Summary of Contents for ADT KS-535
- Page 1 CD+ Graphics Karaoke Player with TFT Screen KS-535 Instruction Manual Please read before using this unit.
-
Page 2: Ventilation Warning
WARNINGS CAUTION DRIPPING WARNING The product shall not be exposed to dripping This compact disc player is classified as a or splashing and that no objects filled with CLASS 1 LASER product. liquids, such as vases, shall be placed on the The CLASS 1 LASER PRODUCT label is product. -
Page 3: Important Safety Instructions
WARNINGS NOTE: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of Industry Canada. These limits are designed to provide reasonable protection against harmful Nterference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 4 IMPORTANT SAFETY INSTRUCTIONS 13. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
-
Page 5: Additional Warnings
IMPORTANT SAFETY INSTRUCTIONS Additional Warnings To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. AVERTISSEMENT: POUR ÈVITER LE RISQUE D´INCENDIE OU DE CHOCS ÈLECTRIQUES, NE PAS EXPOSER CET APPAREIL À LA PLUIE OU À ĽHUMIDITÈ Caution Marking was located at bottom enclosure of the apparatus. -
Page 6: Control Locations
CONTROL LOCATIONS TOP PANEL BACK PANEL CD/CDG Door 11. SCREEN ON/OFF Button 20. AUX OUT Socket (L) 2. TFT Screen 12. USB Socket 21. AUX OUT Socket (R) 3. Power Indicator 13. KEY+/PAGE+ Button 22. VIDIO OUT Socket 4. ON/OFF Button 23. -
Page 7: Playing Time
TFT DISPLAY ICON This icon show on TFT. See below:- TRK 8/8 00:16:04 PLAYING TIME REPEAT MODE REPEAT ONE REPEAT ALL REPEAT FOLDER NO REPEAT PROGRAM MODE PROGRAM MODE PLAYING NO PROGRAM MODE PLAY PLAY / PAUSE / STOP INDICATOR PLAYING MODE PAUSE MODE STOP MODE... - Page 8 CONTROL LOCATIONS MASTER VOLUME Rotate to the MASTER VOLUME control to obtain to desired sound level. MIC VOLUME Adjust the MIC VOLUME control to a desired level and obtian the best performance. ● Warning- To avoid Microphone feedback please avoid being too close to the speaker. ECHO Adjust the ECHO control to enhance your voice for a concert hall effect.
-
Page 9: Connecting Power
CONTROL LOCATIONS Connecting Power Plug the supplied power adapter small end into the DC jack located on the rear panel, plug the adapter into the standard AC wall socket. CAUTION: The unit is designed to operate from a mains supply of AC 120V~60Hz. If the adapter does not fit properly, turn it over and again. - Page 10 CONNECTIONS SELECTING YOUR KARAOKE MACHINE AS YOUR SOURCE/INPUT Selecting your Karaoke Machine as a source / input on your TV is very similar to connecting a VCR/DVD or Satellite system. We’ve listed below the most common ways of selecting the source from your TV or VCR / DVD player: In the set up menu of the TV or VCR / DVD player there may be an option for “Input Select”...
-
Page 11: Karaoke Functions
KARAOKE FUNCTIONS Sing along with the music by plugging in the provided microphone into either one of the microphone sockets on the unit. Select MIC VOLUME to adjust the mic volume increase or decrease sound. CONNECTION (MICROPHONE) USING YOUR KARAOKE SYSTEM Warning - Tapping or dropping the microphone while it is on can permanently damage your microphone. -
Page 12: Selecting The Audio Source
USING YOUR KARAOKE SYSTEM ● The currently track number will be show on the TFT display. ● To temporarily stop playing, press the PLAY/PAUSE button. ● To resume play, press this button again. PLEASE NOTE: Pressing pause when a CDG is playing may cause distorted lyrics on the monitor. -
Page 13: Changing The Audio Tone
CHANGING THE AUDIO TONE ● During playback, press KEY+ to raise the key of the music or press KEY- to similarly lower the key. ENTER A TRACK NUMBER TO PLAYBACK ● Press the TRACK button once, first digits is blinking on TFT display. ●... -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION No power when POWER AC adaptor is not plugged into a Plug the AC adaptor into a wall is on. wall outlet or the connector is not outlet and plug the connector into plugged into the power supply jack the supply jack on the unit. - Page 15 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION No sound - when audio • Source Selection on your stereo • Select AUX IN as the source for is connected to a home is not set properly your home stereo stereo. • Improper Connection to stereo •...
-
Page 16: Specifications
SPECIFICATIONS Audio Section Output power 1.2W + 1.2W RMS Output impedance 8 Ohms CD player Frequency response 100 Hz - 20 kHz Signal - to - noise ratio 50 dB Number of programs 20 STEPS RANDOM ACCESS PROGRAMMING Sampling system 8 TIMES OVER SAMPLING Microphone -73 dB 600 OHMS IMPEDANCE WITH...
