  • Page 1 Digital Dimmer User´s Manual Version 1.40...

  • Page 2: Table Of Contents

    10. Declaration of Conformity..............18 11. Appendix .................... 19 12. Index ....................20 2 2 2 2 2 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 3: Introduction

    1. Introduction The MA DIGITAL DIMMER contains a 32 bit high power computer with a Time Processing Unit and a big graphic display in a very solid housing. This extravagant technology offers new and exciting...

  • Page 4: Quick Manual / Function And Controls

    Programming is only possible by pressing a button and turning the encoder at the same time. 4 4 4 4 4 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 5: Overview Of Functions

    Menu s.4.2 Cha. Menu Curve Menu s.4.4.9 Memory Save Menu Menu s.4.3 000,3 Menu Chase Menu s.4.3..Save Menu 5 5 5 5 5 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 6: The Menus

    (channel menu) recalled after power off. Exception: Dimmer is in "-locked mode-" 6 6 6 6 6 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 7: The Channel Menu (2Nd Menu)

    Exception: When the Dimmer is just working in "normal user" mode, the button switches back to the Top menu. 7 7 7 7 7 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 8: The Memory Menu (3Rd Menu)

    "Save" returns to the Memory menu. The "menu button" leads to the Top menu. 8 8 8 8 8 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 9: The Setup Menu (Supervisor Menu)

    The 2nd DMX channel controls the dimmer channels 6...12. Examples and a table can be found in the appendix of this manual. 9 9 9 9 9 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 10: Dmx/Midi (Switch Between Dmx And Midi)

    Attention! All data will be deleted ! Be careful in using this function, because it may be hard work to reprogram all functions. 10 10 10 10 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 11: 4.4.9 Curve User (User Definable Control Curves)

    DMX interface. This function will only be usable when the new DMX norm is finished. Every dimmer will then need to have its own address (unit number). 11 11 11 11 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 12: Starting The Dimmer

    If the phase and neutral are exchanged for a longer time (>15min.), the dimmer can be damaged. 12 12 12 12 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 13: Dmx Connections

    The real depth varies according to the used connector, cable outlet and cable. It increases by up to 100mm. Weight: 30 kg (2,3 kW); 35 kg (3,7 kW, 5,7 kW) 13 13 13 13 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 14: In- And Outputs

    The MIDI THRU socket is necessary to send the MIDI data to further dimmers or other MIDI equipment. 14 14 14 14 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 15: Link In- And Output

    Reason: The Socapex connector has no earth contact which is conducting at first.! At any rate the connectors should only be moved when the dimmer is switched off! 15 15 15 15 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 16: Opening The Dimmer (Service)

    Tilt to the top and pull afterwards to the front. pull 3 cm to the front 16 16 16 16 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 17: Important Safety Instructions

    E. The unit fell down and the case was damaged. Please note! For transportation please make sure the protection is fixed! 17 17 17 17 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 18: Declaration Of Conformity

    Waldbüttelbrunn, Nov. 11st, 1995 Dipl. Ing. Michael Adenau 18 18 18 18 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...

  • Page 19: Appendix

    011111 ..98 % ( 96.8750 % ... 98.4375 %) 111110 ..49 % ( 48.4375 % ... 50.0000 %) 111111 ..FF % ( 98.4375 % ..100.0000 %) 19 19 19 19 eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Digital Dimmer...

  • Page 20: Index

    Program change 10 Programming of memories 8 Go button 8 Preheat 7 Quick Manual 4 20 20 20 20 MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de...
