Installation and Service Manual
"IHR/ISHR/HR/HRDV/R" SERIES
INDOOR/OUTDOOR SYSTEMS AND
INDIVIDUAL DUCT FURNACES
Read These Instructions Before Installation
Inspect unit on arrival for any shipping damage. This unit has been
test fired for at least 15 minutes to prove out all phases of operation.
If any part is missing or damaged, notify the carrier at once.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or death. Read the installation, opera-
ting and maintenance instructions thoroughly before installing or
servicing this equipment.
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don't touch electrical switches
3. Extinguish any open flame.
4. Immediately call gas supplier
Notice
WARNING
The use and storage of gasoline or
other flammable vapors and liquids in
open containers in the vicinity of this
appliance is hazardous.
FOR YOUR SAFETY
ISIRHS-1
February 2010
Advertisement
Table of Contents
Related Manuals for Hastings IHR series
Summary of Contents for Hastings IHR series
- Page 1 ISIRHS-1 February 2010 Installation and Service Manual “IHR/ISHR/HR/HRDV/R” SERIES INDOOR/OUTDOOR SYSTEMS AND INDIVIDUAL DUCT FURNACES Notice Read These Instructions Before Installation Inspect unit on arrival for any shipping damage. This unit has been test fired for at least 15 minutes to prove out all phases of operation. If any part is missing or damaged, notify the carrier at once.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page HRDV Dimension………………………………………………………………………………………. (IH) (ISH) (H) RHF (IH) (ISH) (H) RMU and ((IH (ISH) (H) RHV Unit Dimensions..... (H) RHF and (H) RHV Unit Dimensions with Optional Intake and Discharge Plenums and Curbs……………………………………………………………......(H) RMU and (H) RHV Unit Dimensions with Optional Discharge Plenums and Curbs………………………………………………………………...... -
Page 3: Hrdv Dimension
“HRDV DUCT FURNACE” Dimensions ISHRDV, IHRDV, HRDV MODEL NO. 30 5/8 30 5/8 41 3/8 41 3/8 52 1/16 52 1/16 65 1/2 28 3/4 28 3/4 39 1/2 39 1/2 52 7/8 21 7/8 21 7/8 32 5/8 32 5/8 43 3/8 43 3/8 56 7/8... -
Page 5: (H) Rhf And (H) Rhv Unit Dimensions With Optional Intake And Discharge Plenums And Curbs
(IH) (ISH) (H) RHFA - (IH) (ISH) (H) RMUA (IH) (ISH) (H) RHFB - (IH) (ISH) (H) RMUB (IH) (ISH) (H) RHVA (IH) (ISH) (H) RHVB 1000 1600 1200 103-1/2 110-1/2 110-1/2 113-1/2 120-1/2 120-1/2 30-5/8 41-3/8 52-1/8 65-1/2 30-5/8 41-3/8 52-1/8 65-1/2... - Page 6 Dimensions - Roof Curbs for Intake and Discharge Plenums. OUTLINE OF UNIT WITH PLENUMS NOTES: 1. Inlet plenum is shown for units with mixing BLOWER SUPPORT dampers. This includes louver assembly, FURNISHED FOR drain pan and fresh air intake with birdscreen. (H) RHVA 600 AND 800 For 100% return air applications, inlet plenum AND (H) RHVB-1000...
-
Page 7: (H) Rmu And (H) Rhv Unit Dimensions With Optional Discharge Plenums And Curbs
"HR/R" OUTDOOR SYSTEMS Dimensions - (H) RMU and (H) RHV Models with Discharge Plenums Only. FRESH AIR INTAKE REMOVABLE PANEL WITH BIRDSCREEN FOR DUCT CONNECTION AND INSPECTION OPTIONAL INTAKE DAMPER DISCHARGE AIR DUCT DUCT DUCT CONNECTION - 1" FURNACE DISCHARGE BLOWER FURNACE FLANGE TURNED UP... -
Page 8: Shipping
(H) RMUA – (H) RHVA (H) RMUB – (H) RHVB 100 & 125 160 & 210 250 & 300 600 & 800 500 & 600 1000 & Up 20-15/16 31-11/16 42-7/16 55-7/8 117-7/16 42-7/16 55-7/8 117-7/16 24-7/16 35-3/16 45-15/16 59-3/8 120-15/16 45-15/16 59-3/8... -
Page 9: Installation
INSTALLATION 1. The unit may be installed on a field fabricated mounting frame or support, a factory roof curb mounting frame or a slab. The following items are important in this regard: A. Be sure that roof joist or support will not interfere with discharge and return air ducts. B. -
Page 10: Location
7. Air flow through the furnace may be in either direction. However, on units with an air distribution baffle assembly, the air flow must enter the furnace from the baffle side. If entering air is desired from the opposite side, the baffle assembly must be relocated to that side of the heat exchanger. -
Page 11: Electrical
1. The (I) (IS) HRDV Furnace has been designed for INDOOR OR HRDV FOR OUTDOOR INSTALLATIONS. 2. Refer to items 1, 2, 5, 6, 9, 10 12, 15, and 16 of INSTALLATION PRECAUTIONS. 3. REQUIRED MINIMUM CLEARANCES to combustible material are as follows: CLEARANCES/INSTALLATION Outdoor Models The minimum clearances from combustible material are as follows:... -
Page 12: Venting
VENTING 1. The (I) (IS) HRDV model furnace is equipped with a power venter and is complete as received. 2. No further venting of unit is required for outdoor installation (HRDV). 3. Indoor units (I) or (IS) are equipped with a blocked vent switch (VS-1) to shut off the main burners in the event the vents are blocked sufficiently to prevent proper operation of the burners. - Page 13 "VENTING" INDOOR DUCT HEATER WITH SEPERATED COMBUSTION OR INDOOR HEATING SYSTEM Positive pressure vent flue required inside building 8" Dia. Vent Pipe Type "B" recommended...
