Neve 2264ALB User Manual

Neve 2264ALB User Manual

Limiter compressor

Advertisement

Quick Links

2264ALB
Limiter
Compressor
User Manual
527 – 402
Issue 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2264ALB and is the answer not in the manual?

Questions and answers

Summary of Contents for Neve 2264ALB

  • Page 1 2264ALB Limiter Compressor User Manual 527 – 402 Issue 1...
  • Page 2: Health & Safety Notice

    © 2009 - 2012 AMS Neve Ltd own the copyright of all information and drawings contained in this manual which are not to be copied or reproduced by any means or disclosed in part or whole to any third party without written permission.
  • Page 3: Table Of Contents

    2264ALB Limiter / Compressor Issue 1 Table of Contents Health & Safety Notice..................2 Introduction......................4 Front Panel Controls....................5 LIMIT THRESHOLD....................5 LIMIT RECOVERY....................5 LIMIT IN / OUT....................5 COMPRESS THRESHOLD..................5 COMPRESSION RECOVERY...................5 COMPRESS IN /OUT................... 5 GAIN MAKE UP....................5 RATIO COMPRESS....................
  • Page 4: Introduction

    2264ALB Limiter / Compressor Issue 1 Introduction The 2264A LB Limiter / Compressor facilities and performance are similar to those of a 2254/R Limiter Compressor. The main advantages of the 2264A LB are it's smaller size and compatibility with Lunchbox...
  • Page 5: Front Panel Controls

    2264ALB Limiter / Compressor Issue 1 Front Panel Controls LIM THR, REC, LIM I/O (Limiter Section) This is a 3-function group of controls comprising the following functions: LIMit THReshold The inner grey knob, variable from +4dBm to +15dBm, controls the threshold at which the limiting effect takes place.
  • Page 6: Bypass / In

    2264ALB Limiter / Compressor Issue 1 BYPASS / IN When in BYPASS this switch connects the Input directly to the Output, in effect bypassing all of the unit's circuitry. When set to the IN position, the unit is in circuit.
  • Page 7: 2264 Operation

    2264ALB Limiter / Compressor Issue 1 2264 Operation LIMITING – ATTACK TIME This unit has a limiting attack time of 4msec. This slow attack time is used on programme material of moderately percussive nature, such as a solo piano. With this attack time a very narrow dynamic range can be achieved by feeding high levels into the limiter while using a low limit level.
  • Page 8: Compress Ratio

    2264ALB Limiter / Compressor Issue 1 COMPRESS RATIO Five compression ratios are provided: • 1.5:1 • 2:1 • 3:1 • 4:1 • 6:1 The characteristic is shaped such that the onset of compression is smooth and progressive, the true ratio being established within about 6dB above the threshold point.
  • Page 9: Limiter & Compressor In Combination

    2264ALB Limiter / Compressor Issue 1 Limiter & Compressor in combination When both of the LIMIT and COMPRESS switches are set to IN, the sidechains controlling limiting and compressing will be operative. Under these conditions, the compressor is effective below +8dBm only, because at this point, the limiting action will take over complete control.
  • Page 10: Insert Mode

    2264ALB Limiter / Compressor Issue 1 Insert Mode It is possible to use the 2264A LB in conjunction with the 1073LB Microphone Pre-amplifier module, with the 2264A LB functioning as an inserted processor within the 1073LB. To enable this mode, the DIP-switch settings on the rear of both modules need to be changed.
  • Page 11: Configuration Examples

    Issue 1 Insert Mode Configuration Examples There are four possible configurations possible when using multiple AMS Neve units in Insert Mode. Either a 2-way or 3-way INS LINK cable is required depending on the configuration. The signal processing order is changed by physically moving the units within the rack.
  • Page 12: Unit Specifications

    2264ALB Limiter / Compressor Issue 1 Unit Specifications General Input 10,000 Ω, bridging, balanced and earth-free. Balanced and earth-free. Output Maximum output into 600 Ω: 26 dBm. Nominally 0 dBm. Gain Compress & Limit thresholds are defined in relation to the output level when terminated to 600 Ω.
  • Page 13: Recall Sheets

    2264ALB Limiter / Compressor Issue 1 Recall sheets - 13 -...
