Summary of Contents for Midland Valley FieldMove Clino

Page 2: Table Of Contents
Contents This is a guide to using FieldMove Clino and the FieldMove Clino Pro features. Introduction Disclaimer Important safety note. Definitions Glossary of terms used in the app and their definitions. Side Panel Navigation between the app pages. Compass / Clino Setting a bearing using the compass and recording planar and linear data.
Page 3: Introduction
Introduction FieldMove Clino is a digital compass-clinometer for data capture on smartphones. The app allows an iPhone or Android phone (see the Android user guide) to be used as a traditional hand-held bearing compass and clinometer for measuring and capturing the orientation of planar and linear features in the field.
Page 4: Disclaimer
Your phone service provider is not the provider of the FieldMove Clino App. Midland Valley accepts no liability or loss, resulting from the use or misuse of this product.
Page 5: Definitions
Definitions Terms used in FieldMove Clino Project A project is a set of localities, structural data, notes and images related to a specific mapping area. When exporting data it is the whole project that is exported. Localities Localities are a way of grouping data and are user definable. For example, localities can be applied to an outcrop or for a new day in the field.
Page 6: Side Panel
Keeps a chronological record of data captured and allows georeferenced notes and photos to be taken, which can be edited and deleted. Displays structural data on online and offline maps, and in FieldMove Clino Pro, allows line drawing. Stereonet Available in...
Page 7: Compass / Clino
Compass / Clino Compass / Clino page Navigate to the Compass / Clino page from the Side Panel. A hand bearing compass or clinometer face will be activated. The active face can be switched between by tapping on the small face. Note: always give the compass and clinometer a few seconds to stabilize before tapping the clinometer to lock...
Page 8 GPS or set by the user. Automatic positioning using the GPS and updates FieldMove Clino uses the iPhone’s inbuilt GPS unit for two tasks:  Finding your location when taking a reading.
Page 9 Compass / Clino Setting location manually Location Locations can be set manually without using the GPS functionality, in Degrees / Minutes / Seconds, from the Compass / Clino page. On the Compass / Clino page tap on the latitude / longitude (lat / long) value in the Top Bar this will open the lat / long Edit Location page.
Page 10 Stratigraphy can be imported from pre-existing FieldMove Clino projects or from Move as .csv files. Press the import icon to open the Import page. Tap the cross icon to cancel import.
Page 11: Data Type
Tap any symbol to assign it to the current data or tap above to dismiss. FieldMove Clino Pro this list can be customized: Select the Settings icon . This opens the list of currently collectable planar and linear data types.
Page 12: Notes & Images
Notes & Image page Editing structural data FieldMove Clino does not allow the user to modify existing structural readings; however the rock unit, data type, comment and location can be edited. The rock unit and comments can be edited in the same way as on the Compass / Clino page.
Page 13: Screen Options
Notes & Images Editing localities Edit and Delete When editing a locality, the user can change the name, description, colour and location. The colour of localities defaults to grey, and has no association to rock units. The colour can by selected by tapping the colour square next to the locality name.
Page 14 Notes & Images Note Creating notes allows the user to write longer descriptions which would normally feature in a field notebook. An image can be attached to the note by tapping the camera icon . The image can be selected from the camera roll, or a new photo can be taken. Tap the tick icon when complete.
Page 15: Map
Choose which map is used as the base map from the drop down menu. Refer to Importing Map section for more information. Drawing FieldMove Clino Pro allows lines and polygons to be drawn on the map. Tapping the Drawing option activates drawing mode.
Page 16 Drawing Line style and width Tap to choose the style of the line. Lines can be solid, dotted or dashed. Long press and slide up to activate width. Slide a finger horizontally over the button to adjust the line width. Line or polygon drawing...
Page 17 Active or Idle GPS When the black arrow is displayed, the map will centre on the current location and will keep your position centred in the map as you move around your mapping area. Tapping again, the map will spin to show facing direction This means the map will be rotated to match your orientation.
Page 18 Tap the Base Maps icon. Satellite display Select Edit Base Maps. All the maps that are added to the FieldMove Clino Documents folder, via iTunes, will be listed here as New Maps. Tap on the icon to add the selected map to the current Project Map List.
Page 19 Import MBTiles files into FieldMove Clino Once images are saved in the MBTiles format, they can be added to the FieldMove Clino Documents folder via iTunes. In iTunes, to add the files to the documents folder, select the Add...