- Page 14 "VENTING" INDOOR DUCT HEATER OR INDOOR HEATING SYSTEMS Positive pressure vent flue required inside building 8" Dia. Vent Pipe Type "B" recommended...
-
Page 15: Gas Supply Piping
TABLE II I(S)HRDV HORIZONTAL FLUE SIZING Unit Type Flue Pipe Diameter Maximum Length of Flue Pipe I(S)HRDV-100 4.0 IN 82.0 FT I(S)HRDV-125 4.0 IN 82.0 FT I(S)HRDV-160 4.0 IN 82.0 FT I(S)HRDV-210 6.0 IN 72.0 FT I(S)HRDV-250 6.0 IN 72.0 FT I(S)HRDV-300 6.0 IN 72.0 FT... - Page 16 8. A 1/8 N.P.T. plugged tapping, accessible for test gage connection, must be installed immediately upstream of the gas supply connection to the appliance. 9. The furnace must NOT be operated without a leak limiting orifice installed in the unit pressure regulator vent, if applicable.
-
Page 17: Operation Of Mechanical Modulating Valve
OPERATION When the unit is in the winter mode, the fan is on bringing outside air into the building. The furnace is on and the modusnap valve is set at 73 degrees (room set a 70 degrees – example), the modusnap valve is modulating at this point maintaining the discharge of 73 degrees. -
Page 18: Operation Of Electronic Modulating Valve
ELECTRONIC IGNITION All (I) (IS) HRDV series furnaces are equipped with a solid state design, intermittent pilot ignition system. This electronic system consists of an ignition control module, combination pilot burner/igniter-sensor (sensor or flame rod) assembly, and igniter-sensor lead. Activated by the units 24V transformer and controlled by a field installed thermostat or controller, module will first perform a safe-start check which tests its internal components for a false pilot flame condition. - Page 19 d. Remove the screws from bottom flange of the collector box. Remove the two screws from the venter motor support at the right heater leg and disconnect the three conductor cables at the junction box. Lift collector box off. (Power venter assembly will remain attached to the collector box.) e.
- Page 20 · Additional Maintenance Procedures: 1. Motors should be relubricated according to the manufacturer’s lubrication instructions. 2. Filters must be cleaned (cleanable type) or replaced (throw-away type) with like filters as often as necessary so as not to restrict air delivery. 3.
- Page 21 SUGGESTED REGREASING INTERVALS SERVICE MOTOR HORSEPOWER UNDER 50 50-100 100 UP 3-5 Yrs. 2-4 Yrs. 2 Yrs. 2-4 Yrs. 1-1/2 Yrs. 1-1/2 Yrs. 1-2 Yrs. 1 yr. 6 Mos. 4 Mos. 4 Mos. 3 Mos. SERVICE TYPE OF SERVICE SYMBOL Infrequent operation or light duty in clean atmosphere.
- Page 22 NATURE OF TROUBLE CORRECTIVE MEASURES 5. Improper pilot. Flame either too small or flame “lifts.” If pilot is too small, clean pilot line, primary air openings, and pilot orifice. If flame lifts, reduce gas pressure. For both conditions, adjust pilot flame to surround end of flame rod about 3/8”.
- Page 23 NATURE OF TROUBLE CORRECTIVE MEASURES Faulty system ground, flame sensing circuit, If ground is poor, nuisance shutdowns may occur wiring/connections. occasionally even though burner operation is normal at the time of an inspection. Test continuity of ignioter lead and ignition module ground wire. Correct as necessary. as necessary.
- Page 24 Periodic service on any piece of mechanical equipment is necessary for efficient operation. If a service problem arises, Hastings HVAC, Inc. has a technical service organization available to provide professional assistance to help you with a solution to that problem. Two inbound Watts lines to the home offices enables you to consult with qualified factory service personnel.
