OWNER'S ASSEMBLY AND
● User instructions
● Trailer component diagram
● Assembly and disassembly of the frame & seat
● Attaching and removing the top cover
● Securing and removing children & belongings
● Attaching and removing the wheels
● Attaching the reflectors
● Inserting and removing the flag
● Extending and folding the hitch arm
● Attaching and removing the trailer to/from rear axle
● Attaching and removing the jogger/stroller conversion kit
● Using the braking system
● Disassembly, folding and storage
● Maintenance and service
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USE.
FAILURE TO DO SO MAY RESULT IN DAMAGE TO THIS
PRODUCT OR SERIOUS INJURY OR DEATH TO THE USER
AND RIDERS.
SAFETY MANUAL
CAUTION!!!
0
Advertisement
Table of Contents
Summary of Contents for Redman and Associates BKTRLR-SAMS-1
- Page 1 OWNER’S ASSEMBLY AND SAFETY MANUAL ● User instructions ● Trailer component diagram ● Assembly and disassembly of the frame & seat ● Attaching and removing the top cover ● Securing and removing children & belongings ● Attaching and removing the wheels ●...
-
Page 2: Safety Guidelines
SAFETY GUIDELINES The trailer/jogger/stroller is designed and constructed to provide a portable, comfortable and sturdy addition to your outdoor ventures. Please read these instructions and all warnings carefully before using and keep the instructions for future reference. IMPORTANT PASSENGERS RIDERS MUST ALWAYS WEAR... -
Page 3: Pre-Ride Safety Check
speed to 5 kmph (3 mph) when turning. Do not install a car seat or any other seating device to this trailer/jogger/stroller. Do not make any modifications to the trailer. Children must always fasten safety belts and wear bike helmets. -
Page 4: General Safety Guidelines
PRIDING GUIDELINES Follow these riding guidelines for safe and effective performance. Ride slower than you would if you were riding without the trailer. You will require extra stopping distance. Use your brakes early. Take corners very gradually. Use on smooth roads only. Do not ride over curbs, potholes or off- road. - Page 5 D-ring The person riding the towing bicycle should be at least 18 years of age and in good physical condition. Be sure that the bicycle used with the trailer is in good working condition and has good brakes. A bicycle shop can help with inspection...
- Page 6 RIDING SAFETY GUIDELINES Follow these safety guidelines for safe and effective performance. Before using, be sure the trailer/jogger/stroller is correctly assembled according to the manufacturer’s instructions. Before attaching this trailer to your bicycle, please have your bicycle inspection by a qualified bicycle mechanic for compatibility.
- Page 7 for bicycling. Do not use trailer in snow or icy conditions. Do not travel or descend at high speeds. Do not exceed a safe speed. We recommend no speed over 13kmph (8 mph) and reducing speed to 5kmph (3mph) when turning, because high speeds adversely affect your ability to control the bike and to notice road irregularities.
- Page 8 EXPLODED VIEW FOR CLARIFICATION ONLY...
- Page 9 BILL OF PARTS PART NAME Q’TY PART NAME Q’TY Base Frame Side Panel Side Frame Fabric Bottom Cross Bar Top Cover Hitch Arm Reflector Hitch Clamp Front Fork Safety Strap Front Wheel Safety Pin Knob Suspension Push Bar Wheel Brake Bar Wheel Axle Brake Clip Button Hook...
- Page 10 ASSEMBLY AND DISASSEMBLY OF THE FRAME & SEAT Remove trailer and all components from carton and sort all contents. Unfold side panels of trailer to the upright position. Swing the crossbar upward into position across the top between the side panels and route it through the loops at the top of seat. Insert the crossbar into the upper sleeve and lock with the safety pin.
- Page 11 CAUTION! The vehicle is not suitable for children 12 months or younger. Ensure that the safety pin is secured with the spring clip. Ensure that all the locking devices are engaged before use. WARNINGS! Immediately discard all plastic bags and plastic wrapping materials.
- Page 12 CAUTION! It is strongly recommended that children’s eyes are protected from flying insects and airborne particles when using trailer. For protection, ensure that the insect screen or the clear window is closed when using. WARNINGS! Passengers can become hot inside fully closed trailer during very hot weather or when parked.
- Page 13 belts and shoulder straps and wear helmets. The harness system is designed to keep your passengers immobilized and secure during transport. The harness is designed to accommodate one or two children. Disconnect shoulder strap clips from crotch strap D-ring. ...
-
Page 14: Attaching And Removing The Wheels
CAUTION! There should be a minimum distance of 1.5” (40mm) between the top of the child’s head (without a helmet on) and the roof of cabin. If the child’s head protrudes above the upper crossbeam when seated, they are too tall to ride safely in the trailer. -
Page 15: Attaching The Reflectors
by grabbing the center of the hub and pulling away from trailer. To remove the wheels, reach underneath near the axle tube, press the buttonhook while pulling the wheel away from trailer. WARNINGS! For easy towing and safe handling, check tires often for proper inflation and wear. - Page 16 CAUTION! The reflectors that comply with the CPSC regulations shall be visible on the rear of the trailer WARNINGS! Never use the vehicle at night without adequate lighting and reflectors, obey all local laws for lighting and reflectors in accordance with CPSC requirements. In order to meet CPSC Safety Standards, a reflector must be in place on the tear of the trailer.
- Page 17 EXTENDING AND FOLDING THE HITCH ARM Tip the trailer back on its frame so the underside is fully visible. Remove the safety pin, rotate the hitch arm upward until fully extended. Reinsert the safety pin and lock the spring clip. For folding and storage, reverse the process and be sure to fasten the hitch arm fully.
- Page 18 To release the trailer, reverse the order of the attachment instructions. CAUTION! The height of the hitch clamp shall not exceed 15.5” (400 mm) above a road surface and the standard drawbar load shall be between 30N and 80N. WARNINGS! Ensure the safety pin is secured with the spring clip.
- Page 19 ATTACHING AND REMOVING JOGGER/STROLLER CONVERSION KIT The jogger/stroller conversion kit consists of a push bar and front wheel assemblies that attach on the trailer to convert it for walking use. Install the push bar by inserting ends into frame and pushing down until locking devices snap into place.
- Page 20 USING THE STAMP BRAKES The jogger/stroller is equipped with a hand brake to slow down the speed and to park the vehicle. The push bar is equipped with a locking clip for enhanced parking performance. Pull back and engage the stamp brakes and clip the hook onto brake bar to lock the stamp brakes in place.
- Page 21 and adjust the tension of brake cables for proper braking performance. All parking devices shall be engaged during loading and unloading of passengers or belongings. Be sure that all parking devices work properly. Always use the wrist strap when pushing the vehicle to prevent it from rolling away from you.
-
Page 22: Maintenance
MAINTENANCE From time to time, check your trailer for loose hardware, worn parts, torn material or stitching. Repair or replace parts as needed. Over or under inflation of tires may cause handling issues for the trailer. Replace tires only with street tread and not with BMX or knobby tread. - Page 23 MODEL # BKTRLR-SAMS-1 Impoted by / importe par: Redman and Associates, LLC. 900 SE 5th Street, Suite # 18 Bentonville, AR 72712 TEL: 1-877- 901-8811 MADE IN CHINA FABRIQUE EN CHINE...
