- Page 1 AT&T ® PagePac 20 Voice Paging System TalkMate™ Service Manual-Installation...
- Page 2 ® PagePac 20 Voice Paging System TalkMate™ Service Manual—Installation SM-722050-010 999-500-201IS Issue 1, September 1985 HARRIS CORPORATION Dracon Division 809 Calle Piano, Camarillo, California 93010, U.S.A. Telephone 805/987-9511 Telex 182327 © Harris Corporation Dracon Division 1985...
- Page 3 To order copies of this manual: CALL: Your AT&T information Systems Sales Representative Your Business Sales and Service Center The AT&T Customer Information Center, 1-800-432-6600 WRITE: AT&T Customer Information Center P.O. Box 19901 Indianapolis, IN 46219 ORDER: Document Number 999-500-201IS...
-
Page 4: Table Of Contents
Table of Contents Service Manual-Installation Page i September 1985 Table of Contents Page Introduction Overview PagePac 20 TalkMate TalkMate Cords, Cable, and Jacks TalkMate Controls Installation Overview TalkMate Installation and Connections Operation Overview General Operation Adjusting Talk/Listen Sensitivity and Talk-Back Volume Maintenance and Troubleshooting Overview Troubleshooting... -
Page 5: Introduction
Introduction Service Manual-Installation Page 1-1 September 1985 1. Introduction Overview ® TalkMate™ is an optional module of the PagePac 20 voice paging system and is designed to fit under the PowerMate™ module. The physical characteristics of PowerMate and TalkMate are listed in Table 1-A. -
Page 6: Pagepac 20 Talkmate
