- Page 1 Turbo Unit Instruction Manual Adflo ® Turbo Unit Powered Air Purifier 93-0061-00 Rev. A...
- Page 2 Turbo Unit WARNING Do not issue this product until the user reads and understands this instruction manual which is an essential part of this Adflo ® Turbo Unit. If equipment is not properly assembled, connected, and used in strict conformance...
-
Page 3: Table Of Contents
Figure 16 Removing the HE Filter and OV/SD/CL/HC Cartridge ........14 Figure 17 Installing the OV/SD/CL/HC Cartridge into the Adflo ®... -
Page 4: General Information
The Adflo Cartridge consists of OV/SD/CL/HC ® purifier. Combined with the appropriate Hornell elements housed in a black plastic shell. The Adflo ® headpiece, it helps to provide respiratory protection Cartridge snap-fastens onto the Turbo Unit. Then, the from specific airborne contaminants. -
Page 5: Headpiece Approvals And Limitations
(NIOSH 42 CFR 84) Approval Label that was (this manual) supplied with the Adflo ® Turbo Unit. 2) Hornell Respiratory Product Warranty Registration (postcard) For all other headpiece approvals—such as eye, face, helmet protection standards—see the separate manual 3) Breathing Tube that was supplied with the headpiece. -
Page 6: Chapter 2 Adflo Turbo Unit Use
Adflo ® Turbo Unit. The battery can Close-Up of Battery Charger. also be removed from the Adflo ® unit for charging (see Section 3.2: Removing and Installing the Battery Pack). 3) When the battery is fully charged, the charger’s LED... -
Page 7: Pre-Operational Adflo
Turbo Unit Inspection & Testing Prior to beginning each work shift, perform the following Pre-Operational Inspection to ensure the proper airflow and alarm function of the Adflo ® Turbo Unit. 1) Replace any missing or damaged parts. 2) Ensure that the HE filter is properly installed in the Adflo ®... - Page 8 “J” channels found on both the headpiece’s airduct and the Adflo ® Turbo Unit. 93-0061-00 Rev. A...
-
Page 9: Headpiece Assembly Preparation
8) Put on the headpiece. resulting in serious bodily injury or loss of life. 2.4 Donning the System 1) Install a fully-charged battery into the Adflo ® Turbo Unit (see Section 2.1 Battery Charging/Discharging and Section 3.2 Removing & Reinstalling the Battery Pack). -
Page 10: Fault Location Procedures
® Turbo Unit 2.5 Fault Location Procedures WARNING If, at any time during operation, the Adflo ® Turbo Unit stops, or the airflow to the headpiece stops or is reduced, or if the user detects an odor or taste of gas,... - Page 11 1) Let the unit run for 2 minutes so normal” OV/SD/CL/HC cartridge it can automatically adjust to the new filter configuration If further assistance is required, contact your Hornell distributor or the Hornell technical support staff (see Chapter 4). 93-0061-00 Rev. A...
-
Page 12: Chapter 3 System Maintenance
If the Adflo ® Turbo Unit is stored at temperatures below 32°F (0°C), the battery pack must be allowed to Detach the breathing tube from the Adflo ® Turbo Unit warm up to achieve optimal battery performance. The and inspect for holes or tears. Wipe clean the... -
Page 13: Replacing The He Filter, The Prefilter & The Spark Arrestor
NEVER use tools to ply the latch; you can permanently damage the latch or the Filter Cover, making the unit inoperable. Remove the used HE (particle) filter from the Adflo ® Figure 11: Filter Cover Removal, Step 2 Turbo Filter Cover. NOTE: the HE filter CANNOT be While continuing to slightly deflect the silver Filter cleaned. -
Page 14: Replacing/Installing The Ov/Hc/Cl/Sd Adflo Cartridge
Chapter 4 for replacement parts). have the OV/SD/CL/HC Adflo ® cartridge installed from the factory; other users will choose to install the Place the cleaned (or new) spark arrestor into the Adflo ® OV/SD/CL/HC Adflo ® cartridge on their own to meet Turbo Filter Cover. -
Page 15: Replacing The Belt
Adflo ® Turbo Filter Cover into the left side of the OV/SD/CL/HC Adflo cartridge (see ® Figure 18). Press down on the right side of the Adflo ® Turbo Filter Cover until the catch fully engages. Figure 20: Adflo ®... -
Page 16: Chapter 4 Customer Information
Read your instruction manual to the risk of serious bodily injury or loss of life. Hornell, avoid certain situations which could void this warranty. Inc. is not responsible for system performance if other... -
Page 17: Turbo Unit With Part Numbers
See the manual that came with the headpiece assembly for a listing of replacement parts and accessories. 4.5.4 Miscellaneous Replacement Parts The only user-serviceable parts on and Accessories the Adflo ® Turbo Unit are the Adflo ® Turbo Filter Cover, HE Filter,... -
Page 18: Definition Of Safety Signal Words Per Ansi Z535.4
Adflo ® Turbo Unit Appendix A Appendix B Technical Specifications for Adflo ® Turbo Definition of Safety Signal Words per Unit Powered Air Purifier: ANSI Z535.4 Assigned Protection Factor (for approved purifier/ headpiece combination): WARNING Airflow: 6+ cfm (170+ lpm) Noise: <70 db at maximum... - Page 19 Adflo ® Turbo Unit Notes 93-0061-00 Rev. A...
- Page 20 ™ are trademarks of Hornell. All other trademarks are the property of their respective owners. Hornell, Inc. reserves the right to make changes in specifications or products at any time without prior notice. ©2003 Hornell, Inc. Printed in USA. 93-0061-00 Rev. A...
