, pause/play in video and music mode, single picture or slideshow in picture mode.
- Page 11 Note：the effective range of the remote control is 8 meters /±30°, please point the remote control at the infrared receiver and stay in effective range（like the ° picture to the right） ° Remote Control This remote control uses CR2025 type battery, please follow the following replacement instructions when replacing：...
-
Page 12: How To Use The Projector
How to use the projector Connection to AV equipment（DVD/set top box） 红色 白色 黄色 Connecting TF card Note：Please make sure the copper connectors are facing upwards when inserting the card： - 11 -... - Page 13 Connecting to USB equipment Connecting to stereo equipment Turn on the power Connect the projector before turning it on (see previous page). - 12 -...
- Page 14 Plug the power cord into the power outlet, the other end into the DC IN on the projector; flip the power switch to “ON”, now the power led should turn red. Press POWER button for two seconds, the power led will turn green, fan will start, and image will appear after 5 second.
-
Page 15: Focusing The Lens
“ON.” It will take over 4 hours to become fully charged. If the projector is not to be used for an extended period of time, flip the power switch on the right to “OFF,” to save power. Focusing the lens Depending on distance, the image will be fuzzy and out of focus sometimes, to correct this, turn the focus ring till the image is clear and sharp. - Page 16 Plug in the Flash disk or TF card. Turn on the projector. The following screen will appear: Use the button on the remote control or the control panel to select Flash disk or TF card. Note: this machine will automatically recognize the disk or card. If no disk or card is plugged in, the picture in the menu will be gray, it will turn larger when plugged in and selected.
- Page 17 Press button on the remote control or control panel to select picture, then press ENTER button to play; or press the photo button on the remote control. While showing, press button to switch to previous/next picture, press button to turn picture.
- Page 18 button, or the VIDEO button on the remote control to play. While video is playing, press button to switch to previous/next video, button to rewind/fast forward, press Enter button to pause/play, and VOL-/VOL+ to adjust volume. Press EXIT button to return to video list, press again to return to main menu.
- Page 19 Open the PowerPoint file in the computer then save it as JPEG file. Then copy the file to flash disk or Micro SD car. Then display the file like pictures. Note：this machine cannot recognize Word, Excel files, user will need to convert those files into pictures (JPG, BMP, GIF etc) to display File Management Press...
-
Page 20: Delete File
press ENTER button to enter the file management menu, now all the files should be listed. Press RIGHT button to reach the following menu： File manager copy to internal? overwrite to internal? delete file? mark all/unmark To copy files, please select copy to internal or overwrite to internal, and press ENTER button to confirm. - Page 21 the setting menu, or press the SETUP button on the remote control. button to select different menu, ENTER button to access the next menu, to change settings； Use EXIT button to return to previous menu and main menu. Settings for each menu are as follows: Picture settings Options Settings...
- Page 22 Size best/fill/full screen 5sec/15sec/30sec/60sec/5min/15min/30 Time per slide Repeat slide loop/once random/chess grid/filling inwards/erase/blind/filling Slide effect line/grid/central cross/spiral/rectangular/off Display Settings Options Settings Display mode full screen/original size Play mode random/loop/once Music Settings Options Settings Play mode loop/single song loop/random/once Sound effect rock/R&B/classical/soft/jazz/rap/normal - 21 -...
- Page 23 System Settings Options Settings Language English/Simplified Chinese Volume 0-10 Reset Version Using the projector to watch DVD and TV Preparation: Connecting the source equipment (DVD, set top box) to the projector. Turn on the projector. Press the source button on the remote or the control panel to watch DVD.
-
Page 24: Troubleshooting
Trouble Shooting Please check the following before asking for assistance： Confirm the appropriate cables are attached； Confirm the power is on； Please check the following if problems persist： Problem Solution Make sure the power switch is ON. Make sure the power led is green. No Power Make sure the battery is charged if not using power adaptor. - Page 25 Make sure the distance and angle is within 8 meters/±30° ※ If problems persist, please contact your distributor or APAC Optical Electronics Inc.; do not service this projector yourself. - 24 -...
-
Page 26: Specifications
Specifications Projector type Multimedia projector Dimension 126(L)x65(W)x25(D)mm Weight 160g Light source Resolution VGA 640X480 Brightness 10 lumen Contrast 100:1 Screen size 7～70inch/0.2～3meter Signal input AV、PMP Audio out Internal speaker 2X1W PHOTO：JPEG、BMP、TIF VIDEO：MJPEG、3GP、AVI、MPEG4、H.263、 Supported H.264 Media Type MUSIC：MP1、MP2、MP3、WMA、AAC、 WAV、PCM、ADPCM Memory card TF、USB（Max 32G）... - Page 27 Operating Temp 5～35℃ Storage Temp -10～60℃ - 26 -...
- Page 28 Manufacturer：APAC Optical Electronics Inc. 3 Tzu Chiang Road, Hsinchu Industrial Park, Hukow, Hsinchu Hsien 303, Taiwan www.apacoe.com.tw Customer service hotline: +886 3 598 6799 You are welcome to comment on our product quality and after sale service. Dealer： Address： Telephone：...