Page 20: Stereonet
Stereonet Stereonet The Stereonet page in FieldMove Clino Pro allows the user to view structural data on an equal area or equal angle stereonet. The user can use filters to display a subset of the collected data. Mean Dip / Azimuth This option displays the mean resultant plane of all the planar data visible on the stereonet.
Page 21: Project
Project Project Details Locality Prefix By default this is Locality #. Changing the locality prefix changes the default names given to localities when they are created. The hash (#) indicates the position of the number in the name. If it is excluded the locality number will just be appended to the prefix given.
Page 22 Project Deleting a locality Locations can be deleted from the edit location page accessed from the notebook, as well as swiping from right to left on a locality in the Project Details page. Note that the active locality cannot be deleted. Change the active locality from the Compass / Clino or Notes &...
Page 23: Switch Project
Plug the iPhone in so it is linked to iTunes. Go to the app page in the iPhone folder and find FieldMove Clino. Now drop the .fm.zip file into the app directory. Once this is finished copying across to the app, eject the iPhone.
Page 24: Deleting A Project
Switch Project New Project Create a new project, this opens the Project Details page. Deleting a Project To delete a project, navigate to the Switch Project page and select the information icon for the project you wish to delete. This will display the project details. Scroll to the bottom and select Delete Project.
Page 25: Settings
The version of the app currently installed on your iPhone. Please provide this information along with your operating system when reporting bugs. Acknowledgements This lists copyright notices for the third party software libraries used by FieldMove Clino. Tap the tick icon when complete.
Page 26: Export
The device may need to be synced to see these options. Scroll down to the list of apps and select FieldMove Clino. A list of associated documents will appear on the right-hand column. Select the files to copy from the iPhone and click Save to.
Page 27 Export Opening exported projects CSV files are comma delimited and store georeferenced point data and photo locations. The first line of each file gives the column titles. Each .csv file contains a single data type, and is named as such. For example, all localities are saved localities.csv and plane data is stored in planes.csv.
Page 28: Digital Compass Calibration
We are reluctant to recommend specific devices to run FieldMove Clino, however there are significant variations in the quality of the components that are currently being used by the various manufacturers, and we feel strongly that we should make users aware of some of our recent findings.
Page 29 We have found that some devices do not correctly report inclination. This is obvious when a device is on a flat horizontal surface, yet FieldMove Clino still reports a dip. We believe this is due to components in the device not being seated properly, as we have tested other devices of the same make and model and not observed any problems.
Page 30: Faqs
Base maps can be loaded into the app as MBTiles files. Use iTunes to import the MBTiles file into FieldMove Clino. Base maps are added to a project from the Edit Base Maps option in the Map page. The active base map can be selected from the base map list and is indicated with a tick.
Page 31 All data can be viewed in the Notes & Images page, which can be opened from the Side Panel. In FieldMove Clino Pro data can be filtered and displayed on a stereonet. Data can also be viewed on the Map.
Page 32 Frequently Asked Questions How do I use FieldMove Clino offline? FieldMove Clino requires online connectivity for the basic maps (satellite or street views) and for accessing Dropbox. If you disable online connectivity, the map view will still work but will only show a basic grid in places where there is no cached data. Please note that activating airplane mode will also turn off the GPS.
Page 33: Our Experience
Our Experience Collecting data on folded Devonian sediment at Ardmore Point The following comments are based on our experience of testing FieldMove Clino with an iPhone 5 running iOS 7. Hardware Battery can last for a full field day (~8hours, with the GPS on but when other apps and data streaming are turned off).
Page 34 Our Experience Things to watch out for when mapping with a smartphone Make sure that you lock your iPhone when it is in your pocket. This will ensure that you don’t end up with ‘ghost’ readings while you’re en route to the next outcrop. 2.
Page 35: System Requirements
Minimum iPhone model requirements iPhone 4, running iOS 7.0 and above Android smartphone version An Android version of FieldMove Clino is also available to download from the Google Play Store™. Please note that the Android app is for smartphones only, and will not scale up to 7”...
Page 36: About Midland Valley
About Midland Valley Midland Valley is a world leader in the field of structural geology and the development of software modelling tools, using structural validation, restoration and forward modelling, to provide best practice workflows and reduce structural uncertainty. Our structural modelling...
