HomeRemote HRDS1 Installation Manual

HRDS1
WIRELESS DOOR/WINDOW
SENSOR
INSTALLATION
GUIDE
Having problems installing
your product?
Call us at: 888-202-3344
SUPPORT www.HawkingTecH.cOm
Email: support@hawkingtech.com
Rma infORmaTiOn
Website: www.hawkingtech.com/support
http://www.hawkingtech.com.com/rma.php
24-HOUR TecHnical SUPPORT
SaleS infORmaTiOn
800-202-3344 (Toll Free US & Canada)
sales@hawkingtech.com
949-790-0810 (International)
Hawking is a registered trademark or Hawking Technologies, inc. ©2007 Hawking Technologies, inc. all rights
reserved. Other brands and product names are trademarks or registered trademarks of their respective owners.
INTRODUCTION
Thank you for choosing the Hawking HomeRemote Wireless
Door / Window Sensor. This module is an accessory of the
HomeRemote and HomeRemote Pro Home Monitoring Sys-
tems and enables detection of opened or closed access loca-
tions in your home.
PRODUCT DESCRIPTION
Below is a description of the buttons, lights and plugs for the
HomeRemote Door / Window Sensor.
Front Back
Contact Magnet
LED
Contact Magnet - Used to detect when doors or windows are
open. Magnetic contact is placed next to the Door / Window
Sensor.
Program Button - Pressing this button down will put the
Door / Window Sensor into "Program Mode" (used during
installation). .
LED - The light will blink to indicate that the module has en-
tered "Program Mode" or when it is communicating wirelessly
to the HomeRemote Gateway.
Battery Lid / Screw - Located on the back of the Door Sen-
sor, the battery lid is fastened by the battery lid screw on the
bottom of the unit. Remove this lid to install the batteries for
the Door / Window sensor. (See Instructions on right)
WHAT IS Z-WAVE?
Z-Wave is a state-of-the-art wireless technology used as a standard for
wireless home control. It is a next-generation wireless "ecosystem" that
lets all your home electronics talk to each other, and to you, via a con-
troller or gateway. It uses simple, reliable, low-power radio waves that
easily travel through walls, floors and cabinets.
WIRELESS RANGE & FEATURES
The HomeRemote Door Sensor is made wireless by Z-Wave technology.
Typical range for a wireless module is approximately 100 feet. Obstruc-
tions between the module and the controller may have a negative
effect on wireless performance and range. When installing the module
consider an open area with little obstructions for the best signal and
Program Button
performance.
Battery Lid
PACKAGE CONTENT
HomeRemote Wireless Door Sensor
Battery Lid

Installation Guide

Screw
Mounting Kit
3 x AAA Batteries
INSTALLTION REQUIREMENTS
Phillips Screw Driver
HomeRemote Pro Gateway or
HomeRemote Gateway, or
Door Sensor Compatible Z-Wave controller
Installation Continued on Back Side....
