This installation guide provides instructions for installing the NIR series
illuminators
Installation Steps
1. Mount Illuminator
2. Connect Illuminator to low voltage
power supply
– Input 12-24V DC/ 24V AC
Optional Set-up (if required)
3. Adjust Power to alter light intensity
4. Adjust Photocell sensitivity
5. Photocell following contact and
Telemetry input
Set Up Steps
1. Position illuminator adjacent to
camera and point towards scene
2. Adjust vertical and horizontal
position of lamp to ensure full field
of view illuminated
3. Tighten all fixings
Package Contents
1. Illuminator including mounting
bracket
Installation Guide
Overview
PLEASE NOTE:
Ensure operating voltage is
correct for unit being installed
(12-24V DC/ 24V AC)
Advertisement
Table of Contents
Summary of Contents for RDPSEC NIR1 Series
-
Page 1: Package Contents
Installation Guide This installation guide provides instructions for installing the NIR series illuminators Installation Steps Overview 1. Mount Illuminator 2. Connect Illuminator to low voltage power supply – Input 12-24V DC/ 24V AC Optional Set-up (if required) 3. Adjust Power to alter light intensity 4. - Page 2 NIR1 Series NIR2 Series NIR3 Series Cables Back of Unit Control Features 1x six core cable NIR1Series Black Wire Red Wire Photocell 2 Core Power = Red & Black wires Photocell Power adjust Adjust 2 Photocell following contact = Orange and Blue wires...
- Page 3 Installation Mount illuminator Connect Illuminator to low voltage power supply: Installers can extend or reduce lead length using appropriate cable and weather proof box. Note: Ensure the White & Green wires for Telemetry are tied together if the illuminator is being used for normal photocell controlled on/off operation Input 12-24V DC/ 24V AC Note:...
- Page 4 Set Up TARGET Position illuminator adjacent to Adjust vertical and horizontal camera and point towards scene position of lamp to ensure full field (Optional night set-up for of view illuminated optimum image performance) Note: Bracket can be positioned at either end of the illuminator (NIR 2 and 3 only) Tighten all fixings Match illumination to camera field of view...
- Page 5 Technical Drawings (Not to scale) Standard Bracketry 1.41” 0.2” 2.56” 2.2” NIR1 2.3” 2.5” 0.3” 4.3” 0.3” 5.5” 1.2” 1.6” NIR2 NIR3 Optional Bracketry Pole Mount Wall Mount...
- Page 6 NIR Specifications Max. Distance NIR1 NIR2 NIR3 Model dependent Consumption 14W max 40W max 80W max Input 12-24V AC/DC 12-24V AC/DC 12-24V AC/DC 1.17A @ 12V 3.3A @ 12V 6.7A @ 12V Current or 0.6A @ 24V or 1.7A @ 24V or 3.3A @ 24V 1.6 lbs 3.5 lbs...
-
Page 7: Troubleshooting
Troubleshooting Ensure all tests are undertaken by a qualified, trained engineer. Ensure safe working practices are followed at all times. Step 1: Basics • Check polarity of Lamp connection red=+ve, black=-ve • Ensure power is 12-24V DC/ 24V AC • Check photocell is working-cover photocell, light should turn on. •... - Page 8 RDP Security Products, Inc 2691 Richter Ave, Suite 124 Irvine, CA 92606 Tel: (949) 336-4522 Fax: (949) 336-4526 www.rdpsec.com NI/12/10.1...
