Summary of Contents for Solar Skies Stainless Tank Series
- Page 1 Solar Skies Stainless Tank Series Water Heater •Installation •Operation •Maintenance Solar Skies Stainless Tank Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN • Ph 320-762-1151 Fax 320-762-1460 56308 CD1051A.doc Last Revision: 1/31/2011...
-
Page 2: Table Of Contents
Part 5 – Troubleshooting ..........18-20 NOTICE Solar Skies Mfg., LLC reserves the right to make product changes or updates without notice and will not be held liable for typographical errors in literature. - Page 3 WATER TEMPERATURE ADJUSTMENT If the Solar Skies Stainless Tank Series Water Heater is going to have a set temperature above 120 F, you must use a rated thermostatic device to avoid severe burns or death from scalding temperature.
-
Page 4: Part 1: Product And Safety Information
PART 2: GENERAL INFORMATION PREFACE The Solar Skies Stainless Tank Series Water Heater will help to reduce the nation's dependence on polluting fossil fuels. The Solar Skies Stainless Tank Series Water Heater is reliable, with a system performance that runs efficiently based on your specific region in the country. -
Page 5: Part 3: Solar Water Heater Installation
The differential controller uses 10k ohm thermistors or 1k RTDs, depending on the controller model, to monitor the temperature difference between the collector and the Solar Skies Stainless Tank Series Water Heater. The controller turns on the pump when the collector is 8–20° F above tank temperature and turns off when the differential drops to 4°F. -
Page 6: Potable Water Piping
Potable water piping is located on the side of your Solar Skies Stainless Tank Series Water Heater and marked Hot and Cold. It is recommended that unions or flexible copper connectors be used so heater can be easily serviced. - Page 7 THESE CONNECTIONS ARE FOR NON-POTABLE HEAT TRANSFER FLUID LOOP. DO NOT MAKE POTABLE WATER CONNECTIONS TO THESE FITTINGS. DO NOT INTRODUCE NON-POTABLE HEAT TRANSFER FLUIDS INTO ANY OTHER TANK FITTING. Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN •...
-
Page 8: Solar Heat Exchanger Piping
Compare the temperature readings in the two line thermometers. The ¾" cold water supply line to the Solar Skies Stainless Tank Series Water Heater must be insulated with a minimum 7/8" x 1/2"... - Page 9 15. Tank Sensor The tank sensor is wired to the solar controller and measures the temperature on the bottom of the Solar Skies Solar Water Heater. The tank sensor is used in conjunction with the solar collector sensor to turn the circulating pump on and off at the solar control preset temperature differentials.
- Page 10 18. Hot Water Outlet Each Solar Skies Stainless Tank Series Water Heater has a hot water dip tube outlet which draws water from the very top of the heater. This helps keep heat trapped inside the highly insulated storage tank.
- Page 11 SOLAR SKIES STAINLESS TANK SERIES WATER HEATER WITH SOLAR COLLECTOR Solar Skies Stainless Tank Model with Solar Collector (Electric Back-up) NOTES: THIS DRAWING IS MEANT TO SHOW A YSTEM PIPING CONCEPT ONLY. THE INSTALLER IS RESPONSIBLE FOR ALL EQUIPMENT AND DETAILING BY LOCAL CODES.
-
Page 12: Electrical Connection
The heating element in the Solar Skies Stainless Tank Series Water Heater is wired to junction box inside the jacket in the front of heater for 240 volt / 4500 watt A.C. The voltage requirement and wattage load for the heater are specified on the heater identification plate. -
Page 13: Thermostat Adjustment
Solar Tank Fill the solar tank with water by opening the cold water isolation ball valve. See Fig. 4. Inspect all fittings for leaks. Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN • Ph 320-762-1151 Fax 320-762-1460 56308 CD1051A.doc... - Page 14 Turn the circulating pump off by shutting down the power to the solar control and contact your installation contractor. Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN •...
- Page 15 6" above a drain where any discharge will be clearly visible. Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN • Ph 320-762-1151 Fax 320-762-1460 56308 CD1051A.doc...
-
Page 16: Part 4: Maintenance
46 Gal All tank dimensions are approximate. Solar Skies Mfg., LLC reserves the right to make product changes or updates without notice. Solar Skies Mfg., LLC will not be held liable for typographical errors in literature. For questions, please consult the factory. - Page 17 Installation Manual PART 4: MAINTENANCE SOLAR SKIES STAINLESS TANK SERIES WATER HEATER (w/Electric Back-up) PARTS BREAKDOWN Item Description Qty. O-Ring-Electric Element (#213 EDPM Electric Element (w/O-Ring) Upper Thermostat Control Thermodisc Mounting Clip Green Ground Wire w/Ring 5/16-18 Hex Nut - Thermodisc Mounting...
-
Page 18: Part 5: Troubleshooting
CAUTION **For your safety, DO NOT attempt repair of electrical wiring, thermostat, heating element or other operating controls. Refer repairs to qualified service personnel. Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN • Ph 320-762-1151 Fax 320-762-1460 56308 CD1051A.doc... -
Page 19: Maintenance Notes
____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ Solar Skies Mfg, LLC 106 Donovan Drive • Alexandria, MN • Ph 320-762-1151 Fax 320-762-1460 56308 CD1051A.doc Last Revision: 1/31/2011... -
Page 20: Service Information
Phone Number ____________________________________________________________________ Emergency Number ________________________________________________________________ Contractor Name __________________________________________________________________ Address _________________________________________________________________________ Phone Number ____________________________________________________________________ Emergency Number ________________________________________________________________ The Solar Skies Stainless Tank Series Water Heater Is manufactured by HTP, Inc. 120 Braley Rd. P.O. Box 429 East Freetown, MA 02717-0429 Solar Skies Mfg, LLC 106 Donovan Drive •...
