Tevion Micro Freeview Receiver Quick Setup Manual

1. Scart
Use this to connect to an available scart socket on your
TV.
2. Remote Sensor Slot
Connect the remote sensor to the micro freeview
receiver.
3. DC Input
Insert the power adaptor and connect to your mains
electric.
4. RF Out
For connecting external Devices.
5. RF In
To connect your aerial.
To TV scart input
Aerial cable
Aerial
Insert your existing aerial cable
into the RF in socket on your
micro freeview receiver, and
insert into an available scart
socket on your TV.
When switch on the micro freeview receiver for the first time,
the "Easy Install" menu will appear. Use the "LEFT/RIGHT" arrow
keys to setup the region and OSD Language.
Highlight "Search" and press the "OK" button to start the
channel search.
Helpline No. UK/Northern Ireland 01270 508538
Web Support www.quesh.co.uk
Micro Freeview Receiver
Quick Set-Up Guide

FUNCTIONS AND CONNECTIONS

CONNECTING TO YOUR TV

Then insert your remote
sensor into the IR socket and
place the sensor somewhere
visible and free from clutter.
2
1
Connect your power adaptor
into the DC in socket and
connect the plug to your
mains socket.
Rep.Ireland 1800 995 036
Model Number: 44176
5
3
4
