Oakton 35622 Series Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
9. Warranty
Oakton Instruments warrants this product to be free from significant deviations in
material and workmanship for a period of one year from the date of purchase. If
repair is necessary and has not been the result of abuse or misuse within the warran-
ty period, please return by freight pre-paid and amendment will be made without
charge. The Customer Service Department. will determine if the product problem is
due to deviations or customer abuse. Out-of-warranty products will be repaired on a
charge basis.
10. Return of Goods
Authorization must be obtained from our Customer Service Department before
returning items for any reason. When applying for authorization, please include
data regarding the reason the items are to be returned. For your protection, items
must be carefully packed to prevent damage in shipment and insured against possi-
ble damage or loss. We will not be responsible for damage resulting from careless or
insufficient packing. A restocking charge will be made on all unauthorized returns.
NOTE: We reserve the right to make improvements in design, construction, and
appearance of products without notice.
DISTRIBUTED BY:
OPERATING INSTRUCTIONS
OAKTON
®
35622-series
Printer
Printed in the U.S.A. 9/97

Advertisement

Table of Contents
loading

Summary of Contents for Oakton 35622 Series

  • Page 1 ® 35622-series Oakton Instruments warrants this product to be free from significant deviations in material and workmanship for a period of one year from the date of purchase. If repair is necessary and has not been the result of abuse or misuse within the warran-...

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction Thank you for purchasing an OAKTON 35622-series printer. The OAKTON 35622-series printer is a dot-matrix, impact, micro-printer with built-in internal 1. Introduction ......................3 rechargeable batteries. It prints on standard adding machine type rolls of paper.

  • Page 3: Features And Functions

    The printer’s factory default settings are 9600 baud, 8 data bits with one stop bit and even parity. This matches the default setting on the OAKTON products and should printer in the Specifications sec- DC power connector 25-pin female connector not need to be changed.

  • Page 4: Preparing To Print

    When the paper runs out, see section 3.2 on how to load paper into the printer. Both the ribbon and the paper are available in local office sup- ply stores or from your OAKTON distributor.

  • Page 5: Loading The Paper

    Loading Paper 1. To load paper, first lift the cover plate. 2. Cut the end of the new paper roll into a point. (Figure 3.2.1) 3. Place the paper roll inside printer case. The cut end of the paper must be underneath the roll. (Figure 3.2.2) Slide the cut end of the paper between the two metal Figure 3.2.1 plates inside the printer case.

  • Page 6: Setting Up Printer Parameters

    When shipped, the printer is set to print output from the OAKTON 200 series even parity (2), and 2 stop bits, and that the printer is set to 9600 baud, pH hand-held meter. If you are using the OAKTON pH 2000 or pH 2500 benchtop even parity (2), and 1 stop bit.
  • Page 7 Printing OAKTON pH Benchtop Meter Calibration Parameters 1. While holding down the SEL key, turn the printer power on. If you are using your printer with an OAKTON pH benchtop meter and you 2. Release the SEL key as soon as printer starts printing.
  • Page 8 6. Specifications 7. Troubleshooting Printer: Loading the Ribbon Print modes: HH pH meter, Benchtop pH meter, HH Cond meter, General Sometimes, although cassette is put in correctly, part of the ribbon rides up over the printer head. This may be caused by two reasons: Baud Rate: 9600, 4800, 2400 or 1200 selectable 1.
